Nevco 871 Basic Operating Procedures

Nevco Model 871Time Clock at Bear Mountain & Juan de Fuca
To set time for first period - press SET / TIME / 20 / 00 - period - 1
1.
as the referee blows the whistle to begin the period, turn the panel switch on.
2.
To enter goals - press HOME SCORE or VISITOR SCORE / 1
3.
To enter a penalty - press SET / GUEST PENALTY / 02 / 00 / YES player number -
4.
01
To clear a penalty - press HOME PENALTY / PENALTY CLEAR / YES
5.
To edit a penalty - press HOME PENALTY / PENALTY EDIT / enter edited time,
6.
press YES
To edit the time (with clock running) press SET / TIME enter edited time, press YES
7.
To edit the score - press SET / HOME SCORE / then enter edited score
8.
At the end of the first period - turn the panel switch off after the horn has sounded.
9.
To save existing penalties between periods - press PENALTY OFF before you
10.
re-start the clock for the three minute break.
11.
To set the break time between periods - press SET / TIME / 03 / 00 / YES
12.
To stop the shot-clock between periods - press SET / MISC. SHOT TIME / BLANK
13.
/YES
When horn sounds at the end of the break - turn panel switch off
14.
Press PENALTY ON (shot-clock will re-engage automatically)
15.
While the referee is setting up the face-off for the second period, set the time for
16.
period two as you did for period one. The clock will ask for the period number - enter
2
As the referee blows the whistle to start the period, turn the panel switch on.
17.
for NEVCO Model 871 Time Clock at Bear Mountain & Juan de Fuca
Turn the clock power on. (toggle switch on the side of the clock )
1.
Turn the panel switch off. (this on/off plunger switch is on a cord coming from the
2.
left side of the clock and allows the count-down function of the clock to be stopped
and started without interrupting the power supply.
The clock will now ask if you want to start where turned off - press no
3.
The panel will now read 'Hi, I'm your Nevco MPC - 4. I can operate over 500 Nevco
4.
Models, please enter your model code'. Now enter 8-7-1 .
The clock will ask if you want to use penalty time-out - press yes. The panel will now
5.
read 0: 00. 03
Now set up the time for the first period - press set, press time, press 2-0 press 0-
6.
0, press yes. The clock will now read 'period' - press 1
Turning the panel switch on as the referee blows the whistle at the opening face-off
7.
will start the clock counting down the first period.

Basic Operating Procedures

DETAILED Operating Procedures
