Quick Start Guide
Smart Battery Switch (SBS) HW Version 3
Product Safety Warnings
The Smart Battery Switch (SBS) is only intended to be used as an engineering demon-
„
strator. It is not intended for extensive use or to be re-used in a product or system that is
sold to consumers.
The SBS is intended to be used by electrical engineers who are experts in the field of
„
high current design. If you are not qualified, seek the help of an expert before using the
demonstrator.
Questions about the SBS should be directed to Infineon Application Engineering.
„
The cable, cable lug, washer and nut used to connect to the bolt mounted onto the SBS
„
demonstrator's circuit board must all be made of high current-capable metals which will
not experience a significant temperature rise while conducting the current.
Battery Camping compliant to IEC 60095-2_Ed.4 (2009)
„
The cable lug must be mounted directly to the bolt (torque 6Nm ±1Nm).
„
Keep the current below 1800 A. The time a current may be applied is limited by
„
the temperature rise.
Don't exceed 1 Joule of switching energy.
„
Switching to high currents or to high switch off energy may destroy the switch and
„
the test setup and end up in fire.
Content
„
„
Top
Bottom
Advertisement
Table of Contents
Related Manuals for Infineon SBS
Summary of Contents for Infineon SBS
- Page 1 It is not intended for extensive use or to be re-used in a product or system that is sold to consumers. The SBS is intended to be used by electrical engineers who are experts in the field of „...
- Page 2 Schematic Battery Positive Q1 … Q6 Terminal Drain … R IN414SW-13-F 100 Ω/150 V/1% Voltage max. 15 V 100 Ω/150 V/1% Gate 560 Ω/ 150 V/ 10 nF/ 10 nF/ 10 kΩ/ 10 kΩ/ 100 V/ 100 V/ 150 V/ 150 V/ Supply Voltage max.
- Page 3 Designator SmartBatterySwitch_Main_SW_V30.SchDoc Output Terminal Power ource Clamp INT_VBB 680 Ω/ 120 kΩ/ 150 V/ 150 V/ 120 kΩ/ 120 kΩ/150 V/1% 150 V/ Q7 Active Freewheeling IPLU300N04S4-R7 g_freewh 100 Ω/150 V/1% LT6015IS5 Q8 Wrong Supply 120 kΩ/ Polarity Voltage max. = 50 V 150 V/ Protection IPLU300N04S4-R7...
- Page 4 Reset latched N.C. = Not connected = Connected to InGND = Pull down In2 to InGND and release again Thermal Image after 10 minutes and 250A. www.infineon.com/smart-battery-switch www.infineon.com/mosfet Order Number: DEMO_BATT_SW_V3 SP001332050 © 2015 Infineon Technologies AG. All Rights Reserved.
