INSTALLATION INSTRUCTIONS
FM-25814
•
Read all instructions before installing.
•
System is intended for installation by a licensed electrician in accordance with the National Electrical Code (NEC) and local regulations.
•
When handling the fixture, do not apply pressure to the LEDs. Hold the fixture by the base only.
•
Retain installation instructions for future maintenance reference.
All parts must be used as indicated in these instructions. This product is designed for use only with the supplied parts and/or
accessories designated for use by Modern Forms. Substitution of parts or accessories not designated for use with this product by Modern
Forms could result in personal injury or property damage, and will void the warranty. Contact an authorized dealer or the manufacturer if any
parts are damaged or missing.
Coastal conditions may cause mineral and residue build-up on the fixture. We recommend that customers in coastal
areas clean all external surfaces of the fixture once every two weeks with a wet cloth.
Pour éviter tout choc électrique, assurez-vous que le disjoncteur soit mis hors tension avant de commencer.
•
Lisez toutes les instructions avant l'installation.
•
Le système doit être installé par un électricien licensié conformément au code national de l'électricité (NEC), et également aux
règlements locaux.
•
Lors de la manipulation du luminaire, n'appuyez pas sur les LED. Tenez-le uniquement par la base.
Toutes les pièces doivent être utilisées comme indiqué dans ces instructions. Ce produit est conçu pour être utilisé seulement
avec les pièces et/ou accessoires fournis pour être utilisés avec les produits Modern Forms. Remplacer des pièces ou accessoires non conçus
pour ce produit Modern Forms pourrait causer des dommages corporels ou matériels et pourrait également causer l'annulation de la
garantie. Veuillez contacter un revendeur autorisé ou le fabricant si des pièces manquent ou sont endommagées.
Les conditions côtières peut causer une accumulation de minéraux et de résidue sur le luminaire. Nous recommendons
aux clients qui resident dans les zones côtières de nettoyer toutes les surfaces externes du luminaire une fois toutes les deux semaines avec
un chiffon humide.
A
Wire Connector
Qty: 3PCS+1 Extra
Phone (800) 526.2588
Fax
(800) 526.2585
44 Harbor Park Drive
Port Washington, NY 11050
B
Mounting Screw
Qty: 4+1 Extra
1600 Distribution Ct
Lithia Springs, GA 30122
1750 Archibald Avenue
Ontario, CA 91760
1
