Oaktree Products HomeAware HA360VPT Quick Setup Manual

HomeAware Remote Phone Transmitter
The HomeAware Remote Phone Transmitter (item# HA360VPT) is designed
to expand the scope of the HomeAware Main Unit, alerting individuals of an
incoming telephone call from a phone located in a different room, video relay
service or fax. It will be necessary to link your Basic Receiver to your
HomeAware Main Unit.
To link the remote phone transmitter to HomeAware Main Unit, follow steps
below:
1. Remove pull tab located at the bottom of the HA360VPT to activate
batteries
2. Carefully remove the latch to expose the bottom compartment of the
HA360VT.
a. NOTE: if the batteries fall out, install them into the compartment
with both "+" sides of the battery facing the black LINK button.
When batteries are installed properly, the red light on the front
of the HA360VPT should illuminate when the black link button is
pushed. If the light does not light up, the batteries may be
backwards of the
3. Press SET UP button on the Main Unit. The word LINK will show on the
display where the time of day is usually appears. Press ENTER. The
word LINK will begin to flash.
4. Press and hold down the link button on the bottom of the HA360VPT.
The red light on the transmitter will light up. Release the button and
the words PICK A DEVICE will begin to scroll on the display of the main
Quick Set-Up Guide
Item# HA360VPT
Oaktree Products
800.347.1960
otp@oaktreeproducts.com
SET-UP BUTTON
ENTER
