Audiomusic Systems Marktinez MTU 50 User Manual

Thank you for purchasing stomp chromatic tuner MTU 50
7
3
Tuning Mode : Chromatic
Tuning Range : A0 (27.5Hz) - C8 (4186.00Hz)
Tuning Way : The signal input must be connected
Tuning Tolerance: ± 0.5
Power :6F22 battery, or 9V DC
Dimension :125mm×73.8mm×40mm
Weight 353g :
Attachment Manual, Battery :
. Install a battery, or link a AC-DC 9V connector. Please pay much attention to polarity.
1
2 Link the input, and the tuner automatically turns on. When the tuner is on, the singal can't get .
through the output. When turn off the tuner by pressing the ON / OFF button, the signal will pass
through the output.
3 Play a single note from your instrument, the note name will appear in the tuner screen. The screen .
color will change, and the tuning needle will move.
The screen turns green, the center needle appears, both triangles besides the note name appear: in tune.
The screen is white, the left tuning needles appear, the triangle at the left side of the note name appears:
flat note
The screen is white, the right tuning needles apprear, the triangle at the right side of the note name
appears: sharp note.
4 When disconnect the Input, the tuner will turn off automatically. .
MTU 50
Metal Stomp Chromatic Tuner
Operation and Function
6
b
a
4
2
Specification
How to Use
5
1. ON / OFF
2. Screen: a. Note Name
b. Tuning Meter and Calibration
3. Input
4. Output
5. 9V DC Input
6. 9V DC Output
7. Battery Compartment
1
www.audiomusic.es
User manual
