Camec 2 Series Quick Start Manual

Folding Mono­crystalline solar panel with

Kit Contents

3 versions of the Solar Panel kits are available. Depending on which kit you have, it will
include one of the panels below:
100W Kit p/n 044047
15A Solar Charge Regulator
•
•
•
NOTE: It is normal for the LED's to flicker on & off or alternate when in use as the
controller's microprocessor constantly monitors the state of charge, discharge and
amount of energy being generated by the panel.
5 Meter connection cable with Anderson plugs & battery connector.
Padded storage bag,
15A Charge Regulator – Series 2
120W Kit p/n 044048
Green (Working) LED on or flashing indicates that the unit is operating/optional
load output is connected.
Blue (Charging) LED on indicates that the battery is charging. Note when the
battery is fully charged, this LED may flash as the controller cycles the charge to
keep the battery topped up.
Red (Low Voltage) LED indicates that there is no battery connected or the battery is
below 10.8V. The LED may flash along with the Blue charging LED to indicate the
battery is fully charged. Also this LED may flash alternately with the Green LED to
indicate there is no Solar input (ie the panel is obscured by clouds etc) – but by
flashing, this indicates the battery is still above 10.8V and suitable for use.
160W Kit p/n 044049
