Kids Scandinavia - Table And 2 Chairs
Assembly Instructions
Retain these instructions for future reference
Dimensions
Table
Width - 50cm
Depth - 45cm
Height - 52cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
Chair
Width - 36cm
Depth - 35cm
Height - 60cm
498/1699
503/4459
Issue 2 - 07/11/2016
Advertisement
Related Manuals for Argos Kids Scandinavia
Summary of Contents for Argos Kids Scandinavia
- Page 1 Kids Scandinavia - Table And 2 Chairs Assembly Instructions 498/1699 Retain these instructions for future reference 503/4459 Dimensions Table Chair Width - 50cm Width - 36cm Depth - 45cm Depth - 35cm Height - 52cm Height - 60cm Important – Please read these instructions fully before starting assembly...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • Dispose of all packaging components and tools listed on the product, this could cause carefully and responsibly.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the panels listed below Table top (50 x 45cm) underside Short rail x 2 (33 x 5cm) Long rail x 2 (38 x 5cm) Table leg (50.2 x 4.5cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 80mm Screw x 4 Washer x 4 70mm Screw x 12 Allen key x 1 50mm Screw x 18...
- Page 5 Components - Key Diagram Table Components - Key Diagram Chair...
- Page 6 Assembly Instructions Assembly of the table Step 1 Assemble rails Fix all border fitts to the long rails with screws Fix short rails pre assembled long rails with screws Chamfers down...
- Page 7 Assembly Instructions Step 2 Fix top to pre assembled rails Put dowels into table assemble pre assembled rails to the pre-inserted dowel on top Fix rails with screws Step 3 Mounting the table legs onto the table top. Put the nut in leg and fix with screw...
- Page 8 Assembly Instructions Step 4 Press the table legs onto the table top Fix the table legs, using , washers spanner through the holes indicated. Assembly of the chair Step 1 Inserting the dowels to the top plinth and side rails. Insert the dowels into the holes indicated on...
- Page 9 Assembly Instructions Step 2 Mounting the top plinth and the side rails onto the left leg. Press the top plinth and the side rails onto the left leg Fix the top plinth and the side rails using screws and allen key through the holes indicated.
- Page 10 Assembly Instructions Step 5 Adding the seat to the chair. Fix the side rails onto the seat using screws through the holes indicated. Repeat with remaining chair Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800...
-
