iPdomo Wi-Fi Thermostat
Installation and User Guide
Rev. 3.1EN of 03/06/2015
Control your heating system easily and efficiently
Use it from anywhere and anytime via the Internet
From any device with a Web browser or using our App for Android
Set the time schedule according to your stay at home
See temperatures and the use of the boiler in time charts
It connects to the Internet through your Wi-Fi network
Quick and easy guided installation
Powered by 3 AA batteries
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for iPdomo Wi-Fi Thermostat
Summary of Contents for iPdomo Wi-Fi Thermostat
- Page 1 Wi-Fi Thermostat Installation and User Guide Rev. 3.1EN of 03/06/2015 Control your heating system easily and efficiently Use it from anywhere and anytime via the Internet From any device with a Web browser or using our App for Android...
- Page 2 Option 1: Keeping your existing Thermostat If you chose to retain your existing thermostat, you can operate your heating system efficiently with iPdomo, and return the control to your thermostat at anytime. You can change the mode control via the web interface, or using the...
- Page 3 If you want to turn off the boiler manually, you can use the thermostat Function button. Wherever you decide to locate your iPdomo thermostat, you will need to obtain a good Wi-Fi signal from your Router. Test your Wi-Fi signal quality at your preferred location with a smartphone, tablet or laptop.
- Page 4 Then fix and mount the existing thermostat on its mounting plate. Leave some free space to the left of the iPdomo Thermostat to insert the USB Pen Drive later. For 3-wire cases, connect the Live and Switched Live wires from your old thermostat to...
- Page 5 Take note of the S/N, fit the 3 AA batteries noting polarity and plug-in the connector to the iPdomo Thermostat as in the first picture. Place it forming a 15 degrees angle with the wall mounting plate, like a "V". Adjust it so that the bottom tab encloses with the device and then fit it using the top tabs.
- Page 6 Device Layout and Operation Operating Modes Activated : The iPdomo Thermostat controls your heating. (#3) Deactivated : Your old thermostat controls your heating. If batteries run out, the thermostat will automatically switch to Deactivated Mode. In Deactivated Mode, if there isn't any manual thermostat, the boiler will stay off.
- Page 7 Wi-Fi Configuration Now we need to setup the Wi-Fi in the iPdomo Thermostat to put it online. 1. You will need: The name of the Wi-Fi network (SSID) you want to connect to Your Wi-Fi network security settings (OPEN, WEP, WPA, WPA2)
- Page 8 (#4) (#4) It is used to show the forecast weather in your city. HOME Screen See at a glance the current status of all of your iPdomo equipment. This bar shows your location within the It shows actual and required (#5) cloud interface.
- Page 9 THERMOSTAT Main Screen Cloud symbol appears after a change. It notes it’s waiting Button to toggle between for the thermostat to wake up and to sync with the Cloud. Automatic control (scheduled) or Manual control Local weather Setpoint temperature Actual room Temperature Increase the Decrease the...
- Page 10 Select the device you want to use as the room temperature sensor If you have an iPdomo remote controlled Socket Meter, you can use it as the room temperature sensor by selecting it at the drop-down list. This will be useful for getting the actual temperature from another room.
- Page 11 PROGRAMMER Screen This button in the Thermostat Main Screen brings you this window, where you can define your time schedule and specify the setpoint temperature you want in each moment. To set a programme: : Copy these : Make your : Save your : Select the first programs to the...
- Page 12 Legend: Click on a parameter name to display or hide it. Specifications are valid except for typographical errors. The company reserves the right to change the specifications of the equipment or change the information contained in this guide without prior notice. Visit us at: http://store.ipdomo.com...
