Futureworks SPINSHOT360 User Manual

360 photo booth
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
rev. 2017.08.17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPINSHOT360 and is the answer not in the manual?

Questions and answers

Summary of Contents for Futureworks SPINSHOT360

  • Page 1 USER MANUAL rev. 2017.08.17...

  • Page 2: Let's Get Started

    Let’s get started! You, your guests, and SPINSHOT360, are going to have a lot of fun together! Before we start setting up, let’s do a quick check of the contents of your SPINSHOT360 KIT: USB Keylok® Installer 27 Mini-ballheads* 1 Mini-panorama...

  • Page 3: Software Installation

    (micro-USB cables not included in the SPINSHOT360 Kit) Measuring tape Samsung Galaxy A5 (2017) String 6-ft. long Note: Please check our website periodically for updated list of 3 units Universal power strips with 5 outlets (SPINSHOT360 phone models supported. USB chargers have US standard plugs)

  • Page 4: Center Point

    IMPORTANT: IF YOU ARE NOT FAMILIAR WITH NETWORK AND SOFTWARE INSTALLATION, IT WILL HELP TO HAVE SOMEONE WHO CAN ASSIST YOU. IF THIS IS YOUR FIRST TIME TO SETUP SPINSHOT360, WE RECOMMEND TO FOLLOW THIS MANUAL TO THE LETTER. 18ft.
  • Page 5 setup /360 MARKER 6 feet Take out your string and hold one end of it at the center point while your partner holds the other end. Draw a circle with the chalk while holding the other end of the string. center point Note: Like step #2, the circle diameter can vary depending on your configuration.

  • Page 6: Power Supply

    mini-ballhead phone holder PHONE HOLDERS Get the phone holders mini-ballheads. Attach a mini-ballhead to the bottom of each phone holder. Make sure it is sturdy but do not over-tighten. Screw the phone holders to the stand. Tighten to make it sturdy. Adjust the mini-ballhead nut to make the phone holders upright.
  • Page 7 CABLING Get a USB cable. The right-angled USB Type C connector should be placed by the phone holder. The USB Type A connector on the other end should be connected to the nearest USB charging hub. Secure the cable with velcro cable ties.

  • Page 8: Layout Diagram

    LED video lights. 3 to 4 powerful LED video lights should be enough for SPINSHOT360. Distribute the lights outside the circle of stands and the beam should face towards the center point. Refer to your video light’s user manual for set up instructions.
  • Page 9 Next, configure your PC to connect to another WIFI with internet (a Pocket WIFI or another WIFI internet source). You will set your PC to use this WIFI internet connection to send SPINSHOT360 videos to emails, while at the same time connected to the SPINSHOT network via LAN.
  • Page 10 “OK” again. Close the Network Connection window. The PC will now use the WIFI internet to send SPINSHOT360 videos while it uses the SPINSHOT network to communicate with the Android phones. In the notifications area (lower-right of desktop) , connect to an available WIFI internet.
  • Page 11 “Great things come in small packages.” STEP 3 SPINSHOT360 SOFTWARE INSTALLATION You are now ready to set up your SPINSHOT360 software and hardware. Take out the USB Keylok® installer from the SPINSHOT360 cylinder pack. Turn ON your computer and plug-in the USB Keylok®...
  • Page 12 SINGLE-USE Key or PERMANENT Key to the appropriate box to use SPINSHOT360. You may also close the module to proceed using SPINSHOT360 in TEST MODE but it will produce watermarked videos. While in TEST MODE, you may click GO LIVE to enter license keys any time.
  • Page 13 EMAIL SETTING - Note: If you have never done this before, ask your network administrator for assistance. OUTGOING MAIL SERVER –This is your outgoing mail server PORT – This is the port value of the outgoing mail server USERNAME – This is the username of the mail account to be used for sending PASSWORD –...
  • Page 14 SAVE & CLOSE - Click to save all changes you made in the settings the click Close to exit to main screen LAYOUT EDITOR - Lets you customize the look of you SPINSHOT360 PREVIEW SCREEN – Customize your Preview Screen.
  • Page 15 SHARING & PRINTING - Lets you set sharing and printing options. SHARING – Set sharing options. VIDEO HOST SHARING – Lets you set hosting and viewing URL where the video results will be stored and viewed by your guests. The viewing URL will be linked to the QR code generated on each print output FACEBOOK SHARING...
  • Page 16 COUNTDOWN TRIGGER MODE – Lets you set Auto or Manual capture. AUTO will automatically capture a shot after the countdown. MANUAL will let you manually capture a shot. SHOW PHONE TIME SYNC REPORT – Lets you show or hide the Report Button beside the Sync Button in the main screen.
  • Page 17 All devices should be GREEN. If not, sync again or restart phones, PC, and network. GO LIVE Opens License entry module for your SINGLE-USE or PERMANENT License Key. INFO A quick information guide to Phone and Tablet Status Codes and Buttons. EXIT Closes and Exits the SPINSHOT360 PC App.
  • Page 18 PREVIEW SCREEN The 3 preview screens shows 3 sample shots taken in short intervals. This allows you to select the best-timed shots. By default, the center screen is selected. A thick pink border indicates the selected shot. Just click on any screen to select the shot.
  • Page 19 USING THE SPINSHOT360 CAMERA APP Launch the SPINSHOT360 Camera app. Click the SETTINGS button to assign device numbers. Each phone should have a unique device number. Click when done. Click BACK button to return to preview screen. Lock screen Settings...
  • Page 20 USING THE SPINSHOT360 SENDER APP Choose SENDER App in the SPINSHOT360 Suite home screen. The SENDER App allows SPINSHOT360 to share videos to emails. Make sure the Sender device is connected to the SPINSHOT360 network and synced to the PC.
  • Page 21 Send. The video/s will be sent to the email. Enable fields in the settings screen. USING THE SPINSHOT360 COUNTDOWN APP Choose COUNTDOWN App in the SPINSHOT360 Suite home screen. COUNTDOWN App helps your guests follow the timing of the shot. Make sure the COUNTDOWN device is connected to the SPINSHOT network and is synced to the PC.

  • Page 22: Product Specifications

    Copyright© Futureworks International Limited 2017. All rights reserved. SPINSHOT360 is protected by copyright law and international treaties. The software is licensed (not sold), and its use is subject to a License Agreement. Unauthorized use, copying or distribution of the program or any of its components may result in severe criminal or civil penalties, and will be prosecuted to the maximum extent under the law.

  • Page 23: Limited Warranty Statement

    What Futureworks International Limited Will Do a. During the warranty period, Futureworks International Limited will repair or replace the covered items or its components found to be defective. The purchaser/owner of the product shall not be charged for such repair or replacement within the warranty period. All replaced items, as well as the parts and/or components thereof, shall become the property of Futureworks International limited.
  • Page 24 Futureworks International Limited 502 Golden Gate Commercial Building, 136-138 Austin Road, Kowloon, Hong Kong...
  • Page 25 www.SPINSHOT360.com...
