Summary of Contents for WAREMA Sensor Splitter
- Page 1 Sensor Splitter Installation instructions (Keep for future use) Valid from 01 September 2017 Sun. Light. WAREMA. 2005613_a•en...
- Page 2 Details WAREMA Renkhoff SE Hans-Wilhelm-Renkhoff-Strasse 2 97828 Marktheidenfeld/Main, Ger- many WAREMA and the WAREMA logo are trademarks of WAREMA Renkhoff SE. All other brand or product names included in this document are trade- marks or registered trademarks of their respective owners.
-
Page 3: Table Of Contents
Installation ...................... 10 Mounting the device ..................11 Connection ..................... 12 Connection information ..................12 Bus lines ......................13 Hardware settings on the sensor splitter ............14 Wiring diagrams ..................... 16 Connecting the Wisotronic ................18 ® Connecting the WAREMA climatronic ............ -
Page 4: Features
"listen". The devices can be mutually connected via a separate RS485 bus. The sensor splitter makes 24 V DC/250 mA available on the bus on the sen- sor side (sufficient for one weather station). If multiple weather stations are connected, they need to be supplied by a separate power supply unit. -
Page 5: Safety Instructions
Sensor Splitter 2 Safety instructions We developed and tested the sensor splitter in compliance with the basic safety requirements. Residual risks nevertheless remain! For this reason, please read these instructions before commissioning and operating the control. It is very important to adhere to the safety information listed here and the warning information in these instructions. - Page 6 Sensor Splitter The following pictograms and symbols may be affixed to the control itself or to the connected devices, alerting you to potential danger: WARNING Warning against dangerous electrical voltage! CAUTION Component damage due to electrostatic discharge! NTTE The term NTTE marks important information and helpful tips.
-
Page 7: Intended Use
Sensor Splitter 2.2 Intended use The sensor splitter is an electronic device that is used to connect up to three weather stations or Sensor Interfaces to multiple WAREMA climatronic ® con- trol panels or to connect one weather station multisense to multiple Wisotron- ic control panels at the same time. -
Page 8: Mounting, Connection And Repairs
Sensor Splitter 2.5 Mounting, connection and repairs DANGER Danger to life through electrical voltage! Connecting, maintenance or repair work on the electrical parts of the entire system must only be performed when power to the system has been cut off, unless otherwise described. -
Page 9: Additional Documents
Sensor Splitter 2.6 Additional documents When performing the installation, follow the separate instructions of the com- ponents being connected. 2.7 Maintenance There are no parts within the device that require maintenance. 2.8 Liability Failure to comply with the product information in these instructions and use... -
Page 10: Installation
Sensor Splitter 3 Installation This chapter will tell you where and how the individual components must be installed. WARNING Dangerous situations and malfunctions are possible! The device and its auEiliary components may only be operated when installed and at the specified installation locations. -
Page 11: Mounting The Device
The minimum distance between the terminals and another object equals 10 mm. The devices can be mounted by simply clipping them onto the DIN rail. Fig. 2 Sensor splitter in a 3 MW DIN rail-mounted housing 54 mm 3 TE 60 mm Fig. -
Page 12: Connection
230 V AC lines (power lines) should not be routed between the DIN rail and rear wall but to one side at as great a distance as possible. The external +24-V voltage provided by the sensor splitter is exclusively in- tended for supplying a connected weather station. If other weather stations are connected, they need to be supplied by a separate power supply unit. -
Page 13: Bus Lines
Sensor Splitter 4.2 Bus lines CAUTION Only make changes to the bus wiring while the unit is in a de-energised state. Several basic principles must be observed to ensure fault-free bus communi- cation. Do not accidentally swap the connections of the bus of the central control... -
Page 14: Hardware Settings On The Sensor Splitter
This sensor splitter must be set as a MASTER using the encoding switches on the board of the sensor splitter. By default, all encoding switches are in the OFF posi- tion. - Page 15 Sensor Splitter 2005613_a•en•2017-09-01 We reserve the right to carry out improvements...
-
Page 16: Wiring Diagrams
Sensor Splitter 5 Wiring diagrams Terminals X11 Encoding Bus connection switch S2 for the weather 24V 0V B1 A1 Definition of the stations master, Disabling of addresses Terminals X10 1 2 3 4 Power supply for weather station (max. 250 mA) - Page 17 Sensor Splitter Terminal Designa- Terminal Comment block tion Bus of central control unit (4 inputs) Power supply of sensor splitter 24 V Communication (RS485) Commissioning Push button Prog ID No function Flashes during active bus communication with LTED the connected central control unit...
-
Page 18: Connecting The Wisotronic
The sensor splitter to which the weather station multisense is connected must be supplied via a separate power supply unit. If possible, always connect the weather station to the sensor splitter that is acting as the MASTER. Provide separate on-site fuse protection for the sepa- rate power supply unit. - Page 19 Sensor Splitter Fig. 9 Connection example for Wisotronic 2005613_a•en•2017-09-01 We reserve the right to carry out improvements...
-
Page 20: Connecting The Warema Climatronic
Fig. 11. Please note the following special features when connecting the unit: The sensor splitter to which the weather station is connected must be sup- plied via a separate power supply unit. If possible, always connect the weather station to the sensor splitter that is acting as the MASTER. - Page 21 Sensor Splitter Fig. 11 Connection example for WAREMA climatronic ® 2005613_a•en•2017-09-01 We reserve the right to carry out improvements...
-
Page 22: Connecting A Separate Power Supply Unit
NTTE The sensor splitter MASTER and the weather stations should always have their own power supply unit. Providing a separate power supply unit with its own on-site fuse protection ensures that weather data will always be sent to the sensor bus. -
Page 23: Connecting A Sensor Interface
1 2 3 4 1 2 3 4 24V 0V B1 A1 24V 0V B1 A1 Fig. 13 Use of a WAREMA climatronic ® Sensor Interface (only in units with a WAREMA climatronic ® 2005613_a•en•2017-09-01 We reserve the right to carry out improvements... -
Page 24: Connecting Multiple Weather Stations
Total length of the RS485 bus: maximum 1200 m. The bus voltage must be at least 20 V at each device. The sensor splitter MASTER must be supplied via a separate power supply unit. The maximum line length between the weather station and the sensor splitter MASTER is 200 m. -
Page 25: Commissioning
NTTE The power supply can also be switched on simultaneously for the entire unit. If the power supply of the weather station and sensor splitter MASTER is switched on later, it will not be possible to correctly commission the unit. -
Page 26: Procedure For Warema Climatronic
Separate the bus line in such a way that the bus of the weather station (sen- sor bus) is only connected with the bus of the first climatronic (climabus 1) (Fig. 15, 2 ). The sensor splitter is completely separated from the bus and the bus lines are directly connected to each other. - Page 27 Sensor Splitter Weather station Sensor bus Sensor splitter 1 Sensor splitter 2 Output state or MASTER SLAVE final state of bus wiring BK RD BK RD climabus 1 climabus 2 climatronic 1 climatronic 2 = Terminating resistor Weather station Sensor bus...
-
Page 28: Technical Data
EN 62233:2008 Miscellaneous Location of use Clean ambient conditions Conformity Viewable under www.warema.com Ambient conditions Operating temperature °C Storage temperature °C Rel. humidity (non-condensing) Article number Sensor Splitter REG 2005 604 We reserve the right to carry out improvements 2005613_a•en•2017-09-01... -
Page 29: Troubleshooting
Encoding switch S2:1 set to OFF on all Set the encoding switch S2:1 to ON on sensor splitters one sensor splitter. The sensor splitter MASTER is not ac- Switch on the power supply for the tive. No measuring values are queried sensor splitter MASTER. -
Page 30: Replacement Of A Weather Station Multisense On The Wisotronic
Sensor Splitter 8.2 Replacement of a weather station multisense on the Wisotronic Proceed as follows to replace a faulty weather station multisense. Switch off the power supply of the weather station multisense. Replace the weather station multisense. Switch the power supply of the weather station multisense back on. -
Page 31: Replacement Of A Weather Station On The Warema Climatronic
Separate the bus line in such a way that the bus of the weather station (sen- sor bus) is only connected with the bus of the first climatronic (climabus 1) (Fig. 15, 2 ). The sensor splitter is completely separated from the bus and the bus lines are directly connected to each other. - Page 32 KEEP IN A SAFE PLACE FOR COMMISSIONING Note down installation location here Notes on commissioning (e.g. special features of installation location, wiring, etc.): WAREMA Renkhoff SE http://www.warema.de info@warema.de Hans-Wilhelm-Renkhoff-Strasse 2 97828 Marktheidenfeld/Main, Germany...
