Summary of Contents for Templari HCC

  • Page 1 House Climate Control 1.071...
  • Page 2 WARNING! It is recommended that you read the entire manual before proceeding with the installation. WARNING! In order to receive assistance on the product, the panel must be connected to the internet and be online.

  • Page 3: Table Of Contents

    4.3.3.1 S quare meters assignment ....................22 4.3.3.2 S ervice settings ....................... 23 4.3.4 Set password ........................23 Alarm..........................23 SCHEDULING ........................24 5.1 Scheduling ........................24 ADVANCED USE OF THE PANEL ..................24 6.1 Access advanced features of the HCC panel ..............24 6.2 Retrieve the address of the HCC touch panel ..............25 6.3 Change the password for remote access................. 25 6.4 Remote vision of the HCC panel ..................25...

  • Page 4: Iwarnings

    To use the HCC system remotely, via a VNC program, you must Then prepare the power supply of adequate power to support the connect the RJ45 port on the back of the Touch HCC Panel to system, or use HCC POW.

  • Page 5: Plant Examples

    Connecting to the Kita heat pump. ROOM If you want to use the PGD1 remote control panel at the same time as the Touch Panel HCC, you must use a BMS card, purchased separately. Example of If the BMS card is present, a 120Ω resistore must be installed...

  • Page 6: System Overview

    CIRC. FUSE COM2 COM2 ROOM sensor ROOM sensor FLOOR SENSORE SENSORE HCC touch panel PANNELLO HCC 1.07x NC C NO NC C NO NC C NO NC C NO Figure 2 Sensore ROOM guide MODBUS REGISTERS Device MODBUS address Temperature probe Terminator resistor 120 Ω.
  • Page 7 Touch HCC panel connected via BMS μPC TERMINATOR RESISTOR MODBUS 120Ω figura 5 Touch Panel HCC connected via P-LAN as the only display MODBUS μPC Connecting to ground Collegamento a massa figura 6...

  • Page 8: I/O Floor Board Guide

    WARNING! The card provides the control of a zone mixer, PWM or 3 points type. Refer to the HCC manual for power supply and installation of MODBUS Use the MIX output for digital valves with PWM control. Use the communication.

  • Page 9: Address Programming Procedure, Temperature Offset And Humidity Offset For Fw Versions> 1.2

    Go to SETTINGS -> ADVANCED Screen (see 4.2) to enable the newly installed and connected sensors (green ball selected). Select the square corresponding to the installed HCC ROOM sensors. The selected square will turn green and the sensor will be active.

  • Page 10: Configuration Temperature Offset And Relative Humidity Offset

    When the 24V line is switched on again, each sensor shows its address on the display. Check that it is correct and unique in the network of Hcc devices. When the system is switched back on, using the HCC Touch panel go to SETTINGS -> ADVANCED screen (see 4.2) Reactivate the Room sensors by turning on the relevant green boxes.

  • Page 11: Errors And Malfunctions

    To check the address stored inside the sensor, disconnect the 24Vdc power supply, disconnect the 24V power supply terminal on the TOUCH HCC panel and switch on the power supply again. Wait for the display of the sensor under test to turn off. A moment before switching off, the stored address will appear.

  • Page 12: Modbus Data Network Check

    Make sure that the Modbus data cable used is the recommended type. • Make sure you have inserted the 120 Ω termination resistors, supplied with the Touch HCC Panel, and that you have connected the sheath of the data cable to the ground pole of the power supply.

  • Page 13: Introduction

    20 ° C for heating and 25 ° C for cooling. The system can consist of: • HCC touch panel, which will allow you to monitor and set We recommend using DAY profile for everyday Setpoint, when all operating parameters; you want to make the house comfortable for the people living •...

  • Page 14: Menu Bar Overview

    By default, changing the setpoint is enabled only through the SUMMER and DHW (see 3.1 and 3.3). HCC touch panel, but you can also enable changing from the WINTER is used when you want to generate heat, SUMMER is installed sensors.

  • Page 15: Enviroments

    Mixer Speed of the fancoil. If you have a fancoil provided by By touching the radiant icon on the screen of any environment, you Templari, the speed can be changed: Low, Medium, can open the mixer screen. Maximum and Auto. The mixer color indicates whether the plant is producing hot (orange) or cold (blue) water.

  • Page 16: Heat Pump

    HEAT PUMP The HEAT PUMP section is dedicated to the most important heat pump functions and is divided into subcategories: BASE and PUMP SETTINGS. 3.1 Base In this screen you can monitor the current operation of the heat pump. Opening of the 3-way mixing valve. 100% indicates...

  • Page 17: Overview

    (see 4.3.3), this number is except for the DHW. displayed, showing the percentage of request that the HCC touch panel passes to the heat Manual set point. Tapping the icon will display pump compressor. the pop up to set the manual heating, cooling and DHW setpoints.

  • Page 18: Optimizer

    Graph. open the optimizer screen where you can activate it. Close screen. By tapping this icon you can return to the heat pump settings screen. 3.2.2 Optimizer In this screen you can activate the optimizer and set its operating values.

  • Page 19: Settings

    The sensors and mixers are in constant communication with the representing the language currently in use. HCC panel to be able to work best, but if for some reason more than By tapping the icon, you access the Language 10 consecutive read and / or write errors occur on a device, that Change Screen to select the language you want.

  • Page 20: Builder

    It is also possible to associate more fancoil with a single indicates that it is not a fancoil supplied by Templari. Fancoil sensor. If more fancoils are present and active in the same...

  • Page 21: Room Sensor Settings

    To have the new address become fancoil is not provided by Templari, so some active, the device must be restarted. features may not be available.

  • Page 22: More

    - Compressor controlling: by activating this function, the This screen is password protected and only qualified personnel Templari heat pump compressor rpm will be controlled by the should access it. It is used to modify more specific settings. HCC panel according to the environments request. The higher the demand, the greater the compressor rpm.

  • Page 23: Service Settings

    (see Error Rate Count in 4.3) then the HCC panel will assume that it is malfunctioning and then disconnected to avoid damaging the system by working with potentially incorrect values. In the list then the alert notification will appear in red. At the top right of the monitor, instead of the external temperature, a red triangle will appear to inform the user that an error has occurred.

  • Page 24: Scheduling

    When the system works in manual profile, the user selects by Access to the advanced features of the HCC panel requires access to his own the various setpoints for heat pump and environments, the appropriate menu.

  • Page 25: Retrieve The Address Of The Hcc Touch Panel

    6.4 Remote vision of the HCC panel touch panel Once the system is completed and the HCC panel is installed, it will be possible to monitor its functions remotely. Steps to make this In the advanced functions of the HCC panel (6.1), use the Prev possible are few and simple.
  • Page 26 Templari Srl Via Pitagora, 20/A - 35030 Rubano (PD) - Italy Tel +39 049 5225929 | Tel +39 049 8597400 | Fax +39 049 8055626 info@templari.com - www.templari.com - P. IVA 04128520287...
