Vehicle security system

Advertisement

Quick Links

For convenience this document uses short names when referring to a particular system or kit.
The list below identifies the short names used herein:
Vehicle Security System
Navigating this document can be accomplished by: 1) using the buttons in the Acrobat toolbar or
2) clicking on the bookmark links in the bookmark pane to the left. (Clicking on the (+) symbols
next to a bookmark will expand that bookmark, revealing additional selections).
This installation instruction covers the installation of all Vehicle Security Kits.
Vehicle wiring is subject to change. All possible efforts have been taken to ensure that the
information contained herein is accurate as of the revision dates indicated. As such, it is critical
that vehicle circuits are tested prior to making any connections, to ensure that the proper
vehicle circuit has been located.
Prior to begin
prevent locking the keys in the vehicle.
Prior to beginning your first installation of this product it is recommended that you:
1. Thoroughly review and print out the instructions;
2. Review the reference section to become acquainted with the additional information that is
available.
3. Go through the vehicle specific wiring and use as a reference during the installation .
4. Review the installation video on the Ford Genuine Accessory website that is located with the
VSS Installation Instructions.
Page 1 of 2
READ ME FIRST
TECHNICAL SUPPORT
1-800-FORD-KEY
CANADIAN DEALERS
BILINGUAL FRENCH/ENGLISH
TECHNICAL SUPPORT
(514)973-2846
>VSS
SK9L--19*36-AA
© Copyright Ford 20 FoMoCo

Advertisement

loading

Summary of Contents for Ford VSS

  • Page 1 3. Go through the vehicle specific wiring and use as a reference during the installation . 4. Review the installation video on the Ford Genuine Accessory website that is located with the VSS Installation Instructions. Page 1 of 2 SK9L--19*36-AA ©...
  • Page 2 Systems for return authorization/replacement approval for failed components at no charge by the manufacturer. Return of Components to Code Systems requires the following: 1. Dealer/FAD representative must call the Ford Vehicle Security System Dealer Warranty Department at 1-800-FORDKEY (1-800-367-3539) to obtain generic claim form.
  • Page 3  2Q WKH YHKLFOH ZLUH WR EH VSOLFHG LQWR VWULS RQH LQFK RI LQVXODWLRQ IURP WKH ZLUH  2Q WKH YHKLFOH ZLUH WR EH VSOLFHG LQWR VHSDUDWH WKH VWUDQGV WR DOORZ WKH QHZ ZLUH WR EH SODFHG Page 1 of 9 © Copyright Ford 2012 FoMoCo...
  • Page 4  :UDS WKH FRQQHFWLRQ ZLWK HOHFWULFDO WDSH VR WKH WDSH FRYHUV WKH ZLUHV DSSUR[LPDWHO\ WZR LQFKHV RQ HLWKHU VLGH RI WKH FRQQHFWLRQ ‡ 7DSH WKH ZLUHV WRJHWKHU DV VKRZQ LQ WKH LOOXVWUDWLRQ Page 2 of 9 © Copyright Ford 2012 FoMoCo...
  • Page 5 E\ PDWFKLQJ WKH ZLUH VL]H RQ WKH GLHV ZLWK WKH ZLUH VL]H VWDPSHG RQ WKH EXWW VSOLFH +ROG WKH FULPSLQJ WRRO VR WKH LGHQWLILHG ZLUH VL]HV DUH IDFLQJ \RX 6TXHH]H WRRO KDQGOHV WRJHWKHU XQWLO WKH UDWFKHW UHOHDVHV WKHQ DOORZ WKH MDZV RI WKH WRRO WR RSHQ IXOO\ Page 3 of 9 © Copyright Ford 2012 FoMoCo...
  • Page 6 ‡ :LUH LQVXODWLRQ GRHV QRW HQWHU EXWW VSOLFH :LUH LV IOXVK ZLWK RU H[WHQGV VOLJKWO\ EH\RQG HQG RI EXWW VSOLFH %  ‡ :LUH LV YLVLEOH WKURXJK LQVSHFWLRQ KROH RI VSOLFHV &  Page 4 of 9 © Copyright Ford 2012 FoMoCo...
  • Page 7 (YHQO\ SRVLWLRQ KHDW VKULQN WXELQJ RYHU ZLUH UHSDLU 8VH D VKLHOGHG KHDW JXQ WR KHDW WKH HQWLUH OHQJWK RI WKH KHDW VKULQN WXELQJ XQWLO WKH KRW PHOW DSSHDUV IURP ERWK HQGV RI WKH WXELQJ Page 5 of 9 © Copyright Ford 2012 FoMoCo...
  • Page 8 WDNLQJ FDUH QRW WR QLFN RU FXW ZLUH VWUDQGV 3XOO ZLUH VWUDLJKW IURP VWULSSHU ,I ZLUH LV SXOOHG DW DQ DQJOH ZLUH VWUDQGV PD\ EH FXW RII GXULQJ VWULSSLQJ &XW RII WKH HQG DQG UHVWULS Page 6 of 9 © Copyright Ford 2012 FoMoCo...
  • Page 9 IURP :LUH  WDNLQJ FDUH QRW WR QLFN RU FXW ZLUH VWUDQGV 3XOO ZLUH VWUDLJKW IURP VWULSSHU ,I ZLUH LV SXOOHG DW DQ DQJOH ZLUH VWUDQGV PD\ EH FXW RII GXULQJ VWULSSLQJ &XW RII WKH HQG DQG UHVWULS Page 7 of 9 © Copyright Ford 2012 FoMoCo...
  • Page 10 $SSO\ KHDW VKULQN WXELQJ WR :LUH  7ZLVW ERWK HQGV RI :LUH  DURXQG :LUH  6ROGHU ZLUHV WRJHWKHU  %HQG :LUH  EDFN RYHU WKH WZLVWHG ZLUHV IRU VHDOLQJ ,QVSHFW VROGHU MRLQW ERQG  (YHQO\ SRVLWLRQ KHDW VKULQN WXELQJ RYHU ZLUH UHSDLU Page 8 of 9 © Copyright Ford 2012 FoMoCo...
  • Page 11 SUHYHQWV DLU DQG PRLVWXUH IURP HQWHULQJ WKH VROGHU SRLQW 8VH D VKLHOGHG KHDW JXQ WR KHDW WKH HQWLUH OHQJWK RI WKH KHDW VKULQN WXELQJ XQWLO WKH KRW PHOW DSSHDUV IURP ERWK HQGV RI WKH WXELQJ Page 9 of 9 © Copyright Ford 2012 FoMoCo...
  • Page 12 NOTE: Only a High impact of open hand on steering wheel should cause a honk. Light to Medium impacts need to be adjusted down. Page 1 of 2 © Copyright Ford 2011 FoMoCo...
  • Page 13 High impact level. Press the Lock button on the trim switch to decrease the sensitivity or press Unlock to increase the sensitivity. Turn the ignition key to the OFF position. Arm the system and check the new settings. Page 2 of 2 © Copyright Ford 2011 FoMoCo...
  • Page 14 2013 Taurus - Key Start Vehicle Security Manual Table of Contents VSS SYSTEM INSTALLATION CONTENTS INSTALLATION GENERAL PROCEDURES Proper Splicing Techniques Programming Functional Test Shock Sensor Setting WIRING DIAGRAMS Vehicle Specific Wiring Diagrams SK9L2J-19G364-AA © Copyright Ford 2011 FoMoCo Contents...
  • Page 15 2013 Taurus - Key Start Vehicle Security INSTALLATION Module Preparation Vehicle Security System (VSS) • Taurus - Key Start NOTICE: VSS Installation Kit Contents VSS System Kit QUANTITY DESCRIPTION Page 1 of 8 SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo...
  • Page 16 2013 Taurus - Key Start Vehicle Security INSTALLATION (Continued) • • • Vehicle Preparation Page 2 of 8 SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo...
  • Page 17 2013 Taurus - Key Start Vehicle Security INSTALLATION (Continued) Install the VSS Control Module and Harness Assembly • Install LED • • • • Identify Circuit Wires For Connections Page 3 of 8 SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo...
  • Page 18 2013 Taurus - Key Start Vehicle Security INSTALLATION (Continued) Page 4 of 8 SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo...
  • Page 19 2013 Taurus - Key Start Vehicle Security INSTALLATION (Continued) Power Connection Program The VSS System Secure The Control Module Harness and Control Module Page 5 of 8 SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo...
  • Page 20 INSTALLATION (Continued) Install Trim Programming • • • • Option Bank - 1 Chart (4 - Honks) BANK OPTIONS DESCR NOTICE: Program Bank 2 Chart (5 Honks) BANK OPTIONS DESCR • Page 6 of 8 SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo...
  • Page 21 If the LED is not illuminated press the Unlock button and 66. Arm the VSS system from outside of the car verify the LED illuminates. with the driver’s door window open. Verify the The VSS module is now programmed.
  • Page 22 ’’optional‘‘ starter disable function does the steering wheel with moderate force in an not allow vehicle to start. attempt to trigger the VSS system. • The horn and lights should go through the 73. Press the OEM key fob unlock button to disarm 30 second alarm sequence to indicate full system.
  • Page 23 2013 Taurus - Key Start MAKE THIS CONNECTION FIRST! CHASSIS GROUND POINT IN DRIVERS KICK PANEL VSS MODULE C2280A Pin 1 Dome Lights (GRAY/VIOLET) + DRIVERS SIDE KICK PANEL HARNESS Door Lock (BLUE/GREEN) C olor Function C2280C Pin 6 BLACK...
  • Page 24 2013 Taurus - Key Start BCM Connector Locations C2280D C2280C C2280E C2280A...
  • Page 25 2013 Mustang Vehicle Security Manual Table of Contents VSS SYSTEM INSTALLATION CONTENTS INSTALLATION GENERAL PROCEDURES Proper Splicing Techniques Programming Functional Test Shock Sensor Setting WIRING DIAGRAMS Vehicle Specific Wiring Diagrams Contents SK9L2J-19G364-AA © Copyright Ford 2011 FoMoCo...
  • Page 26 3. Place the supplied fuses into the power • A - Harness: 24-way, used on all systems. distribution block on the VSS control module. • C- Harness: 16-way, used on all systems • Move the polarity jumpers to their proper incorporating Lot Mode.
  • Page 27 Vehicle Preparation 8. Remove the left hand scuff plate and cowl trim panel. 9. Remove the 2 lower instrument panel steering column cover screws and the cover. Page 2 of 8 SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo...
  • Page 28 12. Remove the right hand scuff plate, cowl trim panel and fuse door panel. Install the VSS Control Module and Harness Assembly 13. Place the VSS module and harness assembly in the vehicle. 19. NOTE: A DVOM connected to the correct wire Install LED will show 0V, then show 12V when the ignition switch is in the RUN/START position.
  • Page 29 28. Connect the Green/Violet wire from the control switch is pressed. module harness to the Gray/Violet dome light circuit wire under dash panel. Identify the Yellow/Violet door unlock circuit wire at the SJB connector C2280C Pin 4. Page 4 of 8 SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo...
  • Page 30 Identify the Violet/Grey unlock all doors circuit wire at the SJB connector C2280D Pin 27. Program The VSS System 40. Connect the Light Green wire from the control 45. Refer to the control module programming module harness to the Violet/Grey unlock all section for this vehicle.
  • Page 31 • All other doors should remain closed. panel. 55. Turn the ignition key to the RUN position. Programming 56. Press and hold the VSS override button for at least 10 seconds. NOTE: Make sure that the hood and doors are closed before proceeding.
  • Page 32 NOTE: If you require additional assistance: CALL 1-800-FORD KEY. NOTE: If during any of the functional test steps the VSS system or vehicle does not react or perform 58. Press and release the Lock button on the trim accordingly please refer to the VSS troubleshooting switch 3 times.
  • Page 33 ’’optional‘‘ starter disable function. doors. 77. Turn ignition key to the START position to 71. Arm the VSS system from outside of the car verify ’’optional‘‘ starter disable function does with the driver’s door window open. Verify the not allow vehicle to start.
  • Page 34 ‘13 Mustang MAKE THIS CONNECTION LAST! Battery (BLUE/RED) VSS MODULE WIRE HARNESS IGNITION SWITCH STEERING COLUMN HARNESS Ignition (GRAY/VIOLET) HARNESS C olor Function Starter (BLUE/WHITE) Battery PINK Ignition 1 Input/Output VIOLET Starter Interrupt Motor Side Key Side Starter Interrupt Key Side...
  • Page 35 ‘13 Mustang See "SJB Layout" page for connector locations. Dome Light (GRAY/VIOLET)** UNDER DAASH VSS MODULE WIRE HARNESS PANEL Door Lock (BLUE/GREEN)** Factory Alarm Disarm C2280C Pin 8 (GREEN/VIOLET) KICK PANEL HARNESS C2280C Pin 4 Door Unlock (YELLOW/VIOLET) C2280D Pin 28...
  • Page 36 ‘13 Mustang SMART JUNCTION BOX (SJB) C2280E C2280C C2280D...
  • Page 37 2013 Fiesta - Key Start Vehicle Security Manual Table of Contents VSS SYSTEM INSTALLATION CONTENTS INSTALLATION GENERAL PROCEDURES Proper Splicing Techniques Programming Shock Sensor Setting WIRING DIAGRAMS Vehicle Specific Wiring Diagrams SK9L2J-19G364-AA Contents © Copyright Ford 2011 FoMoCo...
  • Page 38 VEHICLE SECURITY SYSTEM WARNING. WINDOW DECAL Module Preparation 3. Place the supplied fuses into the power distribution block on the VSS control module. • Move the polarity jumpers to their proper locations on the control module, see illustration. Page 1 of 9 SK9L2J-19G364-AA ©...
  • Page 39 2013 Fiesta - Key Start Vehicle Security INSTALLATION (Continued) 4. Place the software cartridge onto the VSS control module. 5. Plug the wiring harness(es) into the module. • A - Harness: 24-way, used on all systems. • B - Harness: 10-way, used on all systems.
  • Page 40 Cover each wire group with electrical tape for approximately 18''. Depending on the vehicle, there will be 2 to 5 different wire groups. Trim the unused wires approximately 6 - 8'' from the module. Page 3 of 9 SK9L2J-19G364-AA © Copyright Ford 2011 FoMoCo...
  • Page 41 10. Open and remove the glove box. 11. Remove the RH lower Instrument panel insulator. Install the Vehicle Security System Control Module and Harness Assembly 12. Place the VSS control module and harness assembly in the vehicle. Identify Circuit Wires For Connections Page 4 of 9 SK9L2J-19G364-AA ©...
  • Page 42 NOTE: proper wire splicing techniques. 13. Connect the Black ground wire from the VSS module harness to the chassis ground point on the drivers side. • Chassis ground points are located near the drivers side sill plate.
  • Page 43 Connect only if system will be used in Lot Mode. NOTE: A DVOM connected to the correct wire will show 1V, then show 0V when the door unlock switch is pressed. Page 6 of 9 SK9L2J-19G364-AA © Copyright Ford 2011 FoMoCo...
  • Page 44 Identify the Green/Violet passenger door unlock motor circuit wire at BCM C2280E Pin 23. 37. Connect the Light Green wire from the control module harness to the Green/Violet passenger door unlock motor circuit wire at BCM C2280E Pin 23. Page 7 of 9 SK9L2J-19G364-AA © Copyright Ford 2011 FoMoCo...
  • Page 45 A DVOM connected to the correct wire will show 12V with the key in any position. A logic probe will show power on the correct wire with the key in any position. Page 8 of 9 SK9L2J-19G364-AA © Copyright Ford 2011 FoMoCo...
  • Page 46 To ensure the best performance of the built-in shock sensor, secure the control module at three points to the vehicle. Use the supplied long tie wraps to mount the VSS control module to the underdash wiring harness. All Vehicles 53. Install the upper and lower steering column shrouds.
  • Page 47 Vehicle Security 2013 Fiesta - Key Start GENERAL PROCEDURES 5. Press and hold the VSS override button for at least 10 seconds. Programming After 10 seconds the horn with honk 3 times, indicating the system is now in the learn mode.
  • Page 48 If the LED is not illuminated press the Unlock button and verify the LED illuminates. 14. The VSS module is now programmed. SK9L2J-19G364-AA Page 2 of 2 © Copyright Ford 2011 FoMoCo...
  • Page 49 '13 Fiesta - Key Start MAKE THIS CONNECTION FIRST! CHASSIS GROUND POINT IN DRIVERS KICK PANEL VSS MODULE WIRE HARNESS Brake Light (BLUE/GRAY) BRAKE SWITCH BCM C2280G Door Lock (YELLOW/GRAY) Pin 6 Door Unlock (BLUE/BROWN) C olor F unction DRIVER KICK...
  • Page 50 TYPE "A" CUSTOM WIRE HARNESS ‘13 Fiesta - Key Start VSS MODULE WIRE HARNESS BODY CONTROL MODULE (BCM) C2280G Pin 4 LR Door Ajar Switch (GREEN) C2280G Pin 3 RR Door Ajar Switch (YELLOW) C2280G Pin 7 Deck Lid Ajar Switch (YELLOW/ORANGE)
  • Page 51 2013 Fiesta - Push Button Start Vehicle Security Manual Table of Contents VSS SYSTEM INSTALLATION CONTENTS INSTALLATION GENERAL PROCEDURES Proper Splicing Techniques Programming Shock Sensor Setting WIRING DIAGRAMS Vehicle Specific Wiring Diagrams SK9L2J-19G364-AA Contents © Copyright Ford 2011 FoMoCo...
  • Page 52 VEHICLE SECURITY SYSTEM WARNING. WINDOW DECAL Module Preparation 3. Place the supplied fuses into the power distribution block on the VSS control module. • Move the polarity jumpers to their proper locations on the control module, see illustration. Page 1 of 9 SK9L3Z-19G361-AA ©...
  • Page 53 2013 Fiesta - Push Button Start Vehicle Security INSTALLATION (Continued) 4. Place the software cartridge onto the VSS control module. 5. Plug the wiring harness(es) into the module. • A - Harness: 24-way, used on all systems. • B - Harness: 10-way, used on all systems.
  • Page 54 Cover each wire group with electrical tape for approximately 18''. Depending on the vehicle, there will be 2 to 5 different wire groups. Trim the unused wires approximately 6 - 8'' from the module. Page 3 of 9 SK9L3Z-19G361-AA © Copyright Ford 2012 FoMoCo...
  • Page 55 10. Open and remove the glove box. 11. Remove the RH lower Instrument panel insulator. Install the Vehicle Security System Control Module and Harness Assembly 12. Place the VSS control module and harness assembly in the vehicle. Page 4 of 9 SK9L3Z-19G361-AA...
  • Page 56 NOTE: Review proper wire splicing techniques before proceeding. 13. Connect the Black ground wire from the VSS module harness to the chassis ground point on the drivers side. • Chassis ground points are located near the drivers side sill plate.
  • Page 57 Identify the Yellow/Gray power door lock circuit wire at BCM C2280G pin 6. 27. Connect the Blue wire from the control module harness to the Yellow/Gray power door lock circuit wire at BCM C2280G pin 6. Page 6 of 9 SK9L3Z-19G361-AA © Copyright Ford 2012 FoMoCo...
  • Page 58 Identify the Brown/Green driver door unlock motor circuit wire at BCM C2280C Pin 3. 35. Connect the Brown wire from the control module harness to the Brown/Green driver door unlock motor circuit wire at BCM C2280C Pin 3. Page 7 of 9 SK9L3Z-19G361-AA © Copyright Ford 2012 FoMoCo...
  • Page 59 Identify the Green/Violet drivers door ajar circuit wire at BCM C2280G Pin 10. 45. Connect one of the Green/Violet wires from the diode harness to the Green/Violet drivers door ajar circuit wire at BCM C2280G Pin 10. Page 8 of 9 SK9L3Z-19G361-AA © Copyright Ford 2012 FoMoCo...
  • Page 60 To ensure the best performance of the built-in shock sensor, secure the control module at three points to the vehicle. Use the supplied long tie wraps to mount the VSS control module to the underdash wiring harness. All Vehicles 53. Install the upper and lower steering column shrouds.
  • Page 61 2013 Fiesta - Push Button Start Vehicle Security GENERAL PROCEDURES 5. Press and hold the VSS override button for at least 10 seconds. Programming After 10 seconds the horn with honk 3 times, indicating the system is now in the learn mode.
  • Page 62 If the LED is not illuminated press the Unlock button and verify the LED illuminates. 14. The VSS module is now programmed. SK9L2J-19G364-AA Page 2 of 2 © Copyright Ford 2011 FoMoCo...
  • Page 63 2013 Fiesta - Push Button Start MAKE THIS CONNECTION FIRST! CHASSIS GROUND POINT IN DRIVERS KICK PANEL VSS MODULE WIRE HARNESS Brake Light (BLUE/GRAY) BRAKE SWITCH Door Lock (YELLOW/GRAY) BCM C2280G Pin 6 Door Unlock (BLUE/BROWN) C olor F unction...
  • Page 64 TYPE "A" CUSTOM WIRE HARNESS ‘13 Fiesta - Push Button Start VSS MODULE WIRE HARNESS BODY CONTROL MODULE (BCM) C2280G Pin 4 LR Door Ajar Switch (GREEN) C2280G Pin 3 RR Door Ajar Switch (YELLOW) C2280G Pin 7 Deck Lid Ajar Switch (YELLOW/ORANGE)
  • Page 65 2013 Focus - Electric Vehicle Vehicle Security Manual Table of Contents VSS SYSTEM INSTALLATION CONTENTS INSTALLATION Shock Sensor Sensitivity Adjustment VSS Functional Test SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo Contents...
  • Page 66 This kit can be installed on Focus vehicles equipped with gas engines, in addition to the Focus - Electric Vehicle. 1. Verify correct kit number. Review VSS Installation Kit Contents NOTE: Kits are vehicle specific and are not interchangeable. 2. Review the VSS kit contents. Vehicle Security System (VSS) System Kit QUANTITY DESCRIPTION VSS Module...
  • Page 67 Vehicle Security INSTALLATION (Continued) 5. NOTE: Failure to secure harness connection with a zip-tie will result in loss of VSS system functionality. Connect the VSS T-harness to the vehicle's OBD II port. • Secure the T-harness to the OBD II port using a zip-tie.
  • Page 68 • Drill a 9/32" hole into the selected location, for the LED to mount in. 11. Route the LED wire harness to the VSS module. 12. Connect the LED wire harness to the VSS module. • Secure the LED wire harness with tie-straps.
  • Page 69 Shock Sensor Sensitivity Adjustment NOTE: The VSS module is equipped with an internal dual zone Shock Sensor. The VSS system will activate a single horn honk / single light flash anytime a light to moderate impact is detected, and a "panic" type 30 second horn honk / light flash sequence when a heavy impact is detected while the VSS system is armed.
  • Page 70 15. Press the LOCK button on the vehicle's RKE fob to arm the VSS system. The LED will light solid for 10-15 seconds and then begin to flash a steady on/off sequence to indicate the system is armed.
  • Page 71 23. Test all other vehicle doors and the trunk in the same manner, by setting off the alarm and disarming with the keyfob. Page 6 of 6 SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo...
  • Page 72 2013 Fusion Vehicle Security Manual Table of Contents VSS SYSTEM INSTALLATION CONTENTS INSTALLATION Shock Sensor Sensitivity Adjustment VSS Functional Test SK9L2J-19G364-AA © Copyright Ford 2012 FoMoCo Contents...
  • Page 73 Vehicle Security System (VSS) VSS System Components Fusion 1. Verify correct kit number. Review VSS Kit Contents NOTE: Kits are vehicle specific and are not interchangeable. 2. Review the VSS kit contents. Vehicle Security System (VSS) Kit QUANTITY DESCRIPTION VSS Module T-harness Zip-tie...
  • Page 74 2013 Fusion Vehicle Security INSTALLATION (Continued) 4. Position aside the LH weather strip and remove the LH Instrument Panel (IP) side trim panel. 5. Remove the upper cowl side trim panel. Page 2 of 10 SK9L3Z-19G361-AA © Copyright Ford 2012 FoMoCo...
  • Page 75 Vehicle Security INSTALLATION (Continued) VSS System Installation 6. Disconnect the electrical connector from the back of the gateway module. 7. Connect the VSS T-harness to the gateway module electrical connector. Page 3 of 10 SK9L3Z-19G361-AA © Copyright Ford 2012 FoMoCo...
  • Page 76 8. Connect VSS T-harness to the back of the gateway module. 9. Install the VSS module to the IP frame. • Ensure the VSS module is positioned for access to the shock sensor adjustment knob for later use. • Secure with zip-ties.
  • Page 77 Identify the Lt. Green rear driver's side door ajar switch wire located in the harness coming down from the IP (behind the carpet), and headed into the driver’s door sill plate. Page 5 of 10 SK9L3Z-19G361-AA © Copyright Ford 2012 FoMoCo...
  • Page 78 A logic probe will show power on the correct wire, then show ground when the horn button is held. Identify the Green/White horn circuit wire at Body Control Module (BCM) Connector C2280G Pin Page 6 of 10 SK9L3Z-19G361-AA © Copyright Ford 2012 FoMoCo...
  • Page 79 • Drill a 9/32" hole into the selected location, for the LED to mount in. 18. Route the LED wire harness to the VSS module. 19. Connect the LED wire harness to the VSS module. • Secure the LED wire harness with tie-straps.
  • Page 80 Shock Sensor Sensitivity Adjustment NOTE: The VSS module is equipped with an internal dual zone Shock Sensor. The VSS system will activate a single horn honk/single light flash anytime a light to moderate impact is detected, and a "panic" type 30 second horn honk/light flash sequence when a heavy impact is detected while the VSS system is armed.
  • Page 81 22. Press the LOCK button on the vehicle's RKE fob to arm the VSS system. The LED will light solid for 20 seconds and then begin to flash a steady on/off sequence to indicate the system is armed.
  • Page 82 32. Test all other vehicle doors, the hood and the trunk in the same manner, by setting off the alarm and disarming with the keyfob. Page 10 of 10 SK9L3Z-19G361-AA © Copyright Ford 2012 FoMoCo...
  • Page 83 2013 C-Max Vehicle Security Manual Table of Contents VSS SYSTEM INSTALLATION CONTENTS INSTALLATION Shock Sensor Sensitivity Adjustment VSS Functional Test Contents SK9L3Z-19A361-AA © Copyright Ford 2012 FoMoCo...
  • Page 84 Vehicle Security C-Max 1. Verify correct kit number. Review VSS Installation Kit Contents NOTE: Kits are vehicle specific and are not interchangeable. 2. Review the VSS kit contents. Vehicle Security System (VSS) System Kit QUANTITY DESCRIPTION VSS Module VSS T-harness...
  • Page 85 Vehicle Security INSTALLATION (Continued) 5. NOTE: Failure to secure harness connection with a zip-tie will result in loss of VSS system functionality. Connect the VSS T-harness to the vehicle's OBD II port. • Secure the T-harness to the OBD II port using a zip-tie.
  • Page 86 • Drill a 9/32" hole into the selected location, for the LED to mount in. 11. Route the LED wire harness to the VSS module. 12. Connect the LED wire harness to the VSS module. • Secure the LED wire harness with tie-straps.
  • Page 87 Observe the LED while performing the following step. NOTE: The VSS module will automatically program itself once connected to the harness / vehicle. The VSS system should immediately flash the LED 3 times to indicate that it is entering "Auto Learn Mode".
  • Page 88 15. Press the LOCK button on the vehicle's RKE fob to arm the VSS system. The LED will light solid for 10-15 seconds and then begin to flash a steady on/off sequence to indicate the system is armed.
  • Page 89 20. Lower the driver's door window, then close all doors, hood, and trunk/hatch and press lock on the keyfob. The LED should stay lit for 10-15 seconds while the VSS system pre-arms, after which it will flash every 3-4 seconds in fully armed mode.
