SmartBidet SB-2600 Quick Installation Manual

SB-2600
Quick Installation Guide

Toilet size (Elongated)

1
The toilet dimensions must be within those shown
below. Do not install this unit on a toilet that does
not meet these dimensional requirements.
2

Remove your existing toilet seat, lid, and accessories and store them away.

3

How to mount the base plate

Place the base plate and bolt cases over each
toilet mounting hole. Insert the mounting bolts
through the base plate and toilet mounting holes.
Screw in the nuts onto the mounting bolts.
Base plate
Bolt case
1.
Mounting bolt
Nut

Bidet Dimensions

This model fits both elongated and round toilets.
There may be a slight overhang for certain
round toilets.
8.1"
14.9"
11.4"
14.5"
4

How to attach and detach the unit

6.4"
20.4"
Slide the unit until it
clicks into the base plate.
Lift the unit up
and forward.
