Installation & Start-Up Procedures
Two-Tank Combo Water
Softener & Filter
Congratulations!
You've selected our best-selling
water conditioning models for top
performance and economy.
Safety Zone Signature Series
water conditioning systems are
designed to provide years of
service with proper care and
maintenance.
Hopefully, this manual will be
beneficial and provide information
you need to install, start-up and
maintain your system.
To view our valve manuals visit
www.safetyzonewater.com
®2020 Safety Zone Water Systems, LLC
Single Tank Combo Water
Softener & Filter
Valve type
Valve sizes
Pipe fittings available
Regeneration method
Riser tube size
Drain line fitting
Brine line
Supply voltage
Supply frequency
Output voltage
Resin volume (cubic feet)
Resin type
Carbon type (Combo units)
KDF (Combo units)
Brine tank volume
Brine tank overflow prevention
By-pass valve
Water Softener
Specifications
Metered
1", 1.25", 1.5" and 2"
¾", 1", 1.25" and 1.5"
Down flow
1.05", 1.25", 1.5"and 2"
¾" male NPT
3/8" quick connect
120 V AC
60 Hz
12 V AC
1.0, 1.5, 2.0, 3.0, 4.0, 7.0 & 10
8% crosslinked
Catalytic coconut shell
KDF-55 foam cubes
200 lbs.
Included
Included
Advertisement
Table of Contents
Related Manuals for Safety Zone Signature Series
Summary of Contents for Safety Zone Signature Series
- Page 1 Carbon type (Combo units) Catalytic coconut shell maintain your system. KDF (Combo units) KDF-55 foam cubes Brine tank volume 200 lbs. To view our valve manuals visit Brine tank overflow prevention Included www.safetyzonewater.com By-pass valve Included ®2020 Safety Zone Water Systems, LLC...
- Page 2 Valve Programming Safety Zone Water® Signature Series electronic control valve The Safety Zone Signature Series valve is highly versatile, and can be programmed for water softeners and Combo softener / Filter systems. Valves are available in 1”, 1-1/4”, 1-1/2” and 2”...
- Page 3 Brine Well with Overflow fitting Brine tank components safety float and air check Brine tank set-up instructions: 1. Install one of the two caps to enclose the bottom of the brine well. 2. Remove overflow device to be able to connect brine well to side of the brine tank. 3.
- Page 4 Warranty Signature Series Safety Zone Water Systems come with a limited warranty. Five years for valves, and ten years for tanks. Resin, activated carbon and filter media come with a quality guarantee only. See warranty card or go to www.safetyzonewater.com...
