- Page 1 HT18/36 RT25/50 Regular Traffic High Traffic • • 12V/24V 12V/24V • • 25/50m per min 18/36m per min • • 500/300kg 600/300kg Proudly manufactured by www.dace.co.za Ver 1.01...
-
Page 2: Table Of Contents
Page Table of Contents Foreword —————————————————————————————–—————— Abbreviations —————————————————————————————————-- Introduction & Recommendations ——————————————————–———————- Specifications Ultima Operator ———————————————————————–——————- Tritek Controller ———————————————————————–——————- Operator & Site Basics Operator Parts Identification ————————————————–———————— 7 Site Layout ————————————————————————————————- 8 Gate Pull & Running Forces ————————————————————————- 8 Cable Recommendations ——————————————————–———————-- Installing the Operator Anchoring the Foundation Plate ———————————————–———————... -
Page 3: Foreword
FOREWORD Thank you for choosing Dura Access Control Equipment (DACE). We welcome you to the ever growing community of happy DACE product owners. The advanced engineering and high-quality construction of each DACE product we build is something of which we are proud. -
Page 4: Introduction & Recommendations
Do not attempt to repair the equipment, this should only be done by a qualified DACE technician. DACE will not be held liable for any accident / incident resulting in damage, injury or death ensuing from the incorrect installation of the automatic gate operator. -
Page 5: Specifications
……..continued DACE cannot be held responsible for a gate bumping either of the ends stops if it runs on a slope. Do not operate the gate unless within direct sight of the gate. A gate is a heavy piece of equipment and injury, even death, may occur due to incorrect installation or opera- tion of the equipment. -
Page 6: Tritek Controller
TRITEK CONTROLLER SPECIFICATIONS Continues……... -
Page 7: Operator Parts Identification
……..continued OPERATOR PARTS IDENTIFICATION PARTS LIST 1. Tritek Controller 6. Foundation Plate 11.Transformer 2. Rev Counter Housing 7. Height adjustment Nuts 12.Battery 3. 12 Volt DC Motor 8. LCD Interface 13.GSM/WiFI Module Input 4. Cam Lock 9. Joystick 14.Marker Sensor 5. -
Page 8: Site Layout
SITE LAYOUT 1. Intercom Gooseneck 5. Exit Loop 9. Guide Rollers 2. Catch Bracket 6. Isolator Switch 10.Pillar Light 3. Close Safety Beam 7. Marker Magnet 4. End Stop 8. Open Safety Beam GATE PULL & RUNNING FORCES The gate Pull and Running Forces must be measured before installing the operator. - Page 9 GATES ON A GRADIENT We do not recommend automating a gate which is not level. Failure to level the gate will put undue stress on the operator. Furthermore, if the operator is in manual override mode, the gate may run freely down the slope and present a safety risk.
-
Page 10: Cable Recommendations
CABLE RECOMMENDATIONS Two options for power supply: 1. Option 1 (Recommended): Low voltage supply 14-24V AC via transformer placed in the house, max 50m from operator with 3 core 1.5mm (Live, Neutral & Earth). 2. Option 2: High voltage mains supply connected to a 220V/240V AC Double Pole Isolator switch, mounted within 1.5m of the operator connected to the transformer inside the operator. -
Page 11: Anchoring The Foundation Plate
❷. III. Ensure a 23mm clearance between the inner edge of the foundation plate and the edge of the gate. This measurement is based on DACE rack. See below to calculate clearance if using other rack. -
Page 12: Securing Operator To The Foundation Plate
Adjusting Nuts MOUNTING THE RACK ON THE GATE Spacing between the Rack and the Pinion DACE Grey Nylon Rack All Other Nylon Rack This rack has a 2mm ‘built in spacer’ There must be a 2mm clearance... - Page 13 ……..continued 1. Rest the rack on the pinion with the end of the rack and the end of the gate aligned. Having the gate slightly open will allow access to the first slot on the rack. 2. Clamp the opposite end of the rack to the gate. 3.
-
Page 14: Placing Oil In The Gearbox
PLACING OIL IN THE GEARBOX It is important that the gearbox be filled with oil before commissioning the operator. Only use SAE75W-90 oil to refill. Fill the gearbox with the oil provided as shown. The The gearbox oil will need to be topped up periodically. entire bottle (70ml) must be emptied into the gearbox. -
Page 15: Tritek Control Board Layout
TRITEK CONTROL BOARD LAYOUT 20A FUSE REV COUNTER MARKER GSM/WiFi BATTERY –VE MOTOR INPUT INPUT INPUT 3A FUSE JOYSTICK SPEAKER BATTERY AUX OUTPUT BATTERY +VE 12V - 24V OVERVIEW OF POWER CONNECTIONS & FUSES FUSE 20A: this fuse protects the motor in ... -
Page 16: Overview Of Low Power Inputs & Outputs
OVERVIEW OF LOW POWER INPUTS & OUTPUTS INF-GND: this is a dedicated ground, used to connect certain brands of safety beams that have the capacity of performing a self test function, such as the DuraOptics Wireless Beams. INF/CLS: connect to the safety beam relay or FET output ... -
Page 17: Charging Supply Options
CHARGING SUPPLY OPTIONS MAINS 220-240V AC HOUSE EARTH WARNING!!! WHEN USING A SOLAR PANEL DISCONNECT THE TRANSFORMER NOT POLARITY SENSITIVE SOLAR PANEL MAX 40V DC... -
Page 18: Menu Navigation Overview
MENU NAVIGATION OVERVIEW IDLE MODE The LCD screen will remain in Idle Mode if the Joystick has not been moved for awhile and will scroll through the following 3 screens. JOYSTICK MENU NAVIGATION The Joystick moves in 5 directions: UP (North); DOWN (South); LEFT (West); RIGHT (East) for navigation and IN- WARD (Press) for item selection. -
Page 19: Commissioning The Operator For The First Time
……..continued INFORMATION SCREEN MENU ICONS: Battery - Displays the current battery voltage, charge current and charge voltage. Mains Supply - Displays the current type of supply, supply voltage and output voltage. GSM / WiFi - Displays the status of the GSM or WiFi module connected to the controller Gate - Displays the number of operations, average force and maximum force of the gate while running Receiver - Displays information about the last remote signal that was received. -
Page 20: Two Sets Of Safety Beams (Relay Output)
TWO SETS OF SAFETY BEAMS (RELAY OUTPUT) MAX. LOAD 300mA... -
Page 21: External Radio Receiver & Loop Detector
EXTERNAL RADIO RECEIVER & LOOP DETECTOR MAX. LOAD 300mA... -
Page 22: Closing Safety Beam (Fet Output & Relay Output)
CLOSING SAFETY BEAM (FET OUTPUT) CLOSING SAFETY BEAM (RELAY OUTPUT) -
Page 23: Opening Safety Beam (Fet Output & Relay Output)
OPENING SAFETY BEAM (FET OUTPUT) OPENING SAFETY BEAM (RELAY OUTPUT) -
Page 24: Connecting Common External Devices
CONNECTING COMMON EXTERNAL DEVICES HOLIDAY LOCK OUT (Normally Open) (Keypad, Receiver, Keyswitch) PEDESTRIAN OPENING (Keypad, Receiver, Keyswitch) (Normally Open) FULL OPEN (Intercom) (Normally Open) STATUS LED (Intercom) TAMPER SWITCH Tamper Switch is CLOSED when the lid is removed (Normally Closed) -
Page 25: Connection For Relay Module
CONNECTION FOR RELAY MODULE OUTPUT DEPENDANT ON VOLTAGE OF BATTERY FITTED. ENSURE ALL EXTERNAL DEVICES ARE CORRECTLY RATED. MAX. LOAD of 100mA DACE DACE Relay Module Relay Module ZONE BYPASS LIGHT... -
Page 26: Electric & Magnetic Locks
ELECTRIC LOCK ELECTRIC LOCK 3A MAX MAGNETIC LOCK MAGNETIC LOCK 500mA max @ 12V 250mA max @ 24V... -
Page 27: Connecting Various Devices To Pulse & Alarm Outputs
CONNECTING VARIOUS DEVICES TO PULSE & ALARM OUTPUTS (USING RELAY MODULE) SIREN DACE Relay Module BELL DACE CAUTION!!! Relay Module OUTPUT DEPENDANT ON VOLTAGE OF BATTERY FITTED. ENSURE ALL EXTERNAL DEVICES ARE CORRECTLY RATED. MAX. LOAD 300mA WIRED ALARM BUZZ... -
Page 28: Two Synchronised Operators Connected To One Set Of Safety Beams
TWO SYNCHRONISED OPERATORS CONNECTED TO ONE SET OF SAFETY BEAMS (USING BEAM RELAY OUTPUT) OPERATOR CONTROL BOARD NO. 1 WARNING!!! ONLY CONNECT +BATT TO ONE MOTOR AS SHOWN OPERATOR CONTROL BOARD NO. 2 MAX. LOAD 300mA WARNING!!! ONLY CONNECT BEAMS RECEIVER GND TO TRITEK COM-GND... -
Page 29: Control Board Functions
Note the following functions on the TRITEK menu: Help To get help on any of the onboard functions, move the cursor to the specific icon for which more information is required. If the cursor is left standing on the same icon for more than six seconds, a help screen will automatically appear. -
Page 30: Auto Close Setup
AUTO CLOSE SETUP To prevent accidents, Safety Beams must be used when enabling the Auto Close function. Enable Auto Close Enabling this function allows the gate operator to Auto Close. If the gate is obstructed and Safety Beams are connected, the Auto Close Time delay will reset when the obstruction is removed. Auto Close Time This feature delays the closing of the gate when Auto Close is enabled. - Page 31 ……..continued Add Remotes (With groups) If the controller has more than just the original Group 0, it will prompt for the group number to which the new remote/s must be added. After selecting the required group number follow the same steps as listed in Add Remotes (No groups).
-
Page 32: Pedestrian Entry
……..continued Copy Group This feature copies the settings from one group, thereby making it easy to set up a new group with just minor adjustments. When setting up a new group for the first time, use the ‘Copy Group’ function to copy Group 0, thereby creating a new group, and then use the ‘Edit Group’... -
Page 33: Light Settings
LIGHT SETTINGS Courtesy Light Usually used to switch pillar lights on when the operator is triggered. The light output must be connected to an EXO Relay Module. Do not connect mains directly to the controller. Set Light Timer This function sets the length of time that the light will remain on if the Courtesy Light option is enabled. Flash On Moving If enabled, the light connected to the light output on the controller will flash while the gate is moving. -
Page 34: Lock Settings
……..continued Alarm Duration This setting adjusts the duration that the alarm output will remain active. Hold Alarm This setting will keep the alarm output activated for as long as an alarm condition persists. The alarm output will only switch off after the alarm condition is removed and the alarm duration time has expired. Rearm Duration This setting prevents alarm conditions from continuously retriggering the alarm output. -
Page 35: Operating Modes
Operator Type When connecting a Tritek controller to an operator that is not a DACE product, use this setting to select the brand and the series of the operator to ensure compatibility. An Interface Module is required to connect the Tritek controller to a non DACE product. -
Page 36: Usb Settings
Check the DACE website regularly for Tritek software updates. Save the updated software on to a USB Flash Drive or Android device and update the Tritek controller. Remember to make a full backup of the controller before loading the updated software. -
Page 37: Hid Settings
HID SETTINGS (Human Interface Device) Contrast Adjust the display contrast for better viewing. Cursor Speed Adjust the cursor speed for easier selection of icons. Click Speed Adjust how fast the joystick reacts to being held down or multiple presses. Voice Assistant Enable or disable the Voice Assistant during programming. - Page 38 ……..continued Before using Time Manager ensure that the controller Date and Time are set correctly. Set Time & Date This function sets the controller time and date. Set Time Period (120 Periods & Exclusions in total) Use this function to set up new Time Periods following these steps. ❶...
-
Page 39: Gate Setup
GATE SETUP Setup Wizard This function automatically programs the open and closed gate limits. The Setup Wizard will run auto- matically after the first power up of a new operator or after a gate factory reset (see Use Factory Settings). The Setup Wizard can be run anytime the limits need to be relearnt. Follow the prompts to complete. - Page 40 ……..continued Open Ramp Up Adjusts the Ramp Up distance before maximum running speed is reached when the gate is opening. Opening Speed Adjusts the maximum opening speed. Open Ramp Down Adjusts the Ramp Down distance before running at crawl speed when the gate is opening. It should be noted that a very short ramp down may damage plastic rack or place unnecessary strain on the gate motor, especially if the gate is heavy.
-
Page 41: Additional Features
……..continued Positive Close If enabled, the open and close gaps are ignored and the gate will stop touching the end stops. This is usually used in conjunction with electric fencing where it is required that the gate stops against contacts for the electric fence. Positive Close Force Sets the force the motor will exert on the end stop when it reaches it. -
Page 42: Upgrading Controller Software
UPGRADING CONTROLLER SOFTWARE Step 1: Download the latest version of the Tritek controller software from www.dace.co.za or it can be received by WhatsApp or email. Step 2: Save the software onto a USB Flash Drive or into the Downloads directory in a compatible Android phone. -
Page 43: Notification Messages
……..continued ANNUALLY Many sealed lead acid batteries do not last for more than one year. The battery condition can be checked by disconnecting the mains supply to the operator. Go to Quick NAV on the LCD screen and press the joystick to enter the Info menu. -
Page 44: Warning Messages
……..continued MESSAGE DESCRIPTION TRIGGER The operator received a trigger signal. PEDESTRIAN The operator received a pedestrian trigger. LOOP The operator received a loop trigger. ACTIVATION IS NOT POSSIBLE WHEN THERE IS If the battery voltage is too low, the controller will not activate the gate. A BATTERY FAULT CONDITION ACTIVATION IS NOT... - Page 45 Check that the motor wires are connected properly and making proper contact. If this fault persists the controller might need to be repaired by a DACE repair centre. MOTOR The controller has detected that the electric motor is disconnected.
-
Page 46: Glossary
FAULT Ensure that the controller is sitting properly on the controller base. If a Tritek controller is being used on a older DACE product i.e. not an Ultima, check that the encoder is plugged in correctly. OPENING IR... - Page 47 ……..continued Main PC Board See Controller Manual Override Allows the gate to be moved manually. Multi User Mode Used in a Townhouse application. The controller will not accept a trigger while opening to prevent the accidental closing of the gate on a vehicle/person. Operator Gate motor.
-
Page 48: Technical Specifications
TECHNICAL SPECIFICATIONS CONTROLLER SYSTEM Main - ARM core - 90 DMIPS Dual Processor Supply - Microchip - 8 MIPS Supply Intelligent multi stage dual switch mode 3.5V, 5V, 7V, 13 - 29.4V Motor Drive Single / Dual H-Bridge 56 Amp Inputs INF/CLS, INF/OPN, LOCK, TRIG, PED, LOOP, LIGHT, TAMPER, REV1, MARKER1, GSM Outputs... -
Page 49: Terms & Conditions
compromising the site's security. All DACE operators must be fitted with safety beams or edges. If the user elects not to install these safety devices, they acknowledge that there is a high risk of the gate or door closing on an object, person or animal. - Page 50 NOTES Recommendations of notes that should be kept: » Groups - group number and group members » Time Manager slots - Time Period and Exclusion Period numbers » Remote users and the respective remote number (label the remotes) » Remote button numbers and the functions assigned to each (see pg. 30) »...
- Page 51 NOTES...
-
Page 52: Warranty & Disclaimer
This warranty is a factory warranty, all goods will be repaired at the factory or one of the DACE designated repair centres. In the case of international customers, the defective product must be returned to the supplier from where the product was purchased WITH PROOF OF PURCHASE FROM THAT SUPPLIER.
