foras Belmont Pebble Pool Luminar Instructions

The Belmont Pebble Pool Luminar water feature is available in two sizes: 30cm or 40cm
ball. The kit can be used recessed into a flower bed or incorporated into a patio.

Belmont Pebble Pool Luminar Water Feature Kit

The kit contains: 65cm reservoir, pump 800 litres per
hour with 10m of cable, plug, 20mm water pipe,
Luminar nozzle, stone ball and a 25kg bag of pebbles.
Check the kit before installation.
The Pebble Pool can be installed above ground (with a
brick surround) or below ground as per our diagrams.
There are some important details that need to be
followed. Please read the instructions carefully before
installation, if you are unsure of any details please
contact local stockist or Foras team for further help.
1: Having installed the reservoir into the ground,
follow our step by step guide for installation.
2: Place the pump in the reservoir, then run the power cable up and over the lip of the reservoir and out to the
required power supply (this could be fed through an underground pipe that leads to the feature from a power
source). Fit the reservoir top in place leaving the inspection hatch off. Place the support ring on the reservoir.
Feed the 20mm water pipe down through the ring and down into the reservoir connecting to the outlet on the
pump. Place some packaging or a wooden block on the lip of the reservoir to protect it when moving the ball.
See diagram A.
A
Cont:-
