Summary of Contents for Termoventiler LADDOMAT 11-30 125
- Page 1 ® LADDOMAT 11-30 125 User and installation instructions LM11-30 125_Manual.indd 88110001 151021...
- Page 2 +49 (0) 3722 - 505 702 info@termoventiler.de www.laddomat.de EC – Declaration of conformity: Laddomat 11-30 125, as delivered, is CE-certifi ed according to relevant provisions. All high effi ciency pumps applies to European directive for energy related products. ErP 2009/125/EC...
- Page 3 ® LADDOMAT 11-30 125 Technical data Thermostat cartridge: 45°, 53°, 57°, 63°, 66°, 72°, 78°, 83° or 87°C Pump: 6 m ErP , 180 mm Connection: 2 x R25 Max. boiler output: 35 kW Kvs-value: 3,4 m³/h Pressure class: PN 6 Max.
- Page 4 Start up phase Laddomat 11-30 enables the boiler to attain working temperature in a very short space of time. This improves boiler effi ciency. During the start up phase, the water is only circulating internally in the boiler Aufheizphase Laddomat 11-30 sorgt dafür, dass der Kessel sehr schnell die Betriebs-temperatur erreicht.
- Page 5 Connection Shut off valves are to facilitate servicing. The installation position does not affect the function of Laddomat 11-30 125, but the lines must be connected to the correct port on the valve. Einbau Die Kugelhähne (KH) sind montiert, um die Wartung zu erleichtern.
-
Page 6: Spare Parts
Spare parts Pos. Art. No. Description 211100XX Laddomat 11-30, XX°C, incl. PF 110007 Gasket kit for Laddomat 11-30 125 146016 Pump Wilo Yonos Para 6, 180 mm 141021 Ball valve R40-R25 141020 Ball valve R40-R25, with built-in check valve 383005... - Page 7 Pump instruction PE N...
