Summary of Contents for AER Domino 3

  • Page 1 user manual Domino...

  • Page 2: Table Of Contents

    3.2 Rear Side 4. Starting up 4.1 Cabling and Switching-on 4.2 Level Adjustment 5. Functional characteristics 5.1 Mute 5.2 Equalization 5.3 Effects 5.4 Phantom-Power 5.5 Stereo-Simulation 5.6 Insert-Loop 5.7 Connecting AER-amps via Insert-Loop 6. Technical Specifications 12/13 7. Circuit Diagram...

  • Page 3: Introduction

    Domino 3 a 2x100-watt system that combines the excellent tone of the Compact with increased power and higher efficiency. The Domino 3 is – of course – dynamically controlled and equipped with two parallel power-amplifiers, two 8“-twin-cone loudspeakers, 1“-neodym tweeter for...

  • Page 4: Safety Instructions

    2. Safety Instructions The following guidelines shall help minimize the risk of injury through fire or electric shock. The lightning flash with The exclamation point C AU T I O N the arrow head symbol within an equilateral RISK OF ELECTRIC SHOCK within an equilateral triangle is intended to DO NOT OPEN...

  • Page 5: Controls And Connections

    3. Controls and Connections 3.1 Front Side input signalinput, Combijacket for 6,3 mm mono or XLR plugs input sensitivity switch – attenuator deactivated, activated line/mic signal source selector switch of the combo socket: line (only via jackplug) for instruments (pickup) and other line level sources mic (only via XLR-connector) for microphones gain input level control...

  • Page 6: Rear Side

    Combined mains switch with mains socket and fuse holder. (s. Technical Data Mains Fuse) 7) insert: insert point, 6,3 mm stereo-jack-plug, tip = send, ring = return, for serial looping of eff ect-devices or for connecting AER-amps with link-feature. (see para. 5.6, page 11)

  • Page 7: Starting Up

    4. Starting up The clip-LED indicates an overload. A short fl icker is of no danger to AER devices. During operation a short 4.1 Cabling and switching on fl icker can be accepted, to be on the safe side you...

  • Page 8: Functional Characteristics

    Furthermore an additional eff ects unit (external eff ect) may be connected to the Domino 3. For this purpose use the send and return sockets on the rear side of the amplifi er (send goes to input, return to Note: the output of the external eff ects device).

  • Page 9: Phantom-Power

    (unbalanced signal) that were fitted afterwards generated. with an XLR connector. On stage (Domino 3 as monitor) the sound remains Audio devices with a balanced XLR output (e.g. unchanged.. DI-boxes, effects devices, instrument preamps with a DI output etc.) which are not protected against...

  • Page 10: Insert-Loop

    1. use as additional line-output 2. use as additional line-input 3. link between two or more AER-amps with insert- feature (AG8, Domino, Compact ClassicPro) For each of these applications you’ll need the appropriate cable connection, e.g. use as line-output: stereo-jack (tip and ring = hot, sleeve = ground) to mono-jack.

  • Page 11: Connecting Aer-Amps Via Insert-Loop

    5.7 Example for the linking of AER-amps via the insert connection input middle treble eff. send gain bass middle treble eff. send mute line/mic clip colour channel one channel two PA-System PA-System effect 2 middle treble eff. send select return master stereo sim.

  • Page 12: Technical Specifications

    6. Technical Specifications Domino 3, part 1 Inputs (notes 1, 2) max. 2 x 100 mW / 32 ohms Input sensitivity for Inputs, channels Combo socket, XLR + jack ¼” (6.35 mm) 2 x 50 mW / 32 ohms: 1 – 4...
  • Page 13 6. Technical Specifications Domino 3, part 2 External effect 1. Input sensitivity Parallel effect loop (see send and return) Input sensitivities refer to 2 x 85 watts into 4 ohms, full gain and master settings, neutral tone control settings, Power and 1 kHz sine-wave test signal.

  • Page 14: Circuit Diagram

    7. Circuit diagram Domino 3...
  • Page 15 notes...
  • Page 16 DOMINO 3-150225-GB...
