Summary of Contents for D.T.Systems SUPER PRO Dummy Launcher
- Page 1 SUPER PRO SUPER PRO SUPER PRO SUPER PRO SUPER PRO SUPER PRO SUPER PRO SUPER PRO Dummy Launcher Dummy Launcher Dummy Launcher Dummy Launcher Dummy Launcher Dummy Launcher Dummy Launcher Dummy Launcher Owner’s Manual...
- Page 2 IMPORTANT NOTICE Please read this owner’s manual in its entirety before op- erating this unit. Should you have any questions about our Launchers or their operation please contact our Customer Service department (contact information on back page of this manual).
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents ........3 • Safety Warning! .......... 4 • Introduction..........5 • Quick Tips ..........6 • Package Contents ........7 • Features ............. 7 • Parts & Functions ........8 • Loading Launcher........10 •... -
Page 4: Safety Warning
SAFETY WARNING! KEEP OUT OF REACH OF CHILDREN AT ALL TIMES! THIS UNIT IS NOT A TOY! SAFETY TIPS AND PROCEDURES This product can be extremely hazardous if not used prop- erly. While it is not a firearm, the same caution and safety procedures should always be followed as if it were. -
Page 5: Introduction
INTRODUCTION Congratulations and thank you for purchasing our Su- per Pro Series Dummy Launcher. This Launcher is the most technologically advanced dummy launcher on the market today. The D.T. Systems Super Pro Dummy Launcher is an excellent tool for teaching and reinforcing the hunt- ing situation of tying together the sound of a bang with the marking of a bird in the sky. -
Page 6: Quick Tips
QUICK TIPS Before You Go Out: • Purchase and use only D.T. recommended GREEN and YELLOW power loads. RED power loads can be used but are not recommended as they will cause faster wear and tear on your unit and dummy. •... -
Page 7: Package Contents
PACKAGE CONTENTS All Super Pro Dummy Launcher units include: • Super Pro Dummy Launcher • Owner’s Manual for Super Pro Dummy Launcher • Earplugs • Extra o-rings Super Pro Dummy Launcher kits also includes: • Super Pro Launcher Dummy (colors vary) NOTE - We recommend using D.T. -
Page 8: Parts & Functions
PARTS & FUNCTIONS Dual Ports Rubber Launching O-Ring Pressure Vent hole Solid Aluminum Launcher Top Deep Well Flash Pan Solid Shell Chamber Aluminum and Extractor Base Thick, Dense Wide Nylon Recoil Pad Comfort Grip Handle Sleeve Solid Aluminum Frame Self-Contained Construction Firing Pin Mechanism... - Page 9 PARTS & FUNCTIONS Dual Ports - Consistently provides steadier, more balanced and farther launch. Rubber O-Ring - Creates a seal within the Dummy Tube to allow pressure buildup for launch. Launching Pressure Vent Hole - Pressure from the fired power load builds through this hole and out the Dual Ports into the Dummy Tube.
-
Page 10: Loading Launcher
LOADING LAUNCHER WARNING - Review the Safety Warnings on p.4 and familiarize yourself with all Parts & Functions on p.8-9 before operating this launcher. Never pull and release the Firing Pin Pull Knob with an empty Chamber. This is known as “Dry Firing” and can severely damage the Chamber/Firing Pin, making power load cartridge insertion and removal very difficult. -
Page 11: Firing Launcher
FIRING LAUNCHER WARNING - Review the Safety Warnings on p.4 and familiarize yourself with all Parts & Functions on p.8-9 before operating this launcher. 1. Grasp Launcher firmly in one hand. Always place the heel of your hand against the Recoil Pad (Fig.1) to avoid injury caused by the recoil. -
Page 12: Unloading/Ejecting Power Load
UNLOADING/EJECTING POWER LOAD WARNING - Review the Safety Warnings on p.4 and familiarize yourself with all Parts & Functions on p.8-9 before operating this launcher. Ejecting Used/Misfired Power Load 1. After launch (or misfire), lift Locking Lever and open Dummy Launcher. 2. -
Page 13: Maintenance
MAINTENANCE Properly cleaning and maintaining your Super Pro Dummy Launcher is essential to keeping it in good working order, and is required for Warranty compliance. Make sure the launcher is not loaded while performing maintenance. • After each use, clean the chamber with a .22 Cal. Stainless Steel cleaning brush and gun solvent (if this is not done powder residue will build up which will make insertion and removal of blank cartridges very difficult). -
Page 14: Warranty
WARRANTY All Super Pro™ Dummy Launcher units have a one year parts and labor warranty effective from the original date of purchase. A copy of the original sales receipt is required to validate the date of purchase for any warranty repairs. This warranty covers all repair costs for any manufacturer’s defects or defects that occur during normal use and maintenance. -
Page 15: Legal Notice
LEGAL NOTICE Proper Use and Maintenance of the Super Pro™ Dummy Launcher is the responsibility of the Buyer. D.T. Systems, Inc. and its representatives are in NO WAY liable for inju- ries/damages resulting from improper use. Buyer/User of said devices agrees to hold D.T. Systems and its repre- sentatives harmless from and indemnify them from any and all claims, damages, demands, penalties, suits or causes of actions whatsoever brought by any person or... -
Page 16: Contact Information
D.T. Systems, Inc. 2872 Walnut Hill Lane Dallas, Texas 75229 (214) 350-9446 (888) 588-8364 Fax: (214) 350-7847 www.dtsystems.com customerservice@dtsystems.com SUPER-PRO 2014.11.26 Printed in Korea...
