Hyperdyne Labs Vortex 3 Instructions

Vortex 3 Voice Changing Module Instructions
The Vortex 3 documentation can be found at:
http://www.hyperdynelabs.com/docs/v3/
Please print out the documentation file commensurate with the voice effect you
The documents are in Adobe PDF format, so you will need the free Acrobat reader available from
Your kit was manufactured using the highest-grade components available, please handle it with care as
not to damage any of the components from static electricity. If you are not familiar with static electricity
handling procedures, please refer to ESD procedures. Basic information on ESD can be found here:

QUICKSTART connection guide

9V battery or 6AA
on/off
switch
Mic in
(mono)
Email: shima@hyperdynelabs.com
NOTICE: There is no warranty on kits. It is your responsibility to install the board. Opened kits cannot be returned. Be
careful if you plan to use a battery source that is capable of delivering alot of current. Contact a professional if you need
assistance. Hyperdyne Labs assumes no responsibility for the misuse of this kit.
Hyperdyne Labs, © 2001-2016
http://www.hyperdynelabs.com
purchased.
www.adobe.com
http://en.wikipedia.org/wiki/Electrostatic_discharge
pack
Vortex 3 board (top view)
pwr hdr
PROG button
STAT PTT
if you are having difficulties setting up the unit.
ACT
PTT remote
pushbutton cable
Amplified speaker
setup (stereo)
