Needed to Assemble: edge power Roll of blue painters tape Pencil or Pen for marking Measuring tape/ Stud Finder Tape Measure Optional in case of wood or concrete mounting surface: Drill bit for concrete: -Size: 1/8 Drill for concrete mounting -Bit Length: 1 ¾”...
Page 3
Frame Assembly Steps: Template Assembly: Step 1: Assemble the mounting template following a clockwise sequence as labeled in each part. Step 2: Secure each part by placing blue tape across each section joint. Step 3: Repeat taping process on backside of template to ensure all sections are well aligned. PAGE 2...
Page 4
Finding TV Midpoints Step 4: Finding and marking the midpoints on TV top section (horizontal) and right side section (vertical). Using blue tape and pencil/pen to mark midpoints. Visually estimate the midpoint of TV top/horizontal section and place a 4 inch piece of tape along the outside TV border as shown in illustration A.
Page 5
Step 5: Once exact midpoints have been identi ed, place a line marking on blue tape as shown in gure 5. Step 6: Place a strip of blue tape on wall adjacent to the midpoint marked on TV (top and right side of TV sections marked).
Page 6
Step 7: Using the 90-degree straight edge provided, align midpoint markings on television with blue tape on the wall and place the corresponding marking so that TV midpoint markings and blue tape markings on the wall are now accurately aligned. Template Placement on Wall &...
Page 7
Maneuver template by placing around and behind top left corner of TV followed by bottom left corner. Once template is behind TV on the left side, slide gently toward the right and repeat process on the right side. The top/horizontal and right side (MP) midpoint markings on blue tape on wall will align with midpoint markings on template.
Page 8
Use provided “level” to ensure template is evenly positioned horizontally by placing level at di erent point on top horizontal edge of template. Also, check vertical alignment using level. PAGE 7...
Page 9
Con rm midpoint alignments using the provided 90 degree edge ruler. Midpoints marked on TV should perfectly align with midpoint markings on template. Locate Mounting Holes Gently slide TV to the Left Gently slide TV to the Right Locate “Mounting Holes” on template by gently sliding TV on the wall bracket until the mounting holes are within comfortable reach.
Page 10
Marking Mounting Holes Step 9: Place marking using pencil/pen at the CENTER of each mounting hole. Mounting hole as shown in illustration: A, B, C & D. Step 10: Remove mounting template from the wall. PAGE 9...
Page 11
Drywall, Concrete & Wood Mounting Step 11: Drywall Anchors + Screws, Concrete Anchors + Screws & Wood Screws Carefully align tip of drywall anchors with mounting hole markings and in a clockwise rotation begin gently inserting anchor into drywall applying moderate pressure and using provided Phillips screwdriver.
If mounting TV frame to wood or concrete, use a corresponding bit (Size: 1/8” and Length: 1 ¾’”) and drill a pilot hole at center of mounting hole markings made with template. Insert provided concrete anchors into pilot hole then proceed with mounting instructions. *Use images below as reference for mounting hole;...
Page 13
Based on your current setup of cable assembly (TV Power cable, Cable Box, etc.) Use section “A” for bottom or top (for cable assembly located at top, reference age 14) of TV as this section provides holes to accommodate your cables. Proceed to pass all cables through determined hole prior to mounting section to wall.
Page 14
Insert screws into anchors and begin to tighten so that section is securely xed on wall. Repeat process for next section. (*Note: You will need to slide TV to the left to gain access to mounting holes). Left Side Insert screws into anchors and begin to tighten so that section is securely xed on wall. Repeat process for next section.
Page 15
Based on your current setup of cable assembly (TV Power cable, Cable Box, etc.) Reference instruction section “D” for top (*skip section if done in “A”) as this section provides holes to accommodate your cables. Proceed to pass all cables through determined hole prior to mounting section to wall. Insert drywall anchor screws or wood/concrete screws 1/2 way into the frame section “D”...
Page 16
Insert screws into anchors and begin to tighten so that section is securely xed on wall. Repeat process for next section. (*Note: You will need to slide TV to the right to gain access to mounting holes). Left Side Insert screws into anchors and begin to tighten so that section is securely xed on wall. Repeat process for next section.
Tightening Screws Carefully holding each part begin to drive screws into anchor with provided screwdriver until section is well secure to wall. Repeat for next horizontal section. Top Left Top Right Bottom Right Bottom Left PAGE 16...
Page 18
Connecting & Removing Sections Step 13: Placement of side sections (vertical) Carefully align top of section “B” with corresponding section “A”. Magnets will pull sections together. Ensure you ngers are not at edges coming together as magnets are very strong and will “pinch” if your caught in the middle;...
