Summary of Contents for Modern Lights LumaNumbers
- Page 2 LumaNumbers & LumaLetters come in a variety of sizes, colors and mounting options. They can be installed horizontally or vertically directly to a buildings exterior or by using our mounting plates. Depending on the type of installation, tools needed include a drill with...
- Page 3 Each package includes standard mounting hardware. Some surfaces may require additional anchor bolts. 2 types of mounting risers are included; ½ inch and ¼ inch. The optional mounting plate also includes 4 additional screws and plastic caps to cover the screw holes for a clean appearance once installed.
- Page 4 To install directly into wall, level each template against the surface and mark where to drill the holes. If using the mounting plate, tape the templates to the plate. The included screws are designed to screw directly to the wall or into anchor bolts depending on the type of wall. ...
- Page 5 To install the numbers onto the mounting plate, insert the two screws included with each number through the back of the mounting plate for each number. Install the risers behind the numbers between the wall or the mounting plate. The ½ inch riser will create a broader light spread as opposed to the ¼...
- Page 6 From the backside of the mounting plate, gently thread the screws into back of the numbers and then tighten the screws into the back side of the numbers. Do not over tighten, and use just enough force to secure the numbers. ...
- Page 7 Finally, use a heat gun or hair dryer to seal the joined wiring to lock the connections together, which solders the wires together at the same time. The remaining single gray and white wires will be used to connect to the 12v DC power source. ...
- Page 8 If you have any questions, please visit our website. ModernLights.com...
