- Page 1 Connection and installation manual GSM-receiver GSM 420-RS 868...
-
Page 2: Warning Notes
Vienna, 04. 04. 2018 This manual is the sole property of the TOUSEK Ges.m.b.H. and may not be made available to competitors. All rights reserved. No part of it may be reproduced without our prior written permission. We will not accept liability for any claims resulting from misprints or errors. This edition of the manual replaces all earlier publications of the same. -
Page 3: General Information
General information The GSM 420-RS 868 is a reception device that commands two outputs and two independent signal inputs via the GSM (SMS) cell phone network and radio transmission. It is fitted with two independent outputs and two independent inputs. It is possible to configure the device either by sending commands via SMS or through a serial interface of a PC. -
Page 4: Installation
Installation GSM-receiver GSM 420-RS 868 To ensure a safe and reliable operation of your GSM 420-RS 868 device, it must only be installed by qualified personnel. N.C. C N.O. N.O. C N.C. 230Va.c. power supply (IN) inputs IN1 and IN2... - Page 5 1x slow blinking + pause insufficient GSM signal (signal is being tested once per minute) 4x fast blinking + lights in pause no SIM-card available slow blinking the SIM-card is PIN-Code protected - 5 - tousek / E_GSM-420-RS868_00 / 07. 05. 2018...
- Page 6 • Now plug the mains plug in and wait until the programming LED (L-3) lights permanently after approx. 10s after initial flashing. • Now release the button (P3) and plug the mains plug OFF ca. 10s and ON again! - 6 - tousek / E_GSM-420-RS868_00 / 07. 05. 2018...
- Page 7 Lock telephone no. for calls: pass,DVOC,xxxxxxxx pass: password (max. 5 digits) xxxxxxxx: memory positions in the tel. number list (max. 8 digits) e.g. 12345,DVOC,158 → Lock telephone no. for pos. 1,5,8 - 7 - tousek / E_GSM-420-RS868_00 / 07. 05. 2018...
- Page 8 Saving / deleting telephone numbers is also possible by means of a call (see point 3a) Note • The serial number of the transmitters is located on the label close to the battery. e.g. - 8 - tousek / E_GSM-420-RS868_00 / 07. 05. 2018...
- Page 9 SMS text for input IN 1, 2: pass,TEXTy,txt pass: password (max. 5 digits) txt: text that is assigned to input y (max. 127 digits) e.g. 12345,TEXT1,text for input 1 - 9 - tousek / E_GSM-420-RS868_00 / 07. 05. 2018...
- Page 10 L-GSM • for teaching-in / deleting of tranmitter channels there are 2 buttons (P1, P2) and two LED´s (L1, L2) on the board of GSM 420-RS 868. Please follow the following instructions for execution of the desired functions. Teach-in of transmitter channels...
- Page 11 - 11 - tousek / E_GSM-420-RS868_00 / 07. 05. 2018...
- Page 12 Tel. +43/ 1/ 667 36 01 Fax +43/ 1/ 667 89 23 info@tousek.at Tousek GmbH Germany D-83395 Freilassing Traunsteiner Straße 12 Tel. +49/ 8654/ 77 66-0 Fax +49/ 8654/ 57 196 info@tousek.de Tousek Benelux NV BE-3930 Hamont - Achel Buitenheide 2A/ 1 Tel. +32/ 11/ 91 61 60 Fax +32/ 11/ 96 87 05 your service partner: info@tousek.nl Tousek Sp. z o.o. Poland PL 43-190 Mikołów (k/Katowic) Gliwicka 67 Tel. +48/ 32/ 738 53 65 Fax +48/ 32/ 738 53 66 info@tousek.pl Tousek s.r.o. Czech Republic CZ-130 00 Praha 3 Jagellonská 9 Tel. +420/ 2/ 2209 0980 Fax +420/ 2/ 2209 0989 info@tousek.cz tousek We reserve the right to change dimensions and/or technical specifications with- E_GSM-420-RS868_00 out prior notice. Claims resulting from misprints or errors cannot be accepted.
