Article number: 010-252-000
Date: June 2016
Version 1.1– Translation of original manual
According to Annex 1 chapter 1.7.4 Machine Guideline 2006/42/EC
Black V anti-spill
Installation and operating instructions
in feed station: 002-672-010
in VMS: 002-672-020
Anti-mors voerdosator
Anti-spill feed dispenser
Anti-verschütt Fütterdosierautomat
Dosateur d'alimentation anti-gaspillage
Doetinchem,
The Netherlands
www.hanskamp.nl/en
EN
Advertisement
Summary of Contents for Hanskamp Black V anti-spill
- Page 1 Black V anti-spill in feed station: 002-672-010 in VMS: 002-672-020 Anti-mors voerdosator Anti-spill feed dispenser Anti-verschütt Fütterdosierautomat Dosateur d’alimentation anti-gaspillage Installation and operating instructions Article number: 010-252-000 Date: June 2016 Doetinchem, Version 1.1– Translation of original manual The Netherlands According to Annex 1 chapter 1.7.4 Machine Guideline 2006/42/EC...
-
Page 2: Manual Contents
All information in this manual has been compiled with care. Hanskamp shall not be liable for errors or faults in this manual. The recommendations are meant to serve as guide- lines. - Page 3 This creates restlessness in the area around the out-of-parlour feeder or milking robot, as well as in the herd itself. The Black V anti-spill, manufactured by Hanskamp, offers the perfect solution for this problem. This product consists of an auger, actuated by an electromotor, and is placed underneath the concentrate supply line.
- Page 4 Only use approved spare parts, and make sure they are only installed by authorized technicians. 4 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
- Page 5 Before the electrical supply is attached to the Black V, make sure all parts are tight and that all the parts are in good condition. Contact your nearest milking equipment dealer if you have any questions. 5 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
- Page 6 General safety messages appear in this safety messages section. Specific safety messages are in applicable parts of this manual when potential hazards may occur if the instructions or procedures are not followed. 6 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
-
Page 7: Installation Instructions
If the Black V is controlled by a controller, other than the Hanskamp ControlUnit, always consult the instructions for the corresponding control unit. For connecting the Black V to an out-of-parlour feeder, the electric dosage unit can be connected to the next available feed type slot. - Page 8 Keep the safetystickers clean and clearly visible. Clean the stickers with soap and water. Do not use dissolving or corrosive solutions that can damage the stickers. Replace mis- sing or unreadible stickers. Safety stickers are available at Hanskamp. Please refer to the article numbers when corresponding.
- Page 9 Warning! When changes are being installed/mounted in the Black V, make sure to shut down the power of the Black V, to prevent acci- dents. 9 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
- Page 10 Translations in other languages, than Dutch, use the Dutch installation and operating instruction as source document. Hanskamp AgroTech accepts no liability for differences between translations. If there are any doubts about the content and the accuracy of the translated installation and operating instructions, the Dutch installation and operating instructions is the authoritative document.
- Page 11 H.J. Hanskamp Declare entirely under our own responsibility that the product: Black V anti-spill series. Art. nr.: 002-672-000 Concentrate feed dispensing unit for out-of-parlour and VMS milking systems. to which the declaration relates, conforms to the provisions of the following directive(s): Machine Directive 2006/42/EC Annex I art: 1.1.2, 1.1.3, 1.1.5, 1.1.6, 1.2.6, 1.3.1, 1.3.7, 1.3.8.2, 1.4.1, 1.5.1,...
- Page 12 Black V anti-mors Black V anti-spill/anti-verschütt/anti-gaspillage 12 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
- Page 13 12-24V AC/DC Idle current 350 mA Nominal current 360 mA Maximum current 440 mA 22 μF Capacitor Electromotor 28 Rpm Capacity 500-1200 g/min Storage capaciteit Max. 50 kg Rotating direction auger Counter-clockwise 13 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
- Page 14 Black V anti-mors Black V anti-spill/anti-verschütt/anti-gaspillage 14 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
- Page 15 Black V anti-mors Black V anti-spill/anti-verschütt/anti-gaspillage 15 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
- Page 16 PP T-piece 45° 110 mm black 001-808-000 PVC tube 110x3.2mm, 87mm, black 002-017-000 Dosing scale Black V anti-spill 002-018-000 Motor plate plastic Black V anti-spill 002-027-000 Auger left rotating Ø90 002-028-000 Guiding spiral Ø4 011-095-000 RIM motor 28rpm 24V AC with feedback, time-controlled 16 - 17 Hanskamp AgroTech B.V.
- Page 17 Article number Description Fits in system Aantal 011-125-000 RIM pulse motor Lely A4 001-652-000 Intelligent Motor Milking parlour (incl. DeLaval, SAC, Fullwood, Boumatic) 011-021-000 Solid State 5 Nedap 001-001-000 Silver motor GEA/Westfalia 17 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
- Page 18 Black V anti-mors Black V anti-spill/anti-verschütt/anti-gaspillage Hanskamp AgroTech B.V. Broekstraat 17 7009 ZB Doetinchem The Netherlands Please also visit: Tel: +31 (0)314 - 393 797 Fax: +31 (0)314 - 393 826 www.hanskamp.nl 18 - 17 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
