Summary of Contents for Fujikura AFL Telecommunications NOYES TURBOTEST 500B
- Page 1 Noyes TurboTest 500B Specs Provided by www.AAATesters.com TURBOTEST 500B Insertion Loss and Return Loss Test Set User’s Guide...
- Page 3 TURBOTEST 500B Insertion Loss and Return Loss Test Set User’s Guide (For software version 4.1 or higher) © 2002-2009, AFL Telecommunications, all rights reserved. T50B-00-1000 Revision F, 2009-08-04 Specifications are subject to change without notice.
- Page 4 Limited Warranty One Year Limited Warranty All Noyes products are warranted against defective material and workmanship for a period of one year from the date of shipment to the original customer. Any product found to be defective within the warranty period will be repaired or replaced by Noyes.
-
Page 5: Table Of Contents
Table of Contents Table of Contents Safety Information Important Safety Information ................v Section 1: General Information Contacting Noyes Customer Service ..............1 Unpacking and Inspection..................1 Feature Overview ....................2 Recommended Accessories ................2 Section 2: Functional Description TURBOTEST 500B Ports ...................4 Front Panel Features ..................5 Section 3: Common Functions Main Menu Configuration ..................6 Selecting Test Mode ..................7... - Page 6 TURBOTEST 500B User’s Guide Section 4: Turbo Mode - Measuring Insertion & Return Loss Screens and Menus ..................22 Selecting a Test Wavelength ................23 Setting References ....................24 OLTS - Insertion Loss Reference ..............24 SELF Referencing ..................25 MUTUAL Referencing ................26 ORL - Return Loss Reference.................27 Step I: 14.6 dB Referencing - setting the upper ORL limit ......27 Step II: Mandrel Wrap Referencing - setting the lower ORL limit ....27 Performing a TURBO Test ..................29...
- Page 7 Reviewing Saved OPM Test Results ..............55 Auto Retest ....................56 Using the TURBOTEST 500B with Optical Fiber Identifiers ........57 Tone Setup ....................57 Section 9: Talk Option Screens and Menus ..................58 Talk Setup ......................59 Section 10: Troubleshooting and Maintenance Battery Maintenance ..................62 Battery Replacement ..................62 Battery Recharging ..................62 Battery Indicator Lights..................62...
- Page 8 TURBOTEST 500B User’s Guide Figure 5-1. ORL Mode Screens and Menus............32 Figure 5-2. Mandrel Wrap Referencing..............35 Figure 5-3. Testing a Connector................36 Figure 5-4. Link Test Setup................37 Figure 5-5. Reviewing Saved ORL Test Results..........38 Figure 5-6. ORL Auto Retest................39 Figure 6-1.
-
Page 9: Safety Information
Safety Information Important Safety Information WARNING! Use of controls or adjustments other than those specified herein may result in hazardous radiation exposure. The TURBOTEST 500B is a CLASS I LASER PRODUCT. WARNING! Use only the specified AC adapter. Use of another type of AC adapter can damage the instrument and create the danger of fire and electrical shock. - Page 10 TURBOTEST 500B User’s Guide...
-
Page 11: Section 1: General Information
Section 1 Section 1: General Information Thank you for purchasing a Noyes TURBOTEST 500B Optical Loss Test Set. This instrument has been designed specifically for testing high fiber count cable commonly found in Telco or Broadband systems. The purpose of this User’s Guide is to explain how to use and maintain this instrument. Please check our web site at www.AFLtele.com/go/Noyes for updates to this manual, software updates, and additional application information. -
Page 12: Feature Overview
TURBOTEST 500B User’s Guide Feature Overview High-speed transmission systems employ laser sources with narrow bandwidths, which are sensitive to back-reflections caused by components, splices, and connectors. If too much light is reflected back to the laser transmitter, the modulation characteristics and spectrum of the laser may change. This change will degrade the systems performance. - Page 13 Section 1 a fabric-covered or foam-covered stick, we are offering a molded cleaning tip that will trap contamination and wick cleaning solvents from bulkhead connectors. This new cleaning tip is a molded, sintered polymer that is both porous and pliable conforming to virtually any fiber end-face polish geometry while trapping and absorbing contaminants.
-
Page 14: Section 2: Functional Description
TURBOTEST 500B User’s Guide Section 2: Functional Description TURBOTEST 500B Ports Adapter cap The OPM port must be equipped with an adapter cap. Caps for different connector styles are available from Noyes. Removable Cleaning port Provides access to the internal ferrule OPM optical input for safe and easy cleaning. -
Page 15: Front Panel Features
Section 2 Front Panel Features [Talk Active] indicator [Laser Active] indicator When [ON], indicates that Talk laser is When [ON], indicates that the laser Voice Test Port active. transmitter is turned [ON]. Talk Active Laser Active Display Soft keys Used to show various screens and setup The label shown on the display above menus, measured power or loss, and the key indicates the current function... -
Page 16: Section 3: Common Functions
TURBOTEST 500B User’s Guide Section 3: Common Functions Main Menu Configuration When the TURBOTEST 500B is powered on, the working screen -[TEST] screen of the currently selected test mode is always displayed. The [MAIN MENU] screen of the currently selected test mode may be accessed from the [TEST] screen by pressing the [MENU] key. -
Page 17: Selecting Test Mode
Section 3 Selecting Test Mode The TURBOTEST 500B offers five operating modes to perform the following fiber optic measurements: • [TURBO] mode - both optical return loss and optical loss measurements. Two TURBOTEST 500B units are required to operate in this mode. When the [TURBO] mode is enabled one TURBOTEST 500B unit auto-links to second TURBOTEST 500B unit. -
Page 18: File Management
TURBOTEST 500B User’s Guide File Management All the commands and sub-screens you need for creating new files, adding or editing the test identification parameters, opening saved files, deleting saved files, or downloading saved files to a PC can be accessed from the [FILE MENU] screen. -
Page 19: Creating A New File And Setting Test Identification Parameters
Section 3 Creating a New File and Setting Test Identification Parameters The [NEW] option from the [FILE MENU] screen allows you to create a new file to which a series of tests will be saved and set up test identification parameters, such as filename and number, test location, technician and job information, and add notes. -
Page 20: Setting The [Start Fiber] Parameter
TURBOTEST 500B User’s Guide 5 Press the [SEL] soft key to enter the highlighted character in the filename field. 6 Repeat steps 4 & 5 to enter up to 10 characters. 7 When you finish entering characters, press the [OK] soft key to return to the [EDIT FILE HEADER] screen. -
Page 21: Setting The [Location] Parameter
Section 3 7 When you finish entering characters, press the [OK] soft key to return to the [EDIT FILE HEADER] screen. 8 You may continue setting other test identification parameters by selecting the desired parameter (refer to the corresponding section for details). 9 Or you may save the created file by pressing the [SAVE] soft key. -
Page 22: Setting The [Technician] Parameter
TURBOTEST 500B User’s Guide 9 Or you may save the created file by pressing the [SAVE] soft key. 10 If you choose the [SAVE] option, you will be prompted to confirm creation of a new file. • Choose [YES] to save the created file and return to the [TEST] screen of the currently selected test mode. -
Page 23: Setting The [Job] Parameter
Section 3 test mode. • Or choose [NO] to return to the [EDIT FILE HEADER] screen. Note: If you attempt to create a new file with the filename that already exist, you will be prompted to confirm overwriting. Choose [YES] to confirm or [NO] to cancel overwriting. Setting the [JOB] Parameter To set the [JOB] parameter, perform the following steps: 1 From the [EDIT FILE HEADER] screen, use either [Up] or [Down] arrow key to highlight the line... -
Page 24: Adding Notes
TURBOTEST 500B User’s Guide confirm overwriting. Choose [YES] to confirm or [NO] to cancel overwriting. Adding Notes To add [NOTES], perform the following steps. 1 From the [EDIT FILE HEADER] screen, use either [Up] or [Down] arrow key to highlight the line labeled [NOTE]. -
Page 25: Opening Saved Files
Section 3 Opening Saved Files 1 From the [FILE MENU] screen, use either [UP] or [DOWN] arrow key to highlight the [OPEN] option. 2 Press the [SELECT] soft key to access the [OPEN FILE] screen. A list of saved files will be displayed. - Page 26 TURBOTEST 500B User’s Guide 5 When prompted to confirm deletion, choose [YES] or [NO]. 6 By pressing the [ALL] soft key, you may delete all saved files at once. When prompted to confirm deletion, choose [YES] or [NO]. 7 To return to the [FILE MENU] screen, press the [BACK] key Transferring Test Results to a PC The TURBOTEST 500B can store internally up to 460 in any combination of its four operating modes.
-
Page 27: Viewing Statistics
Section 3 Viewing Statistics The [STATISTICS] screen allows you to review the following information: • Total number of saved files. • Number of saved files per every test mode. • Number of used and free fibers. • Percentage of the available memory. To view statistics: 1 From the [MAIN MENU] screen, use either [UP] or [DOWN] arrow key to highlight the [FILE] option. -
Page 28: Other Functions Menu
TURBOTEST 500B User’s Guide Other Functions Menu All the commands and sub-screens you need for general setup, adjusting power, generating a [Tone] signal, and setting OLTS and ORL Pass/Fail limits can be accessed from the [OTHER FUNCTIONS] screen. To access the [OTHER FUNCTIONS] screen, perform the following steps: •... -
Page 29: Power Adjustment
Section 3 Power Adjustment Use the following procedures to turn lasers [ON], [OFF], or to generate a [Tone] signal (270 Hz , 1 KHz, or 2 KHz) and adjust the [Continuous Wave - CW] signal. Refer to Figure 3-4 for a related illustration. Note: Every operating test mode allows you to access the [POWER ADJUSTMENT] screen and perform the [Continuous Wave - CW] signal adjustment, but to turn lasers [ON], [OFF] or to generate a [Tone] signal (270 Hz, 1 KHz, 2 KHz), you need to enable the [OPM] test mode. -
Page 30: Adjusting Continuous Wave - Cw Signal
TURBOTEST 500B User’s Guide Adjusting Continuous Wave - CW Signal 1 Enable the [OPM] test mode, then press the [MENU] key to display the [OPM MAIN MENU] screen. 2 Use either [UP] or [DOWN] arrow key to highlight the [OTHER FUNCTIONS] option. 3 Press the [SELECT] soft key to access the [OTHER FUNCTIONS] screen. -
Page 31: General Setup
Section 3 General Setup The [GENERAL SETUP] sub-screen allows you to adjust Contrast, set Time/Date, and enable or disable the [SOUND], [POWER SAVE], or [LIMITS] functions. 1 From the [OTHER FUNCTIONS] screen, use either [UP] or [DOWN] arrow key to highlight the [GENERAL SETUP] option. -
Page 32: Section 4: Turbo Mode - Measuring Insertion & Return Loss Screens And Menus
TURBOTEST 500B User’s Guide Section 4: Turbo Mode - Measuring Insertion & Return Loss Screens and Menus TURBO TRIPLE nm REFERENCE IS OVER 1 DAY OLD To [REFERENCE] screen To [Test] screen SET REFERENCE IS RECOMMENDED LATER TURBO TRIPLE nm TURBO REFERENCE R E A DY INSERTION LOSS... -
Page 33: Selecting A Test Wavelength
Section 4 Two TURBOTEST 500B units are required to perform bi-directional insertion loss and return loss tests on a single fiber. One unit must be operating in the [TURBO] mode while another - in the [REMOTE] test mode. When the [TURBO] test mode is selected, the LCD display on the MAIN unit shows the [TURBO] indicator in the upper left part of the screen and the selected wavelength(s) in the upper right part of the screen. -
Page 34: Setting References
TURBOTEST 500B User’s Guide Setting References Setting references is recommended on a daily basis before testing and when changing test jumper(s). Lasers must be set to -5 dBm output (refer to the section titled “Power Adjustment”, page 19). If lasers have been adjusted since last referencing, references need to be reset. -
Page 35: Self Referencing
Section 4 when self-referencing. Either referencing method may be selected for performing an insertion loss reference setup. SELF Referencing Clean all fiber optic connectors and optical ports before performing test procedures described below. Refer to Figure 4-2 for a related illustration. 1 On entry to the [TURBO REFERENCE] screen, the [INSERTION LOSS] screen is highlighted by default. -
Page 36: Mutual Referencing
TURBOTEST 500B User’s Guide MUTUAL Referencing Clean all fiber optic connectors and optical ports before performing test procedures described below. Refer to Figure 4-3 for a related illustration. 1 On entry to the [TURBO REFERENCE] screen, the [INSERTION LOSS] screen is highlighted by default. Press the [SELECT] soft key to access the [INSERTION LOSS REFERENCE] sub-screen. -
Page 37: Orl - Return Loss Reference
Section 4 ORL - Return Loss Reference ORL reference characterizes/calibrates the upper and lower back-reflection limits. Clean all fiber optic connectors and optical ports before performing test procedures described below. Step I: 14.6 dB Referencing - setting the upper ORL limit 1 From the [TURBO REFERENCE] screen, use either [UP] or [DOWN] arrow key highlight the [14.6 dB REF] option. -
Page 38: Figure 4-4. Mandrel Wrap Referencing
TURBOTEST 500B User’s Guide 6 Attach the APC connector on the reference cable to the Test Port. 7 Terminate the reference cable by slowly wrapping it around the supplied mandrel until the back- reflectance reading no longer changes. In most cases 10 wraps are sufficient. Note: The TURBOTEST 500B will accept an ORL reference between 40 and 70 dB. -
Page 39: Performing A Turbo Test
Section 4 Performing a TURBO Test Use the following procedures on both TURBOTEST 500B units to simultaneously perform insertion and return loss tests on a single fiber optic link. For this setup procedure the two units will be differentiated by T500B unit A-MAIN and T500B unit Z-REMOTE. Clean all fiber optic connectors and optical ports before performing test procedures described below. -
Page 40: Figure 4-6. Reviewing Test Results
TURBOTEST 500B User’s Guide To Review Test Results (MAIN unit only): 7 From the [TEST COMPLETE] screen, press the [REVIEW] soft key to display the [TURBO REVIEW] screen (refer to Figure 4-6). 8 Press either [UP] or [DOWN] arrow key to toggle between [ORL] - optical return loss test results and [LOSS] insertion loss test results. -
Page 41: Reviewing Saved Turbo Test Results
Section 4 Reviewing Saved TURBO Test Results 1 Prior to reviewing saved tests, select the [TURBO] test mode, and then [OPEN] the file to be viewed (refer to sections titled “Selecting Test Mode”, page 7 and “Opening Files”, page 15). 2 Press the [MENU ]key to display the [TURBO MAIN MENU] screen. -
Page 42: Section 5: Orl Mode - Measuring Optical Return Loss
TURBOTEST 500B User’s Guide Section 5: ORL Mode - Measuring Optical Return Loss Screens and Menus TRIPLE nm REFERENCE OVER 1 DAY OLD SET REFERENCE IS RECOMMENDED LATER To [TEST] screen To [REFERENCE] screen ORL REFERENCE TRIPLE nm 14.6 dB REF T E S T R E S U LT S F O R F I B E R # X WRAP MANDREL FIBER # X... -
Page 43: Setting References
Section 5 One TURBOTEST 500B unit is required to perform an optical return loss test. Fiber optic terminators are recommended to remove back-reflections when testing fiber link less than 60 kilometers (37.5 miles) in length. Call Noyes for ordering information. Refer to Appendix A for a chart and graph relating to return loss of a fiber link with open end vs. -
Page 44: Orl - Return Loss Reference
TURBOTEST 500B User’s Guide ORL - Return Loss Reference ORL reference characterizes/calibrates the upper and lower back-reflection limits. Clean all fiber optic connectors and optical ports before performing test procedures described below. Step I: 14.6 dB Referencing - setting the upper ORL limit 1 From the [ORL REFERENCE] screen, use either [UP] or [DOWN] arrow key highlight the [14.6 dB REF] option. -
Page 45: Step Ii: Mandrel Wrap Referencing - Setting The Lower Orl Limit
Section 5 Step II: Mandrel Wrap Referencing - setting the lower ORL limit Refer to Figure 5-2 for a related illustration. 1 From the [ORL REFERENCE] screen, use either [UP] or [DOWN] arrow key to highlight the [WRAP MANDREL] option. 2 Press the [SELECT] soft key to access the [WRAP MANDREL] screen. -
Page 46: Performing A Connector Test
TURBOTEST 500B User’s Guide Performing a Connector Test Use the following procedures to perform return loss tests on a jumper cable connector. When testing in the [ORL] mode, the display is live. The TURBOTEST 500B is continuously measuring return loss, thus fiber movement will result in fluctuations in the displayed measurement values. -
Page 47: Performing A Link Test
Section 5 Performing a Link Test Refer to Figure 5-4 for a related illustration. 1 Attach the APC connector on the reference cable to the Test Port. 2 Attach the UPC connector on the reference cable to the fiber under test at the patch panel. Note: If the link under test is less than 60 km, then the use of a Terminator is recommended. -
Page 48: Reviewing Saved Orl Test Results
TURBOTEST 500B User’s Guide Reviewing Saved ORL Test Results Refer to Figure 5-5 for a related illustration. 1 Prior to reviewing saved tests, select the [ORL TEST MODE], and then [OPEN] the file to be viewed (refer to sections titled “Selecting Test Mode”, page 7 and “Opening Files”, page 15). 2 Press the [MENU] key to display the [ORL MAIN MENU] screen. -
Page 49: Auto Retest
Section 5 Auto Retest Refer to Figure 5-6 for a related illustration. 1 From the [ORL RESULTS] screen, using either [UP] or [DOWN] arrow key highlight the fiber to be retested. • You may press the [MORE] soft key to scroll through saved test results. 2 Press the [HEADER] soft key to display the [AUTO RETEST] label (if not displayed). -
Page 50: Section 6: Olts Mode - Measuring Insertion Loss
TURBOTEST 500B User’s Guide Section 6: OLTS Mode - Measuring Insertion Loss Screens and Menus OLTS TRIPLE nm REFERENCE OVER 1 DAY OLD To [REFERENCE] screen To [Test] screen SET REFERENCE IS RECOMMENDED LATER OLTS REFERENCE OLTS TRIPLE nm INSERTION LOSS R E A DY FIBER # X λ... -
Page 51: Setting References
Section 6 Two TURBOTEST 500B units are required to perform bi-directional insertion loss tests on a single fiber. One unit must be operating in the [OLTS] test mode while another - in the [REMOTE] test mode. When the [OLTS] test mode is selected, the LCD display on the MAIN unit shows the [OLTS] indicator in the upper left part of the screen and the selected wavelength(s) in the upper right part of the screen. -
Page 52: Olts - Insertion Loss Reference
TURBOTEST 500B User’s Guide OLTS - Insertion Loss Reference [INSERTION LOSS] referencing allows you to reference the laser output for accurate loss measurement of a fiber link. Two methods are available for setting an insertion loss reference: [SELF] or [MUTUAL]. Note: [MUTUAL] referencing is available for eliminating variations due to connector tolerance when self-referencing. -
Page 53: Mutual Referencing
Section 6 MUTUAL Referencing Refer to Figure 6-3 for a related illustration. 1 On entry to the [OLTS REFERENCE] screen, the [INSERTION LOSS] screen is highlighted by default. Press the [SELECT] soft key to access the [INSERTION LOSS REFERENCE] sub-screen. 2 Using either [UP] or [DOWN] arrow key highlight the [MUTUAL] option. -
Page 54: Performing A Link Test
TURBOTEST 500B User’s Guide Performing a Link Test One TURBOTEST 500B unit must be operating in the [OLTS] test mode while another - in the [REMOTE] test mode. For this setup procedure the two units will be differentiated by T500B unit A-MAIN and T500B unit Z-REMOTE. - Page 55 Section 6 To Review Test Results (MAIN unit only): 7 From the [TEST COMPLETE] screen, press the [REVIEW] soft key to display the [OLTS REVIEW] screen. After reviewing results you may do one of the following: • You may press the [EXIT] soft key or [BACK] key to return to the [TEST COMPLETE] screen. •...
-
Page 56: Reviewing Saved Olts Test Results
TURBOTEST 500B User’s Guide Reviewing Saved OLTS Test Results 1 Prior to reviewing saved tests, select the [OLTS] test mode, and then [OPEN] the file to be viewed (refer to sections titled “Selecting Test Mode”, page 7 and “Opening Files”, page 15). 2 Press the [MENU ]key to display the [OLTS MAIN MENU] screen. - Page 57 Section 6...
-
Page 58: Section 7: Testing With The Turbotest 500B, Opm, And Ols
TURBOTEST 500B User’s Guide Section 7: Testing with the TURBOTEST 500B, OPM, and OLS If only one TURBOTEST 500B unit is available for testing, the Optical Power Meter (OPM) and Optical Light Source (OLS) may be used for performing optical loss tests on two fibers. The Optical Power Meter and Light Source in the following examples are manufactured by Noyes, other manufacturers' equipment can also be used. -
Page 59: Turbotest 500B Reference Setup
Section 7 4 The [POWER ADJUST] option is highlighted by default. Press the [SELECT] soft key to display the adjustment sub-screen. 5 Attach the APC connector on the reference cable to the Test Port. 6 Attach an adapter to the other end of the reference cable. 7 Press the [λ] soft key to select the laser to be adjusted. -
Page 60: Figure 7-2. Turbotest 500B Reference Setup
TURBOTEST 500B User’s Guide Do the following to the TURBOTEST 500B 3 Return to the [OPM] test mode. 4 Attach the APC connector on the reference cable to the OPM Port. 5 Attach an adapter to the connector at the other end of the reference cable. 6 Attach the reference cable on the Optical Light Source to the adapter on the TURBOTEST 500B reference cable. -
Page 61: Performing A Link Test
Section 7 Performing a Link Test Once the reference values have been set in the TURBOTEST 500B and the Optical Power Meter, do the following procedures to perform optical loss tests on two optical fiber links. Refer to Figure 7-3 for a related illustration Do the following to the Optical Power Meter and Light Source: 1 Disconnect the cables at the adapters. - Page 62 TURBOTEST 500B User’s Guide 7 Attach the reference cable that is connected to the OPM Port to the fiber under test (Fiber #1). 8 Attach the reference cable that is connected to the Test Port to the second fiber under test (Fiber #2).
-
Page 63: Section 8: Opm Mode
Section 8 Section 8: OPM Mode Screens and Menus 1310 nm TEST RESULTS FOR FIBER #X FILE## FIBER #X λ SAVE UNITS Select wavelength Select units of measure Press the [SAVE] soft key to Use [UP] or [DOWN] arrow key save test results in the next to select a specific memory available memory location. -
Page 64: Setting References
TURBOTEST 500B User’s Guide The TURBOTEST 500B may be used as a stand alone Optical Power Meter to perform diagnostic and evaluation tests associated with fiber optic transmission systems. The TURBOTEST 500B measures both absolute power (dBm or µW) and loss (dB). The operational wavelength and the measurement mode (dBm, dB, or µW) must correspond with the specifications of the transmitter under test. -
Page 65: Reviewing Saved Opm Test Results
Section 8 5 To save test results in a specific memory location, perform the following steps: • Press either [UP] or [DOWN] arrow key to select a specific memory location to increase or decrease fiber number. • Press the [SAVE] soft key to store test results in the selected location. Once saved, test results can later be retrieved. -
Page 66: Auto Retest
TURBOTEST 500B User’s Guide Auto Retest Refer to Figure 8-4 for a related illustration. 1 From the [OPM RESULTS] screen, using either [UP] or [DOWN] arrow key highlight the fiber to be retested. • You may press the [MORE] soft key to scroll through saved test results. 2 Press the [HEADER] soft key to display the [AUTO RETEST] label (if not displayed). -
Page 67: Using The Turbotest 500B With Optical Fiber Identifiers
Section 8 Using the TURBOTEST 500B with Optical Fiber Identifiers The TURBOTEST 500B is designed to generate the 2 kHz [TONE] signal for use with Optical Fiber Identifiers to isolate specific fibers from a bundle. In the following procedures the Noyes OFI 200 Optical Fiber Identifier is used to detect the modulated tone from the TURBOTEST 500B. -
Page 68: Section 9: Talk Option
TURBOTEST 500B User’s Guide Section 9: Talk Option Screens and Menus TALK CONNECT TO VOICE PORT START TALK C A L L I N G The units will establish a connection and ring TALK C O N N E C T E D ANSWER TALK C O N N E C T E D... -
Page 69: Talk Setup
Section 9 The TURBOTEST 500B is optionally equipped to allow voice communication between operators while testing other fibers in a bundle. Designed for use on spare single-mode fibers, the instrument allows quick connection to terminated connectors. The voice communication feature is useful where other types of communication are not available. - Page 70 TURBOTEST 500B User’s Guide CONNECTED The display will read ANSWER 7 Press the [ANSWER] soft key. CONNECTED The display will read VOLUME RETURN • You may press the UP or DOWN arrow key to adjust the volume. Note: The volume control is automatically readjusted to default settings when the [TALK] mode is turned [OFF] or the unit is powered down.
-
Page 71: Section 10: Troubleshooting And Maintenance
Section 10 Section 10: Troubleshooting and Maintenance This section suggests how to diagnose and solve problems that you may encounter, describes the displayed messages, explains how to clean optical ports and charge the battery. Please use the following sequence of steps if there is a problem. 1 Review the "Troubleshooting"... -
Page 72: Battery Maintenance
TURBOTEST 500B User’s Guide Battery Maintenance Battery Replacement To replace a battery: 1 Remove the protective rubber boot from a unit. 2 Remove the battery compartment cover located on the back of the unit. 3 Replace the battery observing proper polarity. 4 Replace the cover and rubber boot. -
Page 73: Cleaning Optical Ports
Section 10 Cleaning Optical Ports The Voice, Test, and OPM Ports must be kept free from dirt or other contaminates to ensure accurate measurements and operation. A supply of optical cleaning pads and isopropyl alcohol or a connector- cleaning cartridge is recommended to clean the optical ports. Before conducting the cleaning procedures that follow, turn the instrument off. -
Page 74: Cleaning Opm Port
TURBOTEST 500B User’s Guide If using lint-free optical cleaning pads and isopropyl alcohol • Be sure to use 99% IPA that has not been contaminated. • Dampen the wipe with the alcohol and gently wipe the exposed ferrule. Then dry the ferrule using a new optical wipe 4 Using a can of filtered compressed air (held vertically), blow out any contaminants from the adapter. -
Page 75: Turbotest 500B Messages
Section 10 TURBOTEST 500B Messages The following display messages are listed alphabetically for easy reference. Message Cause/Meaning Solution The amount of light detected Be sure laser output is properly set in Laser Adjustment is above the range of the screen under OPM menu. Perform the required test TURBOTEST 500B. - Page 76 TURBOTEST 500B User’s Guide REFERENCE NOT VERIFIED The TURBOTEST Clean all fiber optic connectors again. 500B is unable to If operating in TURBO mode, perform the reference setup procedures verify the reference again. Refer to Section 4 cable value. If operating in OLTS mode, perform the reference setup procedures again.
-
Page 77: Section 11: Specifications
Section 11 Section 11: Specifications TURBOTEST 500B specifications Model T503B T504B T506B T506B-FTTH Calibrated wavelengths (nm) 1310, 1550 1310, 1550 1310, 1550, 1625 1310, 1490, 1550 Output power (dBm) Emitter type Laser Laser Laser Laser Safety class Class I FDA 21 CFR 1040.10 and 1040.11, IEC 60825-1: 2007-03 Detector type InGaAs InGaAs... -
Page 78: Rs-232 Pin Designations
TURBOTEST 500B User’s Guide RS-232 Pin Designations PC Cable DB 9 Female Not Used DTR - Data Terminal Ready Transmitted Data Clear to Send Received Data RTS - Ready to Send DTR - Data Terminal Ready Not Used Ground Shield... -
Page 79: Appendix A: Return Loss Of Fiber Link With Open End Vs. Terminated End
Section 11 Appendix A: Return Loss of Fiber Link with Open End vs. Terminated End Length Length 1310 nm 1310 nm 1550 nm 1 550 nm miles Terminated Open Terminated Open 1.61 38.1 15.9 40.9 15.6 3.22 35.7 17.1 38.3 16.5 4.83 34.5... - Page 80 TURBOTEST 500B User’s Guide...
- Page 81 Thank you for choosing Noyes Test & Inspection 16 Eastgate Park Road Belmont, NH 03220 Phone: 800-321-5298 9001 603-528-7780 Fax: 603-528-2025 www.AFLtele.com/go/Noyes...
