Great Gazebo 4FT STAND Assembly Instructions

4FT Stand
assembly instructions
Setup
This Assembly requires two or more people
1) Position the left and right sides of the Bottom Frame with snaps facing outward
and connect together by inserting the pipe with two pieces of velcro(
top sockets on the front of the booth and the other without velcro (
bottom sockets with buttons snapping into the button holes.
2) Attach the top counter cross brace with two pieces of velcro(
found near the back of the booth making sure the buttons snap into the button
holes.
3) Align counter velcro side down and press down firmly to secure.
4) Assemble the Top Frame as shown in the diagram, paying special attention to
positioning of each distinctive part.
5) Place assembled top ( ) onto the two vertical support poles (
6) Place the vinyl top onto the assembled Top Frame and snap into place.
7) Attach the Top Frame to the Bottom Frame by lifting the vertical support
poles and inserting into the frame sockets labeled ( ).
8) Snap the vinyl skirt onto the bottom frame, starting from one end.
top frame
) into the
) into the
) into sockets
).
bottom frame
