5000-sc cleaning solution transport unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
200-Tb
5000-Sc Cleaning Solution Transport Unit
200-Tb Operator (0000000000000-3232247603137)
English Operator Manual
EN
North America
DM20017
Rev. 01 (01-2012)
www.orbiotechnologies.com
Home
Find... Go To..

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 200-Tb and is the answer not in the manual?

Questions and answers

Summary of Contents for Tennant 200-Tb

  • Page 1 200-Tb 5000-Sc Cleaning Solution Transport Unit 200-Tb Operator (0000000000000-3232247603137) English Operator Manual North America DM20017 Rev. 01 (01-2012) www.orbiotechnologies.com Home Find... Go To..
  • Page 2 Minneapolis, MN 55440 Phone: (800) 553-8033 Phone: (763) 513-2850 www.orbiotechnologies.com and parts are subject to change without notice. Original Instructions, copyright © 2012 Orbio Technologies from TENNANT COMPANY, Printed in US. All rights reserved. 200-Tb DM20017 (01-2012) Home Find... Go To..

  • Page 3: Table Of Contents

    Components ............6 Cleaning Solution ........... 7 Requirements ............7 Operating Instructions..........8 Charging Instructions........8 Filling Unit ............10 Solution Transfer ..........10 Troubleshooting ............ 11 ............11 Electrical Diagram ..........11 Warranty..........Back Cover 200-Tb DM20017 (01-2012) Home Find... Go To..

  • Page 4: Intended Use

    Follow safety instructions of chemical manufacturer (MSDS). • Do not mix 5000-Sc cleaning solution with conventional cleaning chemicals. Do not drink cleaning solution. • Refer to MSDS (Material Safety Data Sheet) for • additional safety information and precautions. 200-Tb DM20017 (01-2012) Home Find... Go To..

  • Page 5: Safety Labels

    The safety labels appear on the equipment in the locations indicated. Replace damaged labels. FOR SAFETY: Do not operate machine unless operator manual is read and understood. WARNING: Do not push on inclines. 2% maximum grade. 200-Tb DM20017 (01-2012) Home Find... Go To..

  • Page 6: Components

    OPERATION COMPONENTS Tank Lid Dispensing Nozzle Wheel Lock Battery Level Gauge Toggle Switch Battery Box Discharge Hose Charging Cord 200-Tb DM20017 (01-2012) Home Find... Go To..

  • Page 7: Cleaning Solution

    NOTE: The temperature for the room / location where the 5000-Sc cleaning solution is stored should be between 50- 110°F (10° to 43°C). REQUIREMENTS • 120 VAC outlet for charger in a dry location. 200-Tb DM20017 (01-2012) Home Find... Go To..

  • Page 8: Operating Instructions

    12V GFI protected circuit in an area designated for charging. Use the enclosed screws or other fasteners appropriate for your wall type. 3. Remove the battery box cover. This bracket should be mounted within 70” (178 cm) of the electrical outlet. 200-Tb DM20017 (01-2012) Home Find... Go To..
  • Page 9 9. Green light indicates that charging is complete. 6. Ensure charger is fully connected. 10. Disconnect charger and reconnect battery. 7. Yellow light on charger indicates unit is charging. 11. Replace and secure battery box cover. 200-Tb DM20017 (01-2012) Home Find... Go To..

  • Page 10: Filling Unit

    3. Close tank lid. Make sure lid is secured. 3. Place dispensing nozzle into reservoir to be and squeeze trigger to dispense solution until full. FOR SAFETY: Wipe up any spills. FOR SAFETY: Wipe up any spills. 200-Tb DM20017 (01-2012) Home Find... Go To..

  • Page 11: Troubleshooting

    Dispensed Volume per 1000 gallon Charge (3785 liters) Battery Recharge Time 8 -10 hours from 80% Discharge ELECTRICAL DIAGRAM POSITIVE LEAD (RED) FUSE PRESSURE SWITCH PUMP MOTOR TOGGLE SWITCH NEGATIVE LEAD (BLACK) BATTERY METER 200-Tb DM20017 (01-2012) Home Find... Go To..

  • Page 12: Warranty

    If proof of purchase is unavailable, the warranty begins ninety (90) days after original sale to an Authorized Tennant dealer. LABOR AND TRAVEL WARRANTY During the warranty period, Tennant will, at its option, provide labor or pay for outside repair. Travel is excluded from warranty coverage. PARTS WARRANTY Parts replaced or repaired under this warranty are guaranteed for the remainder of the warranty period.
  • Page 13 Internal Use Only Date Received: MACHINE INSTALLATION / WARRANTY REPORT IMPORTANT: Please fill out completely and return to Tennant Company within 30 days of purchase to ensure full warranty protection. Billing Address: Machine Model/Serial Number Same as Machine Location Customer #: __________________ (If known)
