Juvo COMFORT Series Instructions

COMFORT SERIES
CONTENTS
Carefully remove contents from box and inspect them for any damage
that may have resulted from shipping, or missing parts.

Parts Inside Box:

• Qty. 1 Comfort Series Bath Safety Chair Seat with Foam Padding
• Qty. 1 Padded Back-Rest
• Qty. 2 U-Shaped Leg Braces. They are numbered 1 and 2
• Qty. 2 Back-Rest Support Bars
• Qty. 4 Adjustable Legs with Rubber Feet
• Qty. 4 Butterfly Bolts with Washers – Long
• Qty. 1 Butterfly Bolt with Washer – Medium
• Qty. 2 Butterfly Bolts with Washers - Short
IMPORTANT NOTE: The two U-Shaped Leg Braces are slightly different.
It is important that you follow the instructions and use the correct U-Shaped
Leg Brace in proper sequence. The U-Shaped Leg Braces are numbered with
a sticker for this purpose.

ASSEMBLY INSTRUCTIONS

1. Turn Seat Upside Down
• Place seat on flat surface i.e. table or floor, upside down so underside is facing you
2. Connect First U-Shaped Leg Brace
• Lay U-Shaped Leg Brace #1 across underside of seat. Make sure it is resting
in recessed channel, marked #1, such that the flat portion of the tubing is
aligned with the direction of the channel. IMPORTANT. (Refer to image 2
and 3)
3. Connect Second U-Shaped Leg Brace
• Lay U-Shaped Leg Brace #2 on top of, across U-Shaped Leg Brace #1,
in recessed channel marked #2. (Refer to image 4)
• Fasten U-Shaped Leg Braces #1 and #2 to underside of seat with Butterfly Bolt
with Washer starting in the center first. Use Butterfly Bolt with Washer – Medium
to fasten center position first. Do not over tighten
4. Connect Back-Rest Support Bars and U-Shaped Leg Braces to Underside of Seat
• Lay one Back-Rest Support Bar across the U-Shaped Leg Braces such that the two
holes of the Back-Rest Support Bar align with the two holes of the U-Shaped Leg
Braces, (refer to image 5). Make sure that the Back-Rest Support Bar is facing up,
from the back side of the chair. IMPORTANT
• Fasten Back-Rest Support Bar and U-Shaped Leg Brace to underside of chair with
two Butterfly Bolts with Washers – Long. (Refer to image 6). Do not overtighten.
• Repeat process of fastening Back-Rest Support Bar and U-Shaped Leg Brace
to underside of chair – with second Back-Rest Support Bar. (Refer to image 7).
Juvo Products. LLC. • 111 North Avenue, Suite 205 • Barrington, IL 60010 • 847.381.3030 • info@juvoproducts.com
INSTRUCTIONS:
Bath Safety Chair
TM
Model: BSC01
1
2
INCORRECT
3
CORRECT
4
