Summary of Contents for cramZ 900-R
- Page 1 900-R (remote) Installation Manual Distributed by cramZ marketing services, Inc. - sales@cramzmarketing.com - (770) 529-1040...
- Page 2 WARNING!!! Clear line of sight between the Radio Frequency equipment is mandatory. This means that both antennas must be visible to each other in order to achieve the distances advertised. If installed with floors or walls between the antennas, distances will be significantly reduced.
-
Page 3: Table Of Contents
Relay Status ........................3 Field Strength Indicator (Receive Signal Strength Indicator)........3 Data Communication Indicator..................3 MC LED......................... 3 Power to the 900-R ......................... 4 900-R Setting .......................... 5 RF Channel Setting ......................5 RF VID Setting ....................... 5 RF Power Setting ...................... - Page 4 List of figure Figure 1-1 900-R Overview ......................1 Figure 1-2 Typical System Diagram of 900 Series................. 1 Figure 1-3 900-R Board Diagram ....................2 Figure 3-1 Power to 900-R ......................4 Figure 4-1 RF Channel Setting ....................... 5 Figure 4-2 RF VID Setting ......................5 Figure 4-3 RF Power Setting ......................
-
Page 5: General
Figure 1-1 900-R Overview 900-R functions as a pair with a 900-PRIME. It wirelessly connects a reader, request to exit button, door contact, door strike etc. to a host reader interface (HRI). It is compatible with up to a 50-bit Wiegand signal. -
Page 6: Figure 1-3 900-R Board Diagram
900-R Installation Manual Figure 1-3 900-R Board Diagram 900-R Installation Manual... -
Page 7: Indicators
900-R provides indicators to display its status conveniently. These LED’s allow the user to monitor the status of the 900-R. Power LED (Green) This LED indicates if the 900-R unit has power. LED lit indicates power. If the LED is not on, check the power source. Offline LED This LED indicates the 900-R’s RF link status. -
Page 8: Power To The 900-R
900-R Installation Manual 3 Power to the 900-R The module accepts 24Vdc for power. Locate the power source as close to the module as possible. Make power connections with a minimum of 18AWG (Belden 9740 or equivalent) wire. Figure 3-1 Power to 900-R... -
Page 9: 900-R Setting
4 900-R Setting RF Channel Setting 900-R supports 10 different hopping schemes (CH0 ~ CH9), which MUST be set to the same number as the 900-PRIME that communicates with this module. DIP switch SW1 is used to set the channel. -
Page 10: Rf Address Setting
Input type Unsupervised Supervised Figure 4-5 (Un) Supervised Input Selection Reader Power Setting A built in reader interface on 900-R can support 5Vdc (100mA) or 12Vdc (100mA) reader. Jumper S3 is for reader power selection. Setting Description Function ON / Closed... -
Page 11: Offline Mode Setting
900-R Installation Manual Offline Mode Setting There are four modes which can be set for when communication is lost among the modules. The mode is set by S1 and S2 of the SW1 settings. 4.7.1 Facility Code Only - 5 Second In this mode, the cardholder will be granted access with a card with the correct facility code. -
Page 12: Facility Code Setting
The facility code is established by the card manufacturer or installer. This code is designed to be unique to each building. Every card user will have this facility code along with their user ID. 900-R supports facility codes from 0 to 255. SW2-... -
Page 13: 900-R Wiring
900-R Installation Manual 5 900-R Wiring Input/Output Corresponding Here is the corresponding list of the input/output table for the 900-R and 900-PRIME. This table will work for both 1-1(one 900-R and one 900-PRIME) and 1-2 (one 900-PRIME and two 900-Rs). -
Page 14: Output Wiring
NO/NC selection by jumper settings. Factory default output settings are Normally Open. Use minimum 18AWG (Belden 9740 or equivalent) for the connection. Figure 5-2 900-R Output Wiring Diode selection: Diode current rating > 1X normal current... -
Page 15: Input Wiring
900-R Installation Manual Input Wiring IN1 and IN2 are dedicated as a Door Contact and a Request to Exit button when 900-R is used in an access control system. When using Supervised input they must satisfy the requirements of supervising Host access control systems. -
Page 16: 900-R Reconfiguration
Normal state ON / Closed Reset Figure 6-1 900-R Reset Configuration and Reconfiguration of the System After changing the setting on the SIP switches the radio requires reprogramming. This is done automatically through the microprocessor; however it is vital that the microprocessor completes its work prior to connecting inputs and outputs or modifications to the system. -
Page 17: Specification
900-R Installation Manual 7 Specification The module is for use at low voltage, class 2 circuits only. Primary power DC input: 24Vdc, 600mA Communication RF OEM Module Frequency range: ISM 902M ~ 928MHz Channel 10 hop sequences share 50 frequencies Capacity: Indoor/Urban Range(w/ 2.1 dB dipole antenna): up to 1500’... -
Page 18: Rf Communication Link
TK900F tester kit. Antenna Orientation 900-R has been designed with a swivel antenna for RF transmission. This is an omni directional antenna. This type of antenna will allow the user to orientate the antenna to obtain the maximum desired transmission and reception of signal. -
Page 19: Fcc Compliance
• This device is tested to UL 294 standards with the HID reader. 11 Warnings RFWireless/cramZ marketing is in no way liable for incorrect installations of the RFID products which may cause damage to equipment or persons. End users, installers, purchasers or anyone using, buying, selling or using this product must follow the exact installation instructions as outlined in the instruction manual. -
Page 20: Warranty
900-R Installation Manual 12 Warranty RFWireless/cramZ marketing warrants the product to be free from defects in material and workmanship under normal use and service with proper maintenance for one year from the date of factory shipment. Alertco RF / RFID assumes no responsibility for products damaged by improper handling or installation, including blown power supplies or damage done from "HOT SWAPPING"...
