Summary of Contents for Galvanic Applied Sciences Monitek AT3
- Page 1 MONITEK MODEL AT3 PARTICLE CONTAMINATION MONITOR Operating/Installation Manual P/N 0901-0655-00 October 2019 101 Billerica Avenue Bldg 5, Ste104, Tel: 978-848-2701 North Billerica, MA 01862, USA Toll Free:1.866.254.5420 www.galvanic.com Email: support@galvanic.com...
- Page 2 MONITEK TECHNICAL NOTE MODEL: AT3 Operational Note: Section 3: Calibration Procedure CAUTION: It has come to our attention that in some experiments with calibration plots containing high sample concentration values and plotted in 3 and 4 order poly, a memory overflow condition may occur with the calculated coefficient data, causing a “CPU”...
- Page 3 LONG TERM STORAGE If for any reason this instrument will not be installed within thirty (30) days after receiving it, it is suggested that it remain in its sealed shipping container and stored in a clean, dry and protected area until time of installation. If the instrument has already been unpacked for inspection or testing, or if it has been removed from a process, and it is not to be installed or reinstalled for a period exceeding thirty (30) days, the following procedure should be observed:...
-
Page 4: Table Of Contents
TABLE OF CONTENTS SECTION I – INTRODUCTION OVERVIEW………………………………………………………………………………………………….. 1-1 THE FRONT PANEL……………………………………………………………………………………….. INSTRUMENT OUTPUTS…………………………………………………………………………...……. USER CARE………………………………………………………………………………………………… SECTION II – INSTALLATION SYSTEM INSPECTION……………………………………………………………………………………. POWER REQUIREMENTS……………………………………………………………………………….. CIRCUIT BREAKER……………………………………………………………………………………….. SENSOR INSTALLATION………………………………………………………………………………… SENSOR LOCATION…………………………………………………………………………………...…. SYSTEM INSTALLATION SITE…………………………………………………………………………... CONNECTING THE CABLES…………………………………………………………………………..AT3 INSTALLATION CHECK-OUT REPORT……………………………………………………...…… SECTION III –... -
Page 5: Section I - Introduction
SECTION I – INTRODUCTION OVERVIEW The AT3 monitor is a microprocessor based, real-time, in-line instrument used to monitor liquid-borne particle concentration and oil contaminants in various process liquids. Use of the microprocessor and graphics display provides a user friendly interface for setup and calibration. Because it is acoustically based, Monitek’s patented transducer measures independent of the liquid’s color, opacity, density, flowrate or photosensitivity. - Page 6 Figure 1-1: Typical Return Reflections from Oscilloscope Trace. The far wall pulses and the main bang, although not counted, provide an indication of the operating characteristics of the transducer. Changes in these signals may indicate a transducer problem. At 128 times a second the AT3 sends out a burst of energy into the process liquid, turns around and listens for echoes that return to the transducer, and then analyzes the data to determine a measurement.
-
Page 7: The Front Panel
THE FRONT PANEL The AT3 uses a 240 x 64 dot liquid crystal graphics display in conjunction with a 24 key keypad as a user interface. See Figure 1-2. Three keys on the left and three on the right of the display are “soft”, having different functions depending on what appears adjacent to them on the display. -
Page 8: Section Ii - Installation
SECTION II – INSTALLATION SYSTEM INSPECTION Check to ensure that all components of the AT3 monitor have arrived safely. Included should be: the AT3 system electronics, sensor, and cable set. If there is any damage to the equipment or if anything is missing, please contact the Monitek sales representative immediately. -
Page 9: System Installation Site
Slide probe back until safety cable is taut. Tighten Swage-Lok fitting. CAUTION: Galvanic Applied Sciences USA Inc. recommends that our AS3 probe should not exceed operating temperature of 80ºC without air cooling or 110ºC with air cooling. With the insertable probe configuration, the preamplifier and explosion proof enclosure are an integral part of the probe. - Page 10 FLOW )PAIR OF RG/8 CABLES PER SENSOR ASSY 1 BNC-BNC 10-15 1 N-N DIAMETERS PIPE DIAMETERS FLOW Figure 2-1: Typical Sensor Assembly Placement and Installation. MODEL AT3 2 – 3...
-
Page 11: Connecting The Cables
←---------------------------------------- X --------------------------------→ ↑ ↓ Figure 2-2: SYSTEM ENCLOSURE MOUNTING PATTERN Table 3-1: Window Width Guideline. ENCLOSURE TYPE X (INCHES) Y (INCHES) NEMA4X, PLASTIC 12.00 18.90 8.00 ACROSS END HOLES OF TOP AND BOTTOM BRACKET. NEMA 4X, STAINLESS STEEL 16.75 2.50 ACROSS TWO MIDDLE HOLES OF SAME BRACKETS NEMA7, EXPLOSION PROOF... -
Page 12: At3 Installation Check-Out Report
AT3 INSTALLATION CHECK-OUT REPORT 1) Customer and location: 2) Installation date: 3) AT3 serial number and operating frequency: 4) Preamplifier serial number: 5) Transducer serial number: 6) Transducer lens material: 7) Chamber description (size and material): 8) Cable length (feet): 9) Liquid description: 10) Noise without pulse (mVolts RMS): 11) Main Bang duration (µsec):... -
Page 13: Section Iii - Operation
SECTION III – OPERATION INTRODUCTION Once the system has been installed, the hardware must be set up for your particular application, and checked to ensure that it is operating properly. The system operates by sending out a 5 or 15 MHz RF pulse (depending of sensor type) to the transducer, where it is converted to an acoustic pulse. - Page 14 "CALIBRATION" Used to correlate raw data coming from the sensor to a corresponding concentration. Up to 16 different samples can be read by the instrument. From this information the instrument can construct a lookup table or perform a polynomial fit of degrees 1 to 4. The user can graphically plot the resulting curvefit to visually check how it corresponds to the samples.
-
Page 15: Menu Operation
MENU OPERATION All menu choices can be modified or activated merely by pressing the button corresponding to the menu item. If a screen contains more than six menu items the choice "<More>" will appear as the lower right menu choice, and pressing this will take the user to the next page of choices. See Figure 3- <2. - Page 16 Option list items, when pressed, allow the user to choose from a list of possible options. The user selects the desired option by pressing its corresponding button. The currently selected option is shown In inverse characters At any time "MAIN MENU" can be pressed to go back to the main menu screen. If "MAIN MENU" is pressed when already in the main menu screen, the instrument will return to the top screen (showing the instrument reading and the bar graph).
-
Page 17: Quick Start Up
QUICK START UP The "SETUP" menu. The parameters that can be chosen are: units (use the arrows), the resolution of the main display in digits to the right of the decimal point, and the instrument damping. See Figure 3-5. The "Display" menu allows the user to set the top screen to display "Raw Data"... - Page 18 2. The "Measurement Setup" menu. These are parameters that intimately affect the measurement and must be set before samples are taken. See Figure 3-8. If any of these are changed after samples have been taken, the measurement environment is different enough that the previous samples are no longer valid.
- Page 19 2.c. The "Threshold" value needs to be set above the noise yet not so high that echoes are not seen at all. NOTE: For concentration measurement, a good rule of thumb is to set the "Threshold" so that the typical process concentration gives a reading of 2000 counts (the total range is 0 to 5000).
- Page 20 3.a. Press "SAMPLE TABLE" and you will see a summary of the 16 samples. See Figure 3-12. If a sample has not been entered yet, it will read "INACTIVE". Otherwise it will display the raw data and corresponding concentration for the sample. The instrument prompts the user for a sample number (1 to 16), which is entered by the keypad.
- Page 21 3.b. The user must decide what type of curve fitting to perform on the data, and this Is done in the "Cal Type" menu. See Figure 3-15. Lookup Table Best Fit Line Cal Type: Best Fit Parabola Degree Poly 4 Degree Poly Figure 3-15: Cal Type Menu 3.c.
- Page 22 Table 3.2: Calibration Type and Number of Active Samples Required. NOTE: The user can try many different types of “Cal Types”; however, a “Fit Sample Data” must be done after any change to update the calibration. See Figure 3-17. If only a portion of the curve is of interest, the user can go into the “Partial Plot” menu and choose the desired range to plot (by specifying the Low and High X values).
- Page 23 MODEL AT3 3 – 11...
- Page 24 4. The “ANALOG OUTPUT” menu consists of the parameters to perform the Analog Output Test. See Figure 3-19. Zero: X.XXX PPM Range: 4 to 20 mA ANALOG OUTPUT Span: XXX.X PPM Figure 3-19: Calibration Menu Press “RANGE” to select the output analog current range (i.e., 4 to 20 mA). 4.b.
-
Page 25: At3/As3 Sample Calibration Procedure
AT3/ AS3 SAMPLE CALIBRATION PROCEDURE Sample 0-1000 ppm for 5 mhz and 15mhz systems using diatomaceous earth typically using 5 calibration points. Steps: 1. Mix 2.0 grams of diatomaceous into 2 liters of DI water. This will be 100% of range (1000ppm). 2. -
Page 26: Section Iv Maintenance
SECTION IV MAINTENANCE GENERAL SYSTEM CLEANING: Disengage the A T3 from its power source before any cleaning. The unit can be cleaned with a soft cloth dampened with water. A mild detergent may be used if necessary. Do not allow water inside the unit. Also be sure that no water remains near the power connections to eliminate the possibility of electrical shock. -
Page 27: Glossary Of Terms
SECTION V APPENDIX GLOSSARY OF TERMS Chamber: The short piece of piping in which the AT3 transducer is positioned (see sensor). Detection threshold: The level that the signal from an acoustic reflection must exceed before it Is counted by the receiver. A number from 1 to 255, it is usually shortened to DT. Far wall pulse: Acoustic reflections from the inside diameter of the pipe opposite the transducer. -
Page 28: Application After Dissolved Air Flotation (Daf) Equipment
APPLICATION AFTER DISSOLVED AIR FLOTATION (OAF) EQUIPMENT Dissolved air flotation devices such as Wemcos Introduce a considerable amount of entrained air to the process stream. These bubbles of entrained air will reflect acoustic energy In the same way a particle or oil droplet will. -
Page 29: Spare Parts List - Particle Contamination Monitor, Model At3
SPARE PARTS LIST – PARTICLE CONTAMINATION MONITOR, MODEL AT3 DESCRIPTION PART NUMBER Motherboard 4805-0020-10 Receiver Board 4805-0022-10 Pulser Board 4805-0021-10 I/O Board 4805-0023-10 CPU Board 3000-1050-11 Power Supply C609-0020-00 DC Power Cable 4805-0096-00 Cable Assy, Ribbon, AT3 4805-0055-00 Cable Assy, Coax - A, AT3 4805-0056-00 Cable Assy, Coax - B, AT3 4805-0057-00... -
Page 30: Electrical Wiring Diagram
ELECTRICAL WIRING DIAGRAM MODEL AT3 5 – 4... -
Page 31: Section Vi - Specifications & Warranty
SECTION VI – SPECIFICATIONS AND WARRANTY AT3 ACOUSTIC TRANSMITTER (SUSPENDED SOLIDS MONITOR) SUMMARY OF FEATURES • Focused acoustic energy is resistant to coatings • Monitors panicles in light-sensitive liquids • Insensitive to optically opaque liquids. like dyes & inks • Virtually maintenance free The AT3 transmitter is a microprocessor-based, online instrument used to monitor liquid-borne... -
Page 32: As3 Insertable Probe
AS3 INSERTABLE PROBE The AS3 insertable probe is an in-line device which uses pulsed, focused ultrasound to detect particles, bubbles and suspended droplets in a variety of flowing liquids. It operates in the • pulsed-echo mode. The ultrasonic frequency • is generated by a piezoelectric crystal that converts electrical... - Page 33 Manufacturer’s Warranty Statement Galvanic Applied Sciences Inc. (“Seller”) warrants that its products will be free from defects in materials and workmanship under normal use and service in general process conditions for 12 months from the date of Product start-up or 18 months from the date of shipping from Seller’s production facility, whichever comes first (the “Warranty Period”).
- Page 34 • Products that have been subject to misuse, neglect, accident, or improper installation. • The sole and exclusive warranty applicable to software and firmware products provided by Seller for use with a processor internal or external to the Product will be as follows: Seller warrants that such software and firmware will conform to Seller’s program manuals or other publicly available documentation made available by Seller current at the time of shipment to Buyer when properly installed on that processor, provided however that Seller does not warrant the operation of the...
