1. Introduction

Thank you to choose IBOX V3 for your access control needs.
This manual contains detailed informations about installation of your IBOX V3.
IBOX V3 is a professional server including an application designed to help you in managing access
control system as well as automations.
The devices that you can use are :
A controller for 2 doors (XM200), and the 8 I/O extension board (up to 4 XM8 per XM200).
Your working environment is based on a web interface that allows you to access to IBOX V3 from
any computer (LAN or WAN) using your Web Browser (IE is NOT compatible).
The application run under Linux system to guarantee a solid stability.
Array of possibilities offered by the access control equipment
Users
Events
Alarm inputs
Alarm outputs
Bus
Array of possibilities offered by IBOX V3
Users
16.000
Events
Unlimited – Depends on the hard drive size
Operators
Unlimited – Depends on the hard drive size
Exports
CSV Format
Backup
Settable - on local hard drive and distant on your own ftp server
Connectivity
TCP/IP on Ethernet network
Fieldbus
1 x RS485 expandable to 8 (optional, with D8RS distributor
QG IBOX V3.0 - september 2017
!
IBOX V3
Starting guide
Version 3
XM200
16.000
8.000
4
4
RS485
RS485
XM8
XM216
-
-
8
8
RS485
-
-
16
16
Page 1
