LBWA1U5YR1
IC No. of this product is as follows.
IC :772C-LBYR650
For OEM integration only – device cannot be sold to general public.
Therefore we will ask OEM to include the following statements required
by IC on the product and in the Installation manual Notice.
Contents
1.Land Pattern(Recommended)
Installation Manual
2013/04/25
1
Advertisement
Table of Contents
Summary of Contents for Murata LBWA1U5YR1
- Page 1 2013/04/25 LBWA1U5YR1 Installation Manual IC No. of this product is as follows. IC :772C-LBYR650 For OEM integration only – device cannot be sold to general public. Therefore we will ask OEM to include the following statements required by IC on the product and in the Installation manual Notice.
- Page 2 2013/04/25 2. Supply Voltage Typ. [V] Min. [V] Max. [V] VBUS Please supply a stabilized power supply voltage through the VBUS. Pin configuration by the side of a module. Terminal Name Kind Remarks Power Supply VBUS Power Supply VBUS Data transfer signal D－...
- Page 3 3. Antenna ■Please perform the antenna design that followed the specifications of the antenna. Antenna with a 50-ohm coaxial cable Manufacturer： Murata Manufacturing Co,. Ltd. Type name: ANZM12G44SNK001TD1 Coaxial cable connects with a pattern antenna with soldering. The side opposite to is connector connection.
- Page 4 2013/04/25 4. Notice Please describe the following warning on the final product which contains this module. Contains Transmitter Mobile IC:772C-LBYR650 Contains IC:772C-LBYR650 Please describe the following warning to the manual. Please describe a mark requirement and minimum product operation procedure by both English and French...
- Page 5 2013/04/25 Please describe the following warning to the manual. When an antenna can remove by an end user ( IC:772C-LBYR650 Model : LBWA1U5YR1 ) Antenna type: Monopole antenna (pattern) Gain: -2.7dBi ( IC:772C-LBYR650 Model : LBWA1U5YR1 ) Antenna type: Monopole antenna (pattern) Gain: -2.7dBi...
- Page 6 2013/04/25 Please describe the following warning to the manual. When installing it in a mobile equipment When installing it in a portable equipment Please describe a mark requirement and minimum product operation procedure by both English and French Note) Portable equipment : Equipment for which the spaces between human body and antenna are used within 20cm. Mobile equipment : Equipment used at position in which the spaces between human body and antenna exceeded 20cm.
