Saddlebrook BarnCams Metal/Stone BarnCam Manual

Saddlebrook BarnCams Metal/Stone BarnCam Manual

Advertisement

Quick Links

Metal/Stone
BarnCam
Instructions
Important Safety Precautions
- To prevent fire or shock hazard, do not expose this product to rain or
water. Do not use near a bath tub, wash bowl, sink, or laundry tub; do
not use in a wet basement or in or around a swimming pool.
- To avoid electrical shock, do not open the case of this product.
- Operate this product using only the power supply included with it.
- Do not overload electrical outlets or extension cords as this can result
in fire or electric shock.
- Refer servicing to qualified personnel only.
CAUTION:
Changes or modifications not expressly approved by the seller could
void the user's warranty and create an extreme hazard.
NOTE:
This equipment has been tested and found to comply with the limits
for Class B digital device, pursuant to part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
-
Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-
Consult the seller/dealer or an experienced radio/TV technician
for help.

Advertisement

loading

Summary of Contents for Saddlebrook BarnCams Metal/Stone BarnCam

  • Page 1 Important Safety Precautions - To prevent fire or shock hazard, do not expose this product to rain or water. Do not use near a bath tub, wash bowl, sink, or laundry tub; do not use in a wet basement or in or around a swimming pool. - To avoid electrical shock, do not open the case of this product.
  • Page 2 Camera Setup Instructions Step One: Mount the camera in a good location to view your animals. You can adjust the angle of the camera to position the camera into place. Run the cables from the camera to the outside of the barn where the transmitter will be mounted.
  • Page 3: Setup Tips

    Setup Tips 1.) Make sure you’ve ordered the right system for your situation. A wooden barn covered in metal needs the metal barn system. 2.) Make sure you have set it up completely in your house first. All of our systems are tested before they are shipped. 3.) If it does not work in the house, you should check to make sure your TV is set up correctly.
  • Page 4: Troubleshooting

    TROUBLE SHOOTING Cause and remedies Problems Receiver Camera No power or AC adaptor not AC adaptor not plugged in plugged in picture/sound Improper TV or Monitor connection Poor Improper antenna Antenna reception direction direction Improper channel switching 1. POWER ON/OFF 6.
  • Page 5: Wireless Operation

    Operation With TV 1. If your TV has A/V jacks, connect one set of A/V cables to the TV's A/V jacks and to the A/V jacks on the receiver. Be sure the yellow, red and white plugs match the yellow, red and white jacks on both the TV and the receiver.
  • Page 6 Operation With TV & VCR Operation With Monitor This setup enables you to record 1. Connect one set of A/V cables to the monitor's A/V transmitted audio jacks and to the A/V jacks on the receiver. and video on your remote VCR and 2.
  • Page 7: Warranty

    Please pack unit carefully and safely and send it prepaid by receiver are turned on. insured parcel post to: Saddlebrook BarnCams LLC N76 W36096 Saddlebrook Lane Oconomowoc, WI 53066 USA Please include a note explaining how the unit is defective.
  • Page 8 If you have any questions or need additional help please e-mail: support@BarnCams.com or call: (920)474-7776 Saddlebrook BarnCams LLC N76 W36096 Saddlebrook Lane Oconomowoc, WI 53066...
