Summary of Contents for RIC RG90
- Page 2 Tel: 714-545-5574 Fax: 714-754-0135 TRANSISTORS Q5, Q8: MPSA06. LAST REFERENCED DESIGNATION ON SCHEMATIC: TRANSISTOR Q6: MPSA56. R37, C15, D9, Q13, L1, P1, J1. SCHEMATIC, POWER AMP RG90, RG60, RB60 TRANSISTOR Q7: 2N5088. TRANSISTOR Q9: MPSU06. SCALE CHECKED BY DRAWN BY TRANSISTOR Q10: MPSU56.
