ASG OM Series Manual

OM-R Manual
• Read these instructions for the proper use of this machine.
• After having read these instructions, keep them in a convenient place so you or
the operator can refer to them whenever necessary.
ASG, Division of Jergens, Inc.
S. Waterloo Road | Cleveland, OH
15700 44110-3898
| Phone: ( | Fax: ( | Email: asginfo@asg-jergens.com | Web: www.asg-jergens.com
888) 486-6163 216) 481-4519

Table of Contents

Overview .................................................................................................................1
Before Use ...............................................................................................................1
Operating Precautions .............................................................................................2
Names of Parts .........................................................................................................5
Adjustments and Checks Before Use ........................................................................7
Maintenance ..........................................................................................................15
Parts Adjustments and Replacements ....................................................................15
Application with Robotic System ...........................................................................25
Miscellaneous ........................................................................................................27
Troubleshooting .....................................................................................................29
Specifications .........................................................................................................31
External Dimensions ..............................................................................................32
Warranty ................................................................................................................33

Overview

Thank you very much for selecting the OM Series Automatic Screw Feeder This machine
can line up screws (Type M2 - M6) and supplies them one by one to help the efficiency
of screw fastening work. Different sizes of screws can be used by changing the rail and
parts of the escaper assembly. It can be used wherever there is a power source for an
AC adapter. Note: Only steel screws may be used with this machine. Stainless steel or
plastic screws cannot be used.

Before Use

Please check for the following accessories before operating the machine:
•
(1) Instruction Manual
•
(1) AC Adapter
•
(1) Hexagonal Wrench
•
(1) Screwdriver
1
