Leviton 54A00-1 Installation Instructions And User Manual

WARNINGS AND CAUTIONS

• Read and understand all instructions. Follow all warnings and instructions marked
on the product.
• Do not use this product near water - e.g., near a tub, wash basin, kitchen sink or
laundry tub, in a wet basement, or near a swimming pool.
• Never push objects of any kind into this product through openings, as they may
touch dangerous voltages.
• SAVE THESE INSTRUCTIONS.

DESCRIPTION

The Model 54A00-1 Leviton Access Control Keypad is a weatherproof and vandal resistant piezoelectric keypad designed to interface with the Leviton line of automation control-
lers. Each valid code can be used to arm and disarm the security system, activate an electric door strike or magnetic locks, activate lighting, operate a garage door, operate a
security gate, set off a panic alarm, and many other functions.
The keypad is encased in a stainless steel investment casting that will complement any décor. It mounts in a single gang switchbox or to the surface of any wall indoors or out-
doors. The keypad has a red LED that is illuminated when the security system is armed and a green LED that is illuminated when it is disarmed.

INSTALLATION

The Model 54A00-1 requires the use of one serial port on the controller and one programmable voltage output.
Run a 4-conductor cable from the controller to the location of the Model 54A00-1 Access Control Keypad and install as follows
NOTES: maximum distance 50 feet.
1. At the keypad location, using the supplied B-GEL water-tight wire splice connectors, connect the black, red, white, and brown wires of the keypad cable (P/N: 54A03-1) to the
corresponding wires of the 4-conductor cable as follows:
Keypad Cable (P/N: 54A03-1)
Black
Red
White
Brown
2. Insert the keypad cable into the connector on the back of the keypad.
3. Install the 54A00-1 to the surface of any wall using the supplied wall anchors and screws or to a single gang switchbox using the supplied machine screws.
4. Adhere the top (with LED cutouts) and bottom (with Leviton logo to bottom right) overlay to the 54A00-1 by removing the backing and pressing into place.
5. At the controller location, connect the black, red, green, and white wires of the keypad communications cable
(P/N: 54A02-1) to the corresponding wires of the 4-conductor cable using the supplied wire splice connectors as shown.
6. Connect the green wire of the keypad communications cable (P/N: 54A02-1) to one of the programmable voltage outputs on the controller as shown. Configure the voltage
output as an "Armed" output
7. Connect the red wire of the keypad communications cable (P/N: 54A02-1) to the Auxiliary 12V output on the controller as shown.
8. Insert the modular connector of the keypad communications cable (P/N: 54A02-1) into one of the serial ports on the controller as shown. Configure the serial port to Pro-Link.

OPERATION

The piezoelectric buttons on the Model 54A00-1 work simply by tapping the surface, and do not require an actual physical movement. The piezoelectric feature means that the
sleek keys can be operated with a bare finger or a snow-covered glove equally well. With the depression of each key, the 54A00-1 will emit a short tone and flash the red LED.
To enter a code, press each digit of the code (up to 10 digits). After the code has been entered, press the '#' key to send the code to the controller for verification. If you make
a mistake while entering the code, press the '*' key to cancel the previously entered digits and start over. If there is a 10 second delay between entering digits, the keypad will
cancel previously entered digits. When a previously entered code has been canceled, either by pressing the '*' key or when there has been a 10 second delay, the 54A00-1 will
emit two short tones and flash the red LED two times.
When connected to an Leviton security system, if the system is armed to a security mode (i.e. Away, Day, Night, Vacation, etc.), the red LED is illuminated. If the security system
is disarmed (i.e. Off mode), the green LED is illuminated.
When connected to a Lumina or Lumina Pro, or if you want a custom function for the LED, you can programmatically illuminate the red or green LED by turning the corresponding
voltage output on and off. When the output is turned on, the red LED is illuminated. When the output is turned off, the green LED is illuminated.

PROGRAMMING

The Leviton controller monitors the serial interface for incoming keypad codes (messages). An incoming code that matches a stored message in the controller can be used to
activate macros (e.g. activate an electric door strike, magnetic locks, lighting, etc.). When a code is matched, the macro corresponding to the matching message is activated. The
keypad is capable of sending up to a 10-digit code to the controller. The controller can store as many codes there are available Messages.
FOR CANADA ONLY
For warranty information and/or product returns, residents of Canada should contact Leviton in writing at Leviton Manufacturing of Canada Ltd to the attention of the Quality
Assurance Department, 165 Hymus Blvd, Pointe-Claire (Quebec), Canada H9R 1E9 or by telephone at 1 800 405-5320.
Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that products manufactured by Leviton under the Leviton brand name ("Product") will be free from defects
in material and workmanship for the time periods indicated below, whichever is shorter: • OmniPro II and Lumina Pro: three (3) years from installation or 42 months from manufacture date.
• OmniLT, Omni IIe, and Lumina: two (2) years from installation or 30 months from manufacture date. • Thermostats, Accessories: two (2) years from installation or 30 months from manufacture date.
• Batteries: Rechargeable batteries in products are warranted for ninety (90) days from date of purchase. Note: Primary (non-rechargeable) batteries shipped in products are not warranted.
Products with Windows Operating Systems: During the warranty period, Leviton will restore corrupted operating systems to factory default at no charge, provided that the product has been used as
®
originally intended. Installation of non-Leviton software or modification of the operating system voids this warranty. Leviton's obligation under this Limited Warranty is limited to the repair or replacement,
at Leviton's option, of Product that fails due to defect in material or workmanship. Leviton reserves the right to replace product under this Limited Warranty with new or remanufactured product.
Leviton will not be responsible for labor costs of removal or reinstallation of Product. The repaired or replaced product is then warranted under the terms of this Limited Warranty for the remainder of
the Limited Warranty time period or ninety (90) days, whichever is longer. This Limited Warranty does not cover PC-based software products. Leviton is not responsible for conditions or applications
beyond Leviton's control. Leviton is not responsible for issues related to improper installation, including failure to follow written Installation and operation instructions, normal wear and
tear, catastrophe, fault or negligence of the user or other problems external to the Product. To view complete warranty and instructions for returning product, please visit us at www.leviton.com.
Use herein of third party trademarks, service marks, trade names, brand names and/or product names are for informational purposes only, are/may be the trademarks of their
respective owners; such use is not meant to imply affiliation, sponsorship, or endorsement.
© 2013 Leviton Mfg. Co., Inc.
ACCESS CONTROL KEYPAD
Cat. No. 54A00-1
Installation Instructions and User's Guide
INSTALLATION
WARNINGS AND CAUTIONS
• Never install communications wiring or components during a lightning storm.
• Never install communications components in wet locations unless the components
are designed specifically for use in wet locations.
• Never touch uninsulated wires or terminals unless the wiring has been
disconnected at the network interface.
• Use caution when installing or modifying communications wiring or components.
4-Conductor Cable
Black
Red
White
Green
LEVITON LIMITED WARRANTY
For Technical Assistance Call: 800-824-3005 - www.leviton.com
DI-021-AX541-00A
AR2243
(54I00-1)
ENGLISH
DI-021-AX541-00A
AR2243
