Summary of Contents for Hyperion HYP-SB4R-B
- Page 1 NSTALLATION UIDE YPERION TROBE BAR HYP-SB4R-B Hyperion Wireless Strobe Bar Installation www.wrensolutions.com 7L779 Rev A 200325 Guide...
- Page 2 BOUT THIS OCUMENT OTICES This document pertains to installation of the Hyperion Strobe Bar (HYP-SB4R-B). Before installation, please familiarize yourself with this RF Exposure for FCC installation guide and review the Hyperion User Guide to understand WARNING: To satisfy FCC RF exposure requirements for mobile system configuration and setup.
-
Page 3: Component List
WIRING STANDARD AND ALL CABLES SHOULD BE TESTED BEFORE MPROPER CABLING COULD DAMAGE THE GATEWAY AND VOID PRODUCT WARRANTY DENTIFY MOUNTING LOCATION Mounting Surface The HYP-SB4R-B should be mounted to a structurally solid wall or ceiling surface. Mounting Height The minimum recommended mounting height for this device is 8’... - Page 4 ADIO MOUNTING LOCATION Mounting Surface The Hyperion Radio should be mounted indoors to a structurally solid surface. When selecting a mounting location, take care to ensure that there are no obstructions, especially solid metal surfaces in the immediate vicinity of the radio and antenna. We suggest a minimum 3 foot zone surrounding the area.
-
Page 5: Mounting The Device
Attach the antenna to the radio and position for maximum reception. NOTE: • BSTRUCTIONS WILL NEGATIVELY IMPACT RADIO PERFORMANCE • NSURE THAT THERE ARE NO OBSTRUCTIONS ESPECIALLY METAL NEAR THE YPERION RADIO OR ANTENNA Hyperion Wireless Strobe Bar Installation www.wrensolutions.com 7L779 Rev A 200325 Guide... - Page 6 Cabling should be minimum CAT5 rated and at least 24AWG. Cabling Procedure Run a length of CAT5 or greater cabling from IHYP-PP180R-B to the Hyperion Radio. Crimp RJ45 connectors to each end of the ca- ble run if needed. Certify that the cabling meets the T-568A standard.
-
Page 7: Connecting Devices
Connect the CAT5 cabling to the device and to the radio. radio EVICE TO THE GATEWAY The device is now powered on and ready to be added to Hyperion. Refer to the Hyperion User Manual for setup details. Hyperion Wireless Strobe Bar Installation www.wrensolutions.com...
