HYDRAULIC TABLE CART — 1000-LB.
OWNER'S MANUAL
WARNING:
Read
carefully
and
understand
all
MACHINE
ADJUSTMENTAND
OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item# 44498
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1000-LB and is the answer not in the manual?

Questions and answers

Summary of Contents for Roughneck 1000-LB

  • Page 1 HYDRAULIC TABLE CART — 1000-LB. OWNER’S MANUAL WARNING: Read carefully understand MACHINE ADJUSTMENTAND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 44498...

  • Page 2: Intended Use

    For technical questions please call 1-800-222-5381. INTENDED USE This Roughneck Hydraulic Table Cart has a hydraulic scissor lift tabletop with easy foot pedal operation. It's ideal for lifting, positioning and transporting heavy materials around the shop, factory, warehouse or office.

  • Page 3: Important Safety Considerations

    IMPORTANT SAFETY CONSIDERATIONS USE AND CARE 1. Do not exceed the 1000 lb max weight capacity and be aware of dynamic loading! 2. When the table is hoisted the weight of goods on the table should not exceed the capacity. While loading the table, goods should be loaded gently.

  • Page 4: Operation

    Note: The Control Lever controls the operation of the Hydraulic Pump unit. To lower the Pump and Table, squeeze the Control Lever. When the Control Lever is released, the Pump and Table movement will stop and the table will remain stationary. OPERATION 1.

  • Page 5: Maintenance And Lubrication

    MAINTENANCE AND LUBRICATION 1. BEFORE EACH USE, inspect the general condition of the cart. Check for loose hardware, misalignment of binding parts, cracked or broken parts, and any other condition that may affect its safe operation. 2. For convenient storage, the handle can be folded down. To do this, press down on the Locking Bar, then press down on the Handle.
  • Page 6 REMOVING AIR FROM THE PUMP If the Lift Table is not performing properly, you may need to bleed the air from the system. There are two possible scenarios: (1) The pump is a closed system; after some period of usage, the air would enter into the oil gradually, it would affect the performance of the lift table.
  • Page 7 MAIN DIAGRAM & PARTS LIST...
  • Page 8 Part Description Part Description Part Description Handle Cotter Pin Lock Nut Roll Pin Wheel Control Lever Connecting Rod Bushing Hex Nut Bolt Hex Bolt Bolt Foot Pedal Bearing Jacket Grip Seat Washer Pull Rod Cotter Pin Roller Retaining Ring Washer Washer Handle Lock Pivot Pump...

  • Page 9: Warranty

    Part Description Part Description Part Description Dust Ring Base Pump Piston O-Ring Spring Top Nut Release Valve Linkage Sealing Gasket Seal Washer Spring Cap Rubber Fluid Plug Axle Sleeve Spring Housing O-Ring Bolt T-Ring Screw Plug Cylinder Spring Copper Washer Cotter Pin Pumping Valve Spindle Pumping Valve Seat...
