Summary of Contents for Advent CMOS PC Camera
-
Page 2: Table Of Contents
Contents Introduction………………………………………..2 System Requirements……………………………2 Package Contents………………………………..3 PC Camera Introduction…………………………3 Set up PC Camera……………………………….4 Auto Focusing and Snapshot……………………4-5 Software Installation Arcsoft VideoImpression 2.0………………….6-7 Snapshot by VideoImpression 2.0……………...8-9 Live Video Playing……………..…………………10-11 Camera Specifications……………………………12... -
Page 3: Introduction
Introduction Welcome to the world of digital imaging. The following information will help you to use your camera to its full capabilities. For viewing pictures or video, camera must be connected to your personal computer. This camera is support Microsoft Video Class and plug & play directly without driver. -
Page 4: Package Contents
Package Contents PC camera CD-disc Installation Guide PC Camera Introduction... -
Page 5: Set Up Pc Camera
Set up PC camera You may mount the PC camera to your laptop or stand on the desk. Plug the PC camera into the USB port of PC or laptop properly. Auto Focusing and Snapshot 1. Click “My Computer” 2. Click “ USB Video Device” from Scanners and Camera. - Page 6 3. The focus will adjust automatically according to the subject moving. 4. Click “Take a new picture” or push shutter button for snapshot.
-
Page 7: Software Installation
Software Installation AcrSoft VideoImpression 2.0 1. Turn on the computer and insert CD installation Disc into your CD-ROM drive. Select and click “ArcSoft VideoImpression2.0” 2. Choose Setup Language 3. Click “Next” 4. Click “Yes”... - Page 8 5. Click “Next” 6. Click “Next” 7. Click “Finish”...
-
Page 9: Snapshot By Videoimpression 2.0
Snapshot by AcrSoft VideoImpression2.0 1. Click on the “VideoImpression 2.0” icon on the desktop. 2. Click “Create a New Slide Show” 3. Click “Scan Image” 4. Select source “WIA-USB Video Device”... - Page 10 5. Click “Capture” for snapshot. 6. Click “Select All” and then click “Get Picture”. 7. The pictures are saved.
-
Page 11: Live Video Playing
Live Video Playing AcrSoft VideoImpression 2.0 1. Click on the “VideoImpression 2.0” icon on the desktop. 2. Click “Create a New Video” 3. Click “Capture From Device”... - Page 12 4. Click “Record”, save video name and then click “Stop”. 5. Click “Done” to finish. Now you can play the video.
-
Page 13: Camera Specifications
Camera Specification Image Sensor 1280x1024 pixels, CMOS Lens Specification F2.8, f=4.02mm, Auto Focus Lens White Balance Auto Auto Exposure Frame Rate 1280x1024 pixels @ 8~10fps 640x480 pixels @ 30fps Focus Range Auto focus, 7cm to infinity Depth of Field 50cm to infinity USB2.0 PC Interface Video Format... - Page 14 This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product.
