Artec Avenue 50 Quick Start Manual

BLOCK DIAGRAM

GAIN BASS
GAIN BASS
LEVEL GAIN GAIN BASS
DRIVE

SETTING GUIDE

Gain setting Drive setting
Humbucker or
active pickup
Single pickup
General
microphone
Preamp equipped
Acoustic guitar
CD / MP3 IN
MIDDLE TREBLE
REC OUT
/ PHONE
MASTER
VOLUME
POWER
AMP***
MIDDLE TREBLE
MIDDLE TREBLE TIME
MIXER REVERB
FOOT SW
Reverb setting
Heavy Metal
Blues O.D
Rock
Distortion
Crunch
Distortion
SPEAKER
LEVEL
Reverb
Room reverb
Hall reverb
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
IMPORTANT SAFETY INSTRUCTIONS
- DO NOT OPERATE NEAR ANY HEAT SOURCE AND DO NOT BLOCK ANY VENTILATION OPENINGS ON THIS APPARATUS.
- ONLY CONNECT POWER CORD TO A POLARIZED, SAFETY GROUNDED OUTLET WIRED TO CURRENT ELECTRICAL CODES
AND COMPATIBLE WITH VOLTAGE, POWER, AND FREQUENCY REQUIREMENTS STATED ON THE REAR PANEL OF THE
APPARATUS.
- ONLY USE ATTACHMENTS, ACCESSORIES, STANDS, OR BRACKETS SPECIFIED BY THE MANUFACTURER FOR SAFE
OPERATION AND TO AVOID INJURY.
- WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
- SERVICE MUST BE PERFORMED BY QUALIFIED PERSONNEL.
- OUR AMPLIFIERS ARE CAPABLE OF PRODUCING HIGH SOUND PRESSURE LEVELS. CONTINUED EXPOSURE TO HIGH
SOUND PRESSURE LEVELS CAN CAUSE PERMANENT HEARING IMPAIRMENT OR LOSS. USER CAUTION IS ADVISED AND
EAR PROTECTION IS RECOMMENDED IF UNIT IS OPERATED AT HIGH VOLUME.
DC POWERED
STREET BAND
AMPLIFIER
