Summary of Contents for CONQUEST CA1342
- Page 1 CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL CA1342 FORWARD PLATE COMPACTOR OPERATOR’S MANUAL Serial #: ________________________________ 548 BOURQUIN RD, ESTEVAN, SK S4A 2A7 PH: (855) 483-2500 Copyright © 2020 Conquest Equipment, Inc.
-
Page 2: Table Of Contents
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL Index Safety Instructions For Plate Compactors ................3 Safety ............................3 Transport and Lifting........................ 3 Maintenance ..........................4 Periodic Maintenance ......................4 Fire .............................. 4 Residual Risk ..........................4 Max Inclination ........................... 5 Function............................5 Applications .......................... -
Page 3: Safety Instructions For Plate Compactors
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL SAFETY INSTRUCTIONS FOR PLATE COMPACTORS SAFETY Plate compactors must only be operated by a person who: • is at least 18 years old; • is physically and mentally fit for this job; • may be expected to carry out the job he’s charged with carefully. -
Page 4: Maintenance
Do not turn the engine on without air filter. • WARNING Modifications in this machine are subject to the expressed approval of Conquest Attachments. In case of non-observance, Conquest will refuse all liabilities and all warranties. Do not make maintenance operations when machine is running or when engine is on. -
Page 5: Max Inclination
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL Prolonged exposure to vibrations could cause injury to your hands or wrists. If you feel severe discomfort or pain, do not use the machine and consult a doctor before resuming work. Prolonged exposure to loud noises without adequate ear protection could cause permanent hearing damage. -
Page 6: Applications
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL APPLICATIONS The CA1342 compactor is suitable for repairing asphalted surfaces, for small compacting jobs and for preparing green areas. Only use the machine for the purpose for which it is intended. OPERATION CHECKS BEFORE STARTING Before using compactor, carefully read instruction manual. -
Page 7: Engine Oil
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL Turn the engine switch to the OFF position. • WARNING Never operate the engine switch when the engine is at the maximum speed. Turn the fuel valve to the OFF position. • ENGINE OIL Check oil level using the proper dipstick, if necessary, refill with SAE 15 W 40 oil. - Page 8 CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL Clean the upper bowl. • Remount the upper filtering element. • Remove the lower filtering element. • Clean and dry filtering element. • Drain and clean bowl. • Fill with engine oil up to level mark.
-
Page 9: Maintenance
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL MAINTENANCE PARTS MAINTENANCE INTERVAL Air filter Check filter, clean or replace if necessary Check filter oil level (only oil bath models) Fuel tank Check fuel tank and fuel cap lid. Replace if necessary. Daily... -
Page 10: Troubleshooting
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL TROUBLESHOOTING TROUBLE POSSIBLE CAUSE SOLUTION The transmission belt is broken Replace the belt The engine works properly The wear and tear has but the machine does not caused the belt to loosen up vibrate... -
Page 11: Lubrication
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL LUBRICATION Model Quantity Type Exciter CA1342 Dry Exciter ---------- See engine Engine All models SAE 15W40 instructions ENGINE / EXCITER REVS Model Engine Exciter CA1342 3500 – 3550 5350 – 5400 WARNING Set the rpm as per the above table. A different rpm will cause the compactor to work improperly and could break it. -
Page 12: Technical Data
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL TECHNICAL DATA Model CA1342 CA1342 Dimensions plate mm 420 x 550 Width x Length With Rollbar and Water Operating weight With Lifting Hook With Rollbar Tank CA1342 kg 76 kg 77 kg 78 CA1342... -
Page 13: Expanded View
CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL EXPANDED VIEW EXCITER – BASE PLATE... - Page 14 CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL EXCITER – BASE PLATE CODE DESCRIPTION 560128 BASE PLATE CA1342 151106 BEARING NSK 6309 2RS C3 VV 151102 SEEGER E45 UNI 7435 560071 CLOSED EXCITER COVER 560068 OPENED EXCITER COVER 131043 OILSEAL 30X55X7 BA...
- Page 15 CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL ENGINE SUPPORT...
- Page 16 CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL ENGINE SUPPORT CODE DESCRIPTION 560168 ENGINE SUPPORT 560149 PULLEY SPACER FOR ENGINE SUPPORT 151199 WASHER M 8 UNI 6592 ZN 560184 BELT PROTECTION HOLDER 152286 CENTRIFUGAL CLUTCH 19,05 IORI 181139 HONDA ENGINE GX 160...
- Page 17 CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL VIBRATORY PLATE...
- Page 18 CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL VIBRATORY PLATE CODE DESCRIPTION ---------- COMPL. BASE PLATE CA1342 560180 BELT PROTECTION 560154 ASSY ENGINE SUPPORT 131030 BELT A33 560203 WHEEL WITH AXLE 151904 FLANGED NUT DIN 6923-M10 152040 SCREW FLG DIN 6921 M8X16 8.8 ZN...
- Page 19 CONQUEST CA1342 PLATE COMPACTORS OPERATOR’S MANUAL WATER TANK WATER TANK CODE DESCRIPTION Q.TY 132062 WATER TANK 132254 WATER TANK CAP 132205 RUBBER HOSE 0,15 mt 560123 SPRINKLING PIPE CA1342 152276 WATER VALVE GAS RB9085 3/8-8 560175 NUT GAS 3/8 H15 CH 27 ZN (INSIDE WATER TANK)
-
Page 20: Warranty
OPERATOR’S MANUAL WARRANTY This Conquest Attachments product is warranted to be free from defects in workmanship for three years from the date of purchase. Warranty is void on products and components that have been modified or repaired without the prior consent of Conquest Attachments.
