Summary of Contents for Circutor Wi Beee

Page 1 SAVING IS SIMPLE WITH WI-BEEE SMART PLUGGING [ENG]...
Page 2: Table Of Contents
Introduction, 3 Overview, 4 Instructions, 6 Technical Specifications, 10 Safety Precautions, 10 External Connections, 11 LEDs, 12 Wi-beee Set-up on Breaker Installation, 12 Technical Features, 13...
Page 3: Introduction
1. Introduction Wi-beee is a new method for electrical data acquisition, to ease your decision making when understanding the use of electrical energy. Based on the patented DINZE- RO system, our “clip-on” technology consists of easily clipping the device onto the wire or simply at the top of an MCB and, once powered-up, it will start converting the measured parameters into info, by sending them via wireless.
Page 4: Overview
Electrical Panel Wi-beee...
Page 5 Laptop Smartphone Tablet...
Page 6: Instructions
Before using Wi-beee ensure that the con- ditions are the appropriate for working, and that the protection equipment is the adequate. 1. Remove the protective panel. 2. Install the device, be careful with the neutral terminal (N) this one must correspond with the neutral cable of your ins- tallation (your device could be damaged if a bad installation is...
Page 7 6. Verify that the led red is on and blink. 7. After a few seconds, the led blue turns blinking. SYMBOLS Double Attention! Isolation Refer to manual Do not apply around or remove from hazar- dous live conductors.
Page 8 Wibeee. 2. You can get access to the net configuration and instantane- ous measures through your browser. 2. Open the app http://192.168.1.150 Wibeee CIRCUTOR User: user Password: user 3. Follow the steps indica- ted by the app.
Page 9 1. Now you have access 2. Or you can get access to analysis your data to analysis your data, trough through the website: Wibeee CIRCUTOR. http://wibeee.circutor.com...
Page 10: Technical Specifications
EN 301 489-17 V2.2.1 Prior to use the Wi-beee for the first time, read the following carefully: 1. Circutor does no take responsibility for damage or physical injury that may be caused as a result of improper installa- tion or use of equipment.
Page 11: External Connections
4. Do not use the Wi-beee if there any reason to think that its no operating properly or that it is faulty. 5. For measuring in uninsulated conductor use the appro- priate and necessary personal protection equipment. 2. External Connections 1.
Page 12: Leds
3. LEDs Red LED Blinking Powered device Blue LED, it indicates the connection status Slow blinking (1s) No link to a Wi-Fi network Fast blinking( <1s) Link to a Wi-Fi network Fixed on Sending data over the network 4.Wi-beee Set-up on Breaker Installation Three-phase Single-phase...
Page 13: Technical Features
5. Technical Features 5.1 Electrical Features Voltage Range 85... 265V~ Frequency Range 50 Hz - 60 Hz Consumption of equipment 1.5 VA ... 4.5 VA 5.2 Electrical Safety Isolation Double Isolation Protection Class II IEC/EN 61010-1:2010 5.3 Measurements range Nominal range current 500mA ...
Page 14 5.5 Variations in Range of Use Quantity of influence Range of influence Typical Máx. Temperature -10 °C ... +45 °C 0,3 % Relative humidity 10 % 90 % 0,3 % Crosstalk (current) 0,9 % External stray fiel (current) 1 % Conductor position 2 % 3 % Adjust Full Scale 0,2 % 0,4 % Distance between wire and 2,5%/0.1mm...
Page 15 5.8 Dimensions Single-phase 50,5 Three-phase 50,5...
Page 16 SMART PLUGGING...
Page 17 CIRCUTOR SAT: 902 449 459 (SPAIN) / (+34) 937 452 919 ( Out od Spain) Vial Sant Jordi s/n, 08232 Viladecavalls (Barcelona) - Spain Tel: (+34) 93 745 29 00 - Fax: (+34) 93 745 29 14 sat@circutor.es www.circutor.com...
