Summary of Contents for HORN LHD6001+

Page 1 LHD6001+...
Page 3 Hybrid alarm system INSTALLATION MANUAL...
Page 4: Table Of Contents
CONTENT Installation Attention General System Installation Info…t Basic Requirement Packing List Installation of control panel System Installation Diagram Tamper switch connection power connection 11 AC Operation Backup power connection Indicator signification Installation of keypad Buzzer signification 13 Siren output Siren signification PGM Output Term Definition AUX power output...
Page 5: General
GENERAL INSTALLATION INFO user Name User Address Installer Installation Company Installation Date Tel of Installation Company of Installation Company Center Stations Address Tel of Center Stations 1 Tel of Center Stations 2 Tel of Control panel Note: Please make sure all the above information filled in and confirmed by the installer or the installation company. Packing list The components of the product are packed in a box as followed.
Page 6 GENERAL N.O. detector Controlled element 绿色绿色红色红色...
Page 7: Term Definition
Oper LED Indication Flash Slowly Flash Quickly Low battery Power AC Power lose Normal Alarm away (Red) Arm Stay Arm Away Disarm Panel/Keypad tamper alarm /Module lose Disarm (Green) Disarm Prog programming Programming Keypad lose Alarming Zone 1～16 Zone Invalid Zone activated GPRS Not used...
Page 8: Main Features And Functions
Oper 24-hour zone: No matter armed or disarmed, it is in effective detecting status. It is usually used in fire alarm, plunder alarm and other emergent alarm which can be cancelled only by password holder. Center Monitoring Station(CMS):Alarm message will be sent to CMS via telephone line which can take action accordingly after it received the alarm message.
Page 9 Oper Zone type and definitions Zone Entry delay Flash & Sound Installation place Arm way Arm stay Exti delay Type number Disarm type Alarm or detector Entry/Exit zone Ineffective Effective Effective Gate Active zone Ineffective Effective Ineffective Indoor Balcony window Perimeter zone Ineffective Effective...
Page 10: Remote Controller
Oper Remote controller 1. Wireless remote controller have 4 keys which can achieve operations of arm away/stay, disarm and panic alarm without user password. Press keys on the remote controller towards the control panel to perform corresponding operations. Press the panic button for 2 seconds to trigger the alarm. Arm away Disarm Arm stay...
Page 12: Programming
Oper Siren Signification Siren can be set to sound twice when arm way or disarm the system, and once when disarm, four times when operation failed. When no keypad is connected to the system, when arm or disarm this system, siren will sound no matter siren is set on or off. Keypad locked and unlocked If the password is input wrong for 5 times, the keypad will be locked, then the panel couldn’be operated except the operations which don't need password.
Page 13 Oper 4. Disarm the panic alarm: Press the disarm button, duress code and # to disarm when panic alarm happened. Duress code is produced according to mater code or user's code. For example, if master code is 8889, the duress code will be 8880, and 9990 if the master code is 9999. When disarm the system, after inputting this duress code, the panel will call to alarm, but the siren will not siren even if it is set on.
Page 14 Oper Telephone alarm When there is alarm, the master controller dials the number, and the user will hear “Di Di Di”, and sounds after 2s, the sound will repeat for 5 times. And after 2s, the master controller hangs up. Before the hang up, user can control the panel by telephone buttons.
Page 15: Ac Power Connection
SYSTEM INSTALLATION Notice before usage Before installation, please read the requirements as below: Disconnect the powers supply while open the cabinet. Don't disassemble the control panel and the keypad panel randomly to avoid accidents and damages. Please connect AC power to the control panel after ensuring the installation correct completely. Please use standby power (accumulator) to ensure the control panel can work normally when electric network fails.
Page 16 SYSTEM INSTALLATION Back-up battery connection The control panel uses 12V/7.0Ah sealed lead-acid rechargeable battery as standby power. There is a red and a black power cords with plugs in the master controller for standby power connection. Connect the red power cord to the positive terminal of standby power Battery and the black power cord to the negative terminal of standby power.
Page 17: Anti-Tamper Switch
SYSTEM INSTALLATION Bell output terminal(Bell+, Bell-) Bell (BELL) normial voltage： AC powered，output voltage will be12V，and about12v for battery powered, with protected by fuse F5(1A) fo short circuited. nnect the two power lines of the bell to "BELL+" and "BELL-" to the terminals i the control panel.
Page 18: Telephone Line Connection
SYSTEM INSTALLATION Telephone line connection Connect telephone line to terminal “ L_IN 1 ”, “ L_IN2 as what in the right diagram. ” Connect telephone or facsimile machine to “ L_OUT1 ”, “ L_OUT2 ” Telephone line interface of the master controller, which can ensure no effect on telephone or facsimilemachine.
Page 19: Parameter Setting
PROGRAMMING Parameter setting Press “ PROG →Installer code→ ” “ # ” to set the system, PROG LED will flash slowly, and then the users can program the telephone numbers, parameters etc. by inputting commands. Press “ # ” to confirm the command. If buzzer beep twice, it means it is programmed wrongly and couldn’t be recognized by the system.
Page 20 PROGRAMMING referring Setting Operation on keypad Description Default page X=0 means turning off siren. Turning on/ off siren X=1: turning on siren → 24 → X → Y→# Turning on/ off detecting siren Y=0 means turning off detecting siren, Y=1: tuning on detecting siren Sending installing message X=0~1.
Page 21 PROGRAMMING referring Setting Operation on keypad Description Default page X=0 means not sending a wired zone recover message; X=1:immediately sending a message after a wired zone According to a condition, recovers; X=2: sending a message panel sends a wired zone →...
Page 22 PROGRAMMING referring Setting Operation on keypad Description Default page XX(XX=01~16):zone's series number. Y=0, means zone XX is effected by panel's arm or disarm; Y=1, means zone XX is effected by panel's arm; Setting isolated zone → 68 → XX → Y→ # Y=2, means zone XX is effected by panel's disarm;...
Page 23 PROGRAMMING referring Setting Operation on keypad Description Default page X= 0~1. Protocol of wireless → 90 → X→ # 0 means protocol is PT2262. detectors 1: EV1527 million code. All zones bypass → 910 → # Cancelling all zones bypass →...
Page 24 PROGRAMMING Message type reported to CMS (comnand: 12XYY) YY values and send the contents of the relationship in the following table, X is not sending the content, √ sending the content. For example 05, the corresponding zone bypass and alarm beat √, Zone Bypass report at this time and alarm information, additional information is not sent.
Page 25 PROGRAMMING User’s ID (Command: 20X····X) Note: The ID should be set with 8 digit numbers when it connected to CMS from Longhorn. Edit user’s password (Command: 21XYYYY) If user's password is 8889, then the duress will be 8880, and it will be 9990 when user's password is 9999. To restore the defaults of user's password or installer password, it can jumper the cap of RST on the PCB boards with power disconnected in the case the user forgot the passwords.
Page 26 PROGRAMMING Ring attempts to CMS thru a free of charge of telephone line(command:34X) The calling attempts for CMS number and user’s phone number should be set the same, or trouble will be cause. Setting period of sending the same alarm by only one wired zone (command:38XX) If it will not alarm after the time set, please check the setting via command 46 whether effect the alarm.
Page 27 PROGRAMMING Relay output option (Command: 42XX) Relay Relay description Relay not used. AC lose low battery 01～16 GPRS disconnected. 17～18 disconnected. 31～34 the zones with the numbers set exit/entry zone alarm 51～56 output as（XX-60）zones active zone alarm 61～76 exit delay Perimeter zone alarm ntry delay panic alarm...
Page 28 PROGRAMMING Below list is the different meaning when Z is settled with 0 or 1 meaning Either be disarmed or armed(when Y is When this zone is triggered, disarm or arm will be acted. set with 1,2,3 or 6) Can be disarmed and armed( w hen Y is When this zone is triggered, the system will be disarmed, set with...
Page 29 PROGRAMMING Period of sending 1 message (command: 50XYY) First reporting period to CMS: Period Parameter Period s me with testing report sendingperiod When Mode 2(Double CMS set to receive message ) is set (command 132), the CMS 2 is invalid. 。 Period of sending messages to CMS1 &...
Page 30 APPENDIX Protocol Code Between the panel and CMS there are two format codes: ADEMCO 4+1、ADEMCO Contact ID. The following table defines the Event Codes used in this protocol: Code Event Code Event Medical Alarm Sounder Trouble Loss of Keypad trouble Fire Alarm Keypad temper Alarm Duress Alarm...
Page 31: Wireless Detector Code
APPENDIX ADEMCO 4+1 Event Code Table: Code Event Fire Alarm, including Fire, Gas, Panic zone Duress alarm, including Duress zone Intruder alarm, including Enter / Exit, Active, perimeter, Tamper zone Disarm AC loss Low battery Periodic test report Wireless Detector Code The detector used in EV1527 million code has Hex digits, the last four digits definition: Low battery Low battery recover...
Page 32: Trouble Shooting
APPENDIX Trouble shooting Trouble Possible causes Solution Zone is bypassed. Cancel the bypass. Zone is set as 1,2,3(Entry/exit, active, peremeter) which will not Change the zone type to make it alarming when disarm. alarm when triggered. When arm stay this system, the active Change the zone type to make it alarming when arm stay this system.
Page 33: Specification
APPENDIX Specification Panel 274mm×264mm×86mm Dimension： voltage： AC 220V Stand-by current： ≤80mA －10°C～＋55°C Working temperature： Zone trigger time： 500ms Keypad Dimension： 165mm×121mm×28mm voltage： AC 1 ≤50mA Stand-by current：－10°C～＋55°C Working temperature Zone type record W i r e l e s s z o n e s Zone NO.
