Backlight Inverter Installation Procedures for ViewSonic VX900
There are no screws to remove on this model, you
need to use small flat head screw drive to open the
back cover, starting from the bottom of LCD Monitor
MoniServ, Inc.
http://www.moniserv.com
http://www.lcdpart.com
Set the monitor
upside down
Advertisement
Summary of Contents for MoniServ DAC-12C024MSS
- Page 1 MoniServ, Inc. http://www.moniserv.com http://www.lcdpart.com Backlight Inverter Installation Procedures for ViewSonic VX900 There are no screws to remove on this model, you need to use small flat head screw drive to open the back cover, starting from the bottom of LCD Monitor...
- Page 2 Use Flat head screw drive starting from here...
- Page 3 Set Monitor Face up and lift up this Control panel and set it aside Remove these two screws...
- Page 4 Remove Front Bezel...
- Page 5 Remove these screws Disconnect Speaker wires Disconnect Speaker wires Remove LCD Panel from Back Cover...
- Page 6 Set LCD Panel Face down Remove this screw and metal cover Backlight Inverter...
- Page 7 Disconnect this cable Disconnect CCFL connectors Replace with MoniServ DAC-12C024MSS inverter board. Re-install all component, metal chassis, circuit board and back cover. VX900 should work now.
