  • Page 1 Renogy MTS-CE Cable Entry Housing 2775 E Philadelphia St, Ontario, CA 91761 1-800-330-8678 Version: 1.0...
  • Page 2: Important Safety Instructions

    Important Safety Instructions Please save these instructions. WARNING: Indicates a potentially dangerous condition. Use extreme caution when performing this task. CAUTION: Indicates a critical procedure for safe and proper operation of the system. NOTE: Indicates a procedure or function that is important to the safe and proper operation of the system.
  • Page 3 Table of Contents General Information ..............................4 Identification of Components ..........................4 Installation ..................................4 Technical Specifications .............................9 Dimensions ...................................9...
  • Page 4: General Information

    The Renogy Cable Entry Housing (MTS-CE) is a UV-resistant, waterproof, and ABS plastic membrane designed to provide the solution for cable entry through roofs. With its dual cable entry, the MTS-CE easily passes solar cables and can be conveniently mounted on virtually any roof surface.
  • Page 5 WARNING: Assembly adhesives contain hazardous chemicals that can be detrimental to one’s health. Make sure to abide by the manufacturer’s handling and care when using assembly adhesives. 1. Set Up Mounting Area a. On the flat surface, mark the area by which the wire will feed through b.
  • Page 7 2. Apply Adhesive to the cable entry gland and install on flat surface NOTE: Always mark out where the component will be located on the flat surface before proceeding to apply adhesive a. Clean the surface that will be bonded to ensure maximum bonding potential b.
  • Page 8 3. Tighten cable gland at desired wire length a. Upon desired wire length, tighten individual cable glands by rotating clockwise b. Rotate until wire feed is no longer mobile through the gland. c. Repeat for the other cable gland...
  • Page 9: Technical Specifications

    4.7 x 3.9 x 2.0 in Recommended Adhesive Sikaflex 252 or alike Cable Gland Diameter Range 6mm – 12mm Dimensions Note: The following drawings utilize inches as their dimension units. Renogy reserves the right to change the contents of this manual without notice. Revision: 9/14/2017...
