Summary of Contents for Advanced Wireless Communications AWR-D7500
- Page 7 Unpacking and device check Please take the radio out of the package carefully and before disposing of the packing materials, check the accessories according the the following list. If any part is lost or damaged, please submit a claim letter to the carrier or deliverer. Accessories: Items Quantity...
-
Page 13: Charging The Battery
Charging the Battery Use only the charger and battery specified by Advanced Wireless Communications. Charger LED can indicate the charging process. Charger Indicator Indicator Charge Status Red flash Standby Red glows Charging Green glows Fully charged LED Indicator of Transceiver Indicator Charge Status Green glows 2-3S... -
Page 15: Lcd Icons
LCD icons Icon Icon Name Status Description Display Voice operated function. The radio is in an emergency alarm state or Emergency alarm receives an emergency alarm. Battery power Display remaining battery power. Transmitting indicator The radio is transmitting. The radio is receiving signal. Signal indicator No signal. -
Page 16: Working Mode
Product operation instructions Keyboard introduction The AWR-D7500 has three keyboard modes: channel number mode, DTMF mode, and call ID. Users can select different keyboard modes according to their needs, thus achieving simple and fast operation. Channel number mode: After the user selects the channel number mode, the required channel number can be directly written through the keyboard, and the Radio automatically jumps to this channel. - Page 20 4. Programmable function key function There are four programmable function keys that may be defined in software. These buttons are noted as K1, K2, K3, and TK. Programmable buttons can be modified by the CPS. Programmable button function definition list Button Status Button Assignment Function No [unction;...
-
Page 33: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 34 When worn on the body, always place the radio in a approved holder, holster, case, or body harness or by use of the correct clip for this product. Use of non-approved accessories may result in exposure levels which exceed the FCC's occupational/controlled environmental RF exposure limits. ...
