Summary of Contents for Furun Medical NONE Insertion Biofeedback HnJ-350

  • Page 2 Patent HnJ-350 has co-developed by Furunmedical Co.,Ltd. and professors in university and doctors in the hospital. It is high-tech device and has patents. Anyone who infringe the patent, will be subjected to legal penalty. User Manual Thank you for your purchasing HnJ-350. For the safety and proper operation, it is described for the function of each mode, operation method and maintenance in this user manual.

  • Page 3: Appendix. Warranty

    C o n t e n t s 1. Safety precautions 2. Introduction 2-1. Pelvic floor muscle exercise(Kegel Ex) 2-2. Specification 2-3. Contraindication 2-4. Components and the parts 2-5. Specification 3. Operations of the product 3-1. Installing application 3-2. Operating application 3-3.

  • Page 4: Warnings And Cautions

    1. Safety The manufacturer or distributor doesn’t have a responsibility on damages or impairs caused by improper use or management of the device by the user. 1-1. Warnings and Cautions In case of ignoring Warning”, it may cause critical damages or impairs. “...
  • Page 5 Disconnect the cable when do not use the machine for long time. You can use the machine safely. Do not disassemble, modify, repair except the authorized person only. For the repair service, please contact the dealer or manufacturer you purchased, or refer to the user manual.

  • Page 6: Specification

    Introduction 2-1. Pelvic floor muscle exercise (Kegel Exercise) Kegel exercises strengthen the muscles of the pelvic floor, the "hammock" of muscles that control the flow of urine and hold the pelvic organs in place. Weakness in the pelvic floor muscles can cause bladder control problems (urinary incontinence) or the sagging of some pelvic organ specially after childbirth.
  • Page 7 2-4. Notes during exercise 1) If any abnormality is founded during exercise from the user, please stop operation and guide the patient to comfortable situation and consult with your doctor. 2) If the skin turns red during use or after use, if any side effects such as inflammation, skin disorder, or irritation occur, Please discontinue use immediately and consult with your doctor promptly.
  • Page 8 2-5. Equipment description and configuration This product has an elongated protruding head (1) at the center of the cushion type body, so that the protruding head (1) is closely contact with the seated person and put the pressure to the perineum part between the buttocks. A sensor for sensing a load applied to the protruding head (1) is installed in the cushion under the protruding head (1).
  • Page 9 * Smartphone model: Android phone 2-6. Specification Articles Sub-Articles Specification Input Voltage DC 3.7V Power Input Current 1.5A Dimension 400mm(width)×297mm(length)×49mm(height) Dimension/ Weight Weight Measurement Measuring range 0 ~ 20kg Warning statement: FCC 15.19: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 10 3. Operations 1 . Sitting on the Device Vertically sit with your body so that the protruding head in the middle of the cushion presses the perineum (between the anus and the urethra). ★ Do not move your body, but contract your pelvic floor muscles with a feeling like to stop urination.
  • Page 11 Fig 4 (Adjust height control) Fig 5(Bottom side of the body) f) In the graph mode, as shown in Figure 6, when you apply force to the pelvic muscles along the green target graph (6), the graph of red muscle strength (7) goes up, and when you release the force, it goes down again.
  • Page 12 Fig 8( Game 1) Fig 9( Game 2) h) Additional explanations about screen 1). Main screen (Kegel exercise mode) Fig 10 ( Main screen Kegel exercise mode) Button Description Choose among Room1 ~ Room5 and guest, then the exercise ① User data is saved to the selected Room No.
  • Page 13 2) Select room Fig 11 Select room Select among Room1~ Room5 and guest, and then exercise data is saved and managed in the selected Room. 3)Setting Fig 12 Setting Input user’s weight, height, exercise time and level. It is for ideal exercise setting for individual user.
  • Page 14 4) Height control Fig 13 Height control Button Description Setting the height of sensor at the middle of the device according to Balancing ① user’s condition. If the arrow is placed at the middle of the graph, it is weight graph ready for the pelvic floor exercise.
  • Page 15 Button Description ① Grade It controls the height of the graph when contract the muscles. There are 1~10 levels, when the level is low, the graph goes up ② Level easily with weak muscles contraction, but in cast of high level, the strong muscles contraction is required for the target graph.
  • Page 16 Button Description Result ① It shows the daily exercise result with graphs. Graph The storage acquired the items currently. Item If you acquired 10 gold metals, it is changed to trophy and if you ② storage acquired 10 trophies, it is changed to Crown. So it motivates users to challenge the next level.
  • Page 17 of the cushion and attach the low frequency pad (10) to the desired area such as the waist, shoulder, and arm (Figure 20. Body low frequency diagram) 3) Click the electric stimulus (3) in Figure 18 to select the low frequency stimulation mode, and then select the low frequency (Body) (5).
  • Page 18 b) Low frequency stimulation to body 1) Press power button on the top of the cushion for at least 2 seconds to turn on the product. 2) Connect the low frequency cable to the low frequency jack (12) on the back of the cushion and attach the low frequency pad (13) to the desired area such as the waist, shoulder, and arm as shown in Fig 25.

  • Page 19: Warranty

    WARRANTY Name Pelvic Floor Muscles Exerciser Model Name Dress Fun Kegel (HnJ-350) Date Warranty 1 year after purchasing date Name Customer Address Phone Company Distributor Phone 1. This device is manufactured under strict quality control and inspection. 2. In case of the problem happened again within 1 year, you can get the A/S service in free of charge.
