- Page 1 HT125KM, FA3TM, FA6TE FLANGE ALIGNMENT TOOLS Operator Instruction Manual info@equalizerinternational.com www.equalizerinternational.com INNOVATION IN ITS MOST FUNCTIONAL FORM...
-
Page 3: Table Of Contents
4.1 LATERAL MISALIGNMENT 4.2 ROTATIONAL (TWIST) MISALIGNMENT HT125KM 8-13 HAND ALIGNMENT TOOL 5.1 KIT COMPONENTS 5.2 HOW THE HT125KM WORKS 5.3 INSTALLATION AND OPERATION 9-10 5.4 EXAMINATION, MAINTENANCE AND STORAGE 5.5 PARTS LIST 5.6 WEIGHTS AND DIMENSIONS 5.7 RANGE OF APPLICATION... -
Page 4: Introduction
1. INTRODUCTION The Equalizer HT125KM, FA3TM and FA6TE are aids for use in normal maintenance and installation procedures, and enable the realignment of misaligned flanges within their respective working capacities. For example, all of the tools can be used to assist in the replacement of ring and other types of flange joint. -
Page 5: Safety Information
These instructions are only to cover the safe operation of THE EQUALIZER HT125KM, FA3TM AND FA6TE FLANGE ALIGNMENT TOOLS, during normal maintenance/installation operations. - Page 6 A CAUTION is used to indicate correct operating or maintenance procedures and practices to prevent damage to, or destruction of equipment or other property. A WARNING indicates a potential danger that requires correct procedures or practices to avoid personal injury. A DANGER is only used when your action or lack of action may cause serious injury or even death.
-
Page 7: Technical Data
3. TECHNICAL DATA Tool Description Aligning Force Hand 125 kg (275 lbs) HT125KM Alignment Tool Mechanical Advantage 5 to 1 Mechanical 3.3 T (33kN) FA3TM Fixed Flange and Rotational Alignment Tool from 50 ft/lbs (67.8 Nm) of torque Hydraulic 6 T (60 kN) -
Page 8: Flange Misalignment Determination Procedure
4. FLANGE MISALIGNMENT DETERMINATION PROCEDURE The tool being used must not be attached to a flanged joint prior to the misalignment procedure being carried out. 4.1 LATERAL MISALIGNMENT Slacken and remove every second bolt around the flange , continue with this until misalignment occurs. -
Page 9: Rotational (Twist) Misalignment
4.2 ROTATIONAL (TWIST) MISALIGNMENT If the outer circumference of the flanges are in alignment but the operator is unable to fit the bolt into any two corresponding bolt-holes then rotational misalignment may have occured. In this case the alignment tool can be attached to the most accessible point as misalignment occurs at all bolt-holes to the same degree. -
Page 10: Ht125Km Hand Alignment Tool
Product Code: HT125KGSTD 5.2 HOW THE HT125KM WORKS The HT125KM is secured to the lower of the two flanges by fully inserting the lift pin into the bolt-hole which is parallel with the bolt-hole on the opposite flange. This is where the misalignment is at its greatest point. -
Page 11: Installation And Operation
5.3 INSTALLATION AND OPERATION POINT OF MAX. MISALIGNMENT LIFT MODE: Carry out the Flange Misalignment Determination Procedure (see section 4) to determine the points of maximum misalignment. In this example the points of maximum misalignment are at the top and bottom of the joint. POINT OF MAX. - Page 12 Lift up on the handle and the HANDLE counter-balance will push down on the higher flange bringing the joint into alignment. PUSH MODE: By removing the handle from the lifting assembly and counter-balance, the handle can be re-inserted from the opposite side. Align the joint by pushing down on the handle.
-
Page 13: Examination, Maintenance And Storage
Any missing or damaged items are to be replaced as soon as possible and prior to the tool being used again • Store the HT125KM in a cool dry place and ensure all machined surfaces are greased • Grease all moving parts regularly •... -
Page 14: Parts List
5.5 PARTS LIST ITEM PART No. DESCRIPTION QUANTITY 201201-01 HANDLE SLEEVE-BLUE 01 each 200102-01 MAIN BAR 01 each 200901-02 BUTTERFLY NUT 01 set of 2 200202-01 LIFTING ASSEMBLY 01 each 200302-01 COUNTER-BALANCE 01 each 201102-01 ROLL PIN 3/4” 01 each 200502-01 ROLLER 01 each... -
Page 15: Range Of Application
5.7 RANGE OF APPLICATION TABLE A: RANGE OF APPLICATION on ANSI, BS & API FLANGES pressure 1 1/4 2 1/2 3 1/2 (psi) 1 1/2 ... -
Page 16: Fa3Tm Mechanical Fixed Flange And Rotational Alignment Tool
6. FA3TM MECHANICAL FIXED FLANGE AND ROTATIONAL ALIGNMENT TOOL 6.1 KIT COMPONENTS 1 x FA3TM Tool 1 x 50 ft/lbs (67.8 Nm) Torque Wrench with 22 mm Socket 1 x Instruction Manual 1 x Carry-Case with Protective Foam Inserts Product Code: FA3TMSTD 6.2 HOW THE FA3TM WORKS The FA3TM is secured to the lower of the two flanges by fully inserting the lift hook into the bolt-hole which is parallel with the bolt-hole on the opposite flange. -
Page 17: Installation And Operation
6.3 INSTALLATION AND OPERATION KNURLED LOCKING HANDLE How to use the torque wrench KNOB Balance the wrench in your left hand and unlock the knurled handle by turning the locking knob anti-clockwise. Newton Scale (N/m) Set the torque amount by turning the knurled handle - see example 40-46 1. - Page 18 POINT OF MAX. Carry out the Flange Misalignment MISALIGNMENT Determination Procedure (see section 4) to determine the points of maximum misalignment. In this example the points of maximum misalignment are at the top and bottom of the joint. POINT OF MAX. MISALIGNMENT Guide the lift hook into the bolt-hole at the maximum point of...
- Page 19 Attach the torque wrench to the screw bolt and tighten in a clockwise direction until the joint comes into alignment. The torque wrench should be set at staged increases, e.g. 10 ft/lbs, TORQUE WRENCH 20ft/lbs until the maximum setting of 50ft/lbs (67.8 N/m) is reached.
-
Page 20: Examination, Maintenance And Storage
6.4 EXAMINATION, MAINTENANCE AND STORAGE • On return from each job and before allocation against subsequent work the completeness of the Equalizer FA3TM kit must be established and items examined to ensure that they are serviceable • Any missing or damaged items are to be replaced as soon as possible and prior to the tool being used again •... -
Page 21: Parts List
6.5 PARTS LIST ITEM PART No. DESCRIPTION QUANTITY ITEM PART No. DESCRIPTION QUANTITY 400203-01 50ft/lbs TORQUE WRENCH 01 each 400501-01 SWIVEL 01 each 400204-01 22 mm SOCKET 01 each 400601-01 THRUST BEARING SET 01 each 400301-01 SCREW BOLT 01 each 400801-01 FRICTION PAD 01 each... -
Page 22: Weights And Dimensions
6.6 WEIGHTS AND DIMENSIONS WEIGHTS Tool only = 8.1 kg (17.82 lbs) Carry-Case with Protective Foam Inserts = 6 kg (13.23 lbs) GROSS KIT WEIGHT = 14 kg (30.90 lbs) OVERALL DIMENSIONS 70 mm 380 mm (2.75") (14.90") 288 mm (11.36") MINIMUM EXTENSION MAXIMUM EXTENSION... -
Page 23: Troubleshooting
6.7 TROUBLESHOOTING Problem: The friction pad is sliding in the circumference of the opposite flange as the tool is aligning the joint Grit or dirt on wing, rollers or Ensure the rollers are rotating freely and that there is no restriction to ... -
Page 24: Range Of Application
6.8 RANGE OF APPLICATION MINIMUM AND MAXIMUM FLANGE SIZES Dimension A: must be between 30 and 133 mm (1.18” and 5.23”) Dimension B: bolt-hole diameter must be 24 mm (0.95”) or greater DIMENSION DIMENSION BY FLANGE TYPE, CLASS AND DIAMETER If the flange to be aligned is not listed please use the Minimum and Maximum Flange Sizes guide above FLANGE ALIGNMENT TOOLS PAGE 22... -
Page 25: Fa6Te Hydraulic Fixed Flange And Rotational Alignment Tool
7. FA6TE HYDRAULIC FLANGE SPREADING WEDGE 7.1 KIT COMPONENTS 1 x FA6TE Tool 1 x 10,000 psi (700 bar) 6 T Hydraulic Cylinder 1 x 10,000 psi (700 bar) Hydraulic Hose, 2 m (78.75”) 1 x 10,000 psi (700 bar) HP350S Sealed Hand Pump with Gauge 1 x Instruction Manual 1 x Carry-Case with Protective Foam Inserts... -
Page 26: Installation And Operation
7.3 INSTALLATION AND OPERATION POINT OF MAX. MISALIGNMENT Carry out the Flange Misalignment Determination Procedure (see section 4) to determine the points of maximum misalignment. In this example the points of maximum misalignment are at the top and bottom of the joint. POINT OF MAX. - Page 27 Connect the hydraulic pump to the hydraulic hose, and the hose to the hydraulic adjusting cylinder. Prime the pump until the joint comes into alignment. Once in alignment the bolts may be inserted and tightened. After replacing all of the bolts (apart from the bolt which will go into the bolt-hole in which the FA6TE is located), remove the tool by...
-
Page 28: Examination, Maintenance And Storage
7.4 EXAMINATION, MAINTENANCE AND STORAGE • On return from each job and before allocation against subsequent work the completeness of the Equalizer FA6TE kit must be established and items examined to ensure that they are serviceable • Any missing or damaged items are to be replaced as soon as possible and prior to the tool being used again •... -
Page 29: Parts Lists
7.5 PARTS LISTS FA6TE TOOL ITEM PART No. DESCRIPTION QUANTITY 903101-01 6T HYDRAULIC ADJUSTING 01 each CYLINDER 900302-01 WING 01 each 900502-01 M10 SPRING PLUNGER 01 each 900701-02 FINGER STOP-FRONT 01 set of 2 900801-02 SUPPORT SHAFT 01 set of 2 900901-04 SUPPORT ROLLER 01 set of 4... - Page 30 HP350S HAND PUMP ITEM PART No. DESCRIPTION QUANTITY ITEM PART No. DESCRIPTION QUANTITY 710101-01 PUMP HOUSING 715800-01 SERVICE KIT H: 715100-01 SERVICE KIT A: - CHECK BALL - OIL FILTER - SPRING END CAP - O-RING - SPRING - RESERVOIR BLADDER - SPRING - REFILLING PLUG - O-RING...
-
Page 31: Weights And Dimensions
7.6 WEIGHTS AND DIMENSIONS WEIGHTS Tool with Hydraulic Cylinder = 15.5 kg (34.1 lbs) Carry-Case with Protective Foam Inserts = 7.5 kg (16.5 lbs) GROSS KIT WEIGHT = 28 kg (61.1 lbs) OVERALL DIMENSIONS 526 mm 90 mm (20.75") (3.50") 307 mm 295 mm (12.25") -
Page 32: Troubleshooting
7.7 TROUBLESHOOTING Problem: The tool is advancing but does not reach full pressure Air could be present in Use the airlock removal the hydraulic system procedure as follows: Connect the hand pump to the RESERVOIR tool with the hydraulic hose Close the release valve on the pump, and prime the pump until the hydraulic cylinder... - Page 33 Problem: The friction pad is sliding in the circumference of the opposite flange as the tool is aligning the joint Grit or dirt on wing, rollers or Ensure the rollers are rotating freely and that there is no restriction to ...
-
Page 34: Range Of Application
7.8 RANGE OF APPLICATION MINIMUM AND MAXIMUM FLANGE SIZES Dimension A: must be between 93 and 228 mm (3.75” and 9”) Dimension B: bolt-hole diameter must be 31.5 mm (1.25”) or greater DIMENSION DIMENSION BY FLANGE TYPE, CLASS AND DIAMETER If the flange to be aligned is not listed please use the Minimum and Maximum Flange Sizes guide above FLANGE ALIGNMENT TOOLS PAGE 32...
