INSTRUCTION MANUAL
BC9740
24V DC Automatic Battery Charger
ENTER
PREV
MENU
NEXT
POWER
BC 9740
amperes
CHARGING
FAULT
AUTOMATIC BATTERY CHARGER
Thank you
for choosing another quality product from Amperes Electronics.
We are proud to introduce the all new innovative Battery Charger which had been designed to meet the demanding
requirement of installers and users alike.
The distinctive features as compared to its predecessor are the reduced height for rack space saving, various protective
circuitries to prolong the battery life span and the charger itself and the new communication feature which enables remote
monitoring by Amperes PMX II Software through LAN.
We invite you to experience this innovative product which we developed by taking challenges into reality. You shall be
assured of quality and performance in years to come.
VER 2 / 2016
