INSTRUCTIONS
INSTRUCTIONS
- Main Wing
- Body
- Tail Wing
FAQ'S
FAQ'S
- Glider flies left/right, what should i do?
- Glider flies down, what should I do?
- Glider flies up and stalls in the air, what
should I do?
HOW TO / TIPS
HOW TO / TIPS
- How to Throw
- How to Tune Green Weights
- TIPS
- Key Assembly Check
- Tune Weights
CONTACT US
CONTACT US
- Email Link
Advertisement
Related Manuals for Brainstorm X-Glider
Summary of Contents for Brainstorm X-Glider
- Page 1 INSTRUCTIONS INSTRUCTIONS HOW TO / TIPS HOW TO / TIPS - Main Wing - How to Throw - Body - How to Tune Green Weights - Tail Wing - TIPS - Key Assembly Check - Tune Weights FAQ’S FAQ’S CONTACT US CONTACT US - Glider flies left/right, what should i do? - Email Link...
